D36
Wall Hoods
Wall Cabinets
Peninsula Wall Hood Classic Artisan Chimney
30 5/8” High
PWHCC302830 •A
PWHCC363330 •A
PWHCC423330 •A
42 5/8” High
PWHCC302842 •A
PWHCC363342 •A
PWHCC423342 •A
54 5/8” High
PWHCC302854 •A
PWHCC363354 •A
PWHCC423354 •A
• Solid wood/wood veneer construction
• Check local building codes for
required clearances between the
Wall Hood and cooking surface
• A 3˝ space is recommended on
the right and left side of this unit
before beginning the adjacent
cabinet runs
• 30 5/8˝ high hoods are designed
for use with 8 foot ceilings
• 42 5/8˝ high hoods are designed
for use with 9 ft. ceilings
• 54 5/8˝ high hoods are designed
for use with 10 ft. ceilings
• Shaded areas are unfinished
surfaces that allow for field
application of paint or other
decorative material
• Lower molding matches Beaded Panel Molding
(BPM8) profile, other molding matches Soffit
Crown Molding profile (SCM8)
• Chimney section shipped separately
• This product will
not
be covered under warranty
once alterations of any kind have been made
• Will accept optional onlays, ordered separately;
see Molding Accents section of this book
•
Not
designed to be used with a soffit
• Painted hardwood supplied for EverCore™ and
Laminate
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
•
Not
available in Morristown. Melrose and
Putnam supplied plain sawn
• 30˝ wide requires Wall Hood Component
Package “K”, located before the Wall Hood
Designs in this section
• 36˝–42˝ wide requires Wall Hood Component
Package “H” or “O”, located before the Wall Hood
Designs in this section
•
Note
: Cabinetry and appliances located below
these Wall Hoods
must
be pulled to a minimum
of 27˝deep and a maximum of 30˝ deep for
improved function
•
Note
: Wall hood
must
be securely anchored to
ceiling
PE
v
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
XS
XSG
GD
Opening Sizes
Cabinet
Top Width
Top Depth BottomWidth Bottom Depth
PWHCC30•A
7 ⁄
˝
6 ⁄
˝
28 ½˝
24 ½˝
PWHCC36•A
14 ½˝
10 ½˝
34 ½˝
28 ⁄
˝
PWHCC42•A
20 ½˝
10 ½˝
40 ½˝
28 ⁄
˝
Unless indicated, measurements include molding.
Shaded areas are unfinished.
PWHCC•A
28
3
/
16
˝
32
7
/
16
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
11
3
/
4
˝
15
1
/
2
˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
6
5
/
16
˝
8˝, 20˝, 32˝
22
5
/
8
˝
30
5
/
8
˝
42
5
/
8
˝
54
5
/
8
˝
Wall Hood Classic Chimney Raised Panel Valance
Plain
32” High
WHCCRPV301932 •P
WHCCRPV361932 •P
WHCCRPV362432 •P
WHCCRPV422432 •P
44” High
WHCCRPV301944 •P
WHCCRPV361944 •P
WHCCRPV362444 •P
WHCCRPV422444 •P
56” High
WHCCRPV301956 •P
WHCCRPV361956 •P
WHCCRPV362456 •P
WHCCRPV422456 •P
Beaded Panel
32” High
WHCCRPV301932 •BE
WHCCRPV361932 •BE
WHCCRPV362432 •BE
WHCCRPV422432 •BE
44” High
WHCCRPV301944 •BE
WHCCRPV361944 •BE
WHCCRPV362444 •BE
WHCCRPV422444 •BE
56” High
WHCCRPV301956 •BE
WHCCRPV361956 •BE
WHCCRPV362456 •BE
WHCCRPV422456 •BE
• Solid wood/wood veneer
construction
• A 3˝ space is recommended on
the right and left side of this unit
before beginning the adjacent
cabinet runs
• Decorative molding matches
Soffit Crown Molding profile
(SCM8)
• Chimney section shipped
separately
•
Not
designed to be used with a
soffit
• Painted hardwood supplied for EverCore™ and
Laminate
•
Not
available in Morristown. Melrose and
Putnam supplied plain sawn
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
• 19˝ deep requires Wall Hood Component
Package “J”, located before the Wall Hood
Designs in this section
• 24˝ deep requires Wall Hood Component
Package “G” or “P”, located before the Wall
Hood Designs in this section
•
Note
: Cabinetry and appliances located
below these Wall Hoods
must
be pulled to a
minimum of 27˝deep and a maximum of 30˝
deep for improved function
•
Note
: Wall Hood
must
be securely anchored to
wall
The Wall Hood Classic Chimney
Raised Panel Valance includes a
representative raised panel profile
that blends with most raised panel
door styles. It may
not
match the chosen door
style exactly. Consider designing in a valance
on the adjacent wall of the cooking area to
coordinate with this style hood.
PE
v
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
XS
XSG
GD
Cabinet
Opening Sizes
Top Width
Top Depth Bottom Width Bottom Depth
WHCCRPV30
8˝
WHCCRPV36
10¾˝
WHCCRPV42
20 ½
˝
10¾˝
14 / ˝
18 / ˝
21 / ˝
21 / ˝
7 / ˝
28 / ˝
34 / ˝
40 / ˝
WHCCRPV•P
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
32˝
44˝
56˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
20
3
/
16
˝
23
7
/
16
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
11
3
/
4
˝, 15˝
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
32˝
44˝
56˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
20
3
/
16
˝
23
7
/
16
˝
32
7
/
32
˝
38
1
/
4
˝
44
1
/
4
˝
11
3
/
4
˝, 15˝
WHCCRPV•BE
Unless indicated, measurements include molding
