48˝
BCD36.2D
BCSS12RL
BCSS12LR
48˝
34
1
/
2
˝
24˝
33˝, 36˝
36˝, 33˝
28˝
20 / ˝
24˝
23 / ˝
24˝
34
1
/
2
˝
24˝
26 / ˝
6 / ˝ , 8 / ˝
23 / ˝
33˝
36˝
33˝, 36˝
24˝
All dimensions are to
outside of frame
34
1
/
2
˝
24˝
33˝, 36˝
36˝, 33˝
23 / ˝
23 / ˝
20 / ˝
24˝
24˝
E28
Base Corner Cabinets
Base Cabinets
Asymmetrical Easy Reach
Specify R or L
EZR3633 R or L
EZR3336 R or L
• One fixed shelf
• Frame opening from left to right edge is
12 7/8˝
• Face frame is scooped for hinge installation
on full overlay door styles
• Doors are profiled on one long and two short
edges and are connected with hinges
• Angled back provides clearance for
installation
• 29˝ door clearance recommended for
delivery
• Harlowe, Smithton and Vanderbilt doors will
have a solid, recessed flat panel. Courtney
doors will have a veneer, recessed flat panel.
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
•
Note:
Does
not
include Soft-Close feature
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
CW
RD
l
CH
TWR
l
WR
l
XS
GD
l
RTK
RTKP
l
VTK
Easy Reach Wood Super Susan
Specify R or L
Iu
EZR33 R or L•WSS
EZR36 R or L•WSS
• Two pie-cut shelves rotate individually
• EZR33 has 28˝ diameter shelves; EZR36 has
32˝ diameter shelves
• Rotating shelves have plywood floor and
solid wood trim
• Shelves rotate independently
• Frame opening, from left to right edge is
10 1/2˝ for EZR33 and 14 3/4˝ for EZR36
• Face frame is scooped for hinge installation
on full overlay door styles
• Doors are profiled on one long and two short
edges and are connected with hinges
• Angled back provides clearance for
installation
• 29˝ door clearance recommended for
delivery
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
I
Not
available with Aluminum Frame Glass
doors
•
Note:
Does
not
include Soft-Close feature
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
CW
RD
l
CH
TWR
l
WR
l
XS
I
GD
l
RTK
RTKP
l
VTK
I
Glass door option
not
available
u
Harlowe, Smithton and Vanderbilt doors will
have a solid, recessed flat panel. Courtney
doors will have a veneer, recessed flat panel.
Asymmetrical Easy Reach Wood Super Susan
Specify R or L
EZR3633 R or L•WSS
EZR3336 R or L•WSS
• Two pie-cut 28˝ diameter rotating shelves
• Shelves rotate independently
• Rotating shelves have plywood floor and
solid wood trim
• Frame opening from left to right edge is
12 7/8˝
• Face frame is scooped for hinge installation
on full overlay door styles
• Doors are profiled on one long and two short
edges and are connected with hinges
• Angled back provides clearance for
installation
• 29˝ door clearance recommended for
delivery
• Harlowe, Smithton and Vanderbilt doors will
have a solid, recessed flat panel. Courtney
doors will have a veneer, recessed flat panel.
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• Order Example as shown: EZR3633 L•WLS
•
Note:
Does
not
include Soft-Close feature
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
CW
RD
l
CH
TWR
l
WR
l
XS
GD
l
RTK
RTKP
l
VTK
Base Corner Drawer Cabinet and Base Corner Smart Space Companion View
Base Corner Smart Space
(BCSS) cabinets can also be
used as an alternate corner
solution when used with a
Base Filler 3x3 (BF3X3) in place of a
Base Corner Drawer (BCD) cabinet
