Wall Hoods
Wall Cabinets
Wall Hood Matching Straight Valance
23 1/2” High
WHMSV3624
WHMSV4224
WHMSV4824
WHMSV5424
30” High
WHMSV3630
WHMSV4230
WHMSV4830
WHMSV5430
• Solid wood/wood veneer construction
• 23 1/2˝ high units are designed to align with
90˝ cabinets
• 30˝ high hoods are designed to align with
96˝ high cabinets
• Will accept optional onlays, ordered
separately; see Molding Accents section of
this book
• Check local building codes for required
clearances between the Wall Hood and
cooking surface
• Requires Wall Hood Component Package
“G”, located before the Wall Hood Designs in this section
• Doors open to facilitate duct installation and wiring
• Laminates are painted hardwood
•
Not
available in Morristown. Melrose and Putnam
supplied plain sawn
•
Note
: Wall Hood
must
be installed between two cabinets
•
Note
: Cabinetry and appliances located below these Wall
Hoods
must
be pulled to a minimum of 27˝deep and a
maximum of 30˝ deep for improved function
PE
v
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
XS
XSG
GD
WHMSV36
12˝
23˝
18˝
open
18˝
23
1
/
2
˝
30˝
WHMSV42- 54
12˝
12˝
15˝
16
1
/
2
˝
18˝
18˝
21˝
12˝
15˝
16
1
/
2
˝
open
2
1
/
4
˝
2
19
/
64
˝
6
1
/
4
˝
6
3
/
16
˝
23
1
/
2
˝
30˝
Opening Sizes
Cabinet
Top Width
Top Depth BottomWidth Bottom Depth Floor Opening
Width
Floor Opening
Depth
WHMSV36
33 ⅛˝
10 ⁄
˝
34 ⅝˝
21 ⁄
˝
29 ⅛˝
17˝
WHMSV42
39 ⅛˝
10 ⁄
˝
40 ⅝˝
21 ⁄
˝
29 ⅛˝
17˝
WHMSV48
45 ⅛˝
10 ⁄
˝
46 ⅝˝
21 ⁄
˝
29 ⅛˝
17˝
WHMSV54
51 ⅛˝
10 ⁄
˝
52 ⅝˝
21 ⁄
˝
29 ⅛˝
17˝
