D1
Wall Cabinets
Caution
: Installation of a wall cabinet 30˝ or wider requires additional support,
such as attachment to a soffit, or support from below.
Wall Cabinets
Wall Cabinets
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
Note
: Standard wall cabinet box depth is 12˝ unless stated otherwise. Add door
thickness with bumpers for total depth.
Note
: Wall cabinets with standard matching Viraguard interior, or Wall cabinets
ordered with matching Viraguard interior option will be supplied with Natural
Birch exterior material. Wall cabinets with standard matching interior, Wall cabinets
ordered with APC, FPEB or APF, or Wall cabinets ordered with MIP, MIFP, MIAPFC
will have exterior floors and ceilings that are finished to match.
Caution
: Installation of a wall cabinet 30” or wider requires additional support, such as attachment to a soffit, or support from below.
Failure to provide additional support could result in collapse of the cabinet, serious personal injury, or property damage. Damage
relating to failure to provide additional support is
not
covered by the limited warranty. See inside cover for warranty details
Material dimensions listed may vary slightly from actual dimensions of the product.
Specifications subject to change without notice.
WR 30
12
code
width
height
Wall Single Door 12”-42” H
Specify R or L
No shelf
12” High
r
W1212 R or L
r
W1512 R or L
r
W1812 R or L
r
W2112 R or L
15” High
W1215 R or L
W1515 R or L
W1815 R or L
W2115 R or L
18” High
W1218 R or L
W1518 R or L
W1818 R or L
W2118 R or L
W2418 R or L
One shelf
23 1/2” High
mi;
W924 R or L
W1224 R or L
W1524 R or L
W1824 R or L
W2124 R or L
W2424 R or L
27” High
srm
W1527 R or L
srm
W1827 R or L
srm
W2427 R or L
Two shelves
30” High
im;
W930 R or L
W1230 R or L
W1530 R or L
W1830 R or L
W2130 R or L
W2430 R or L
33” High
im;
W933 R or L
W1233 R or L
W1533 R or L
W1833 R or L
W2133 R or L
W2433 R or L
Three shelves
36” High
im;
W936 R or L
W1236 R or L
W1536 R or L
W1836 R or L
W2136 R or L
W2436 R or L
39” High
im;s
W939 R or L
s
W1239 R or L
s
W1539 R or L
s
W1839 R or L
s
W2139 R or L
s
W2439 R or L
42” High
im;s
W942 R or L
s
W1242 R or L
s
W1542 R or L
s
W1842 R or L
s
W2142 R or L
s
W2442 R or L
12˝
15˝
18˝
W930-W2433
W1212-W2418
W924-W2427
23 ½˝
27˝
30˝
33˝
12˝
12˝
12˝
36˝
39˝
42˝
12˝
W936-W2442
r
Change Height (CH) option
not
available
m
Change Width (CW) option
not
available
i
Doors are square except full overlay arch door styles. Laminate
door styles will always be square. Harlowe, Smithton and
Vanderbilt doors will have a solid, recessed flat panel.
;
Glass door option
not
available
s
Top Wide Rail (TWR) option
not
available
PE
Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI
Matching Interior
DE Integrated Decorative End
OE Operational End
CW Change Width
RD Reduced Depth
ID Increased Depth
CH Change Height
TWR Top Wide Rail
XS
Extended Stile
XSG Integrated Extended Stile
GD Glass Doors
• Adjustable shelves
I
Integrated Extended Stile (XSG) only
available on cabinets 30” high or
higher
I
Operational End (OE) is
not
available
with Increased Depth (ID) or
Reduced Depth (RD) options
Tip: When mounting a 6”
Spice Drawer (SD—) or
Organizer (O—)
underneath a 23 1/2” cabinet next to
a 30” high wall cabinet, the overall
height will be 29 1/2”. To correct this,
you can place a piece of Stack
Molding (STM8) or a 1/2” filler between the 23
1/2” cabinet and the 6” cabinet.
Remember, all 9” wide doors in 1/2”
overlay will be square even for a roman
door style. If a 9” cabinet is required, one
suggestion is to void the door and order the
cabinet with matching interior and use it as a
decorative open cabinet.
Any wall cabinet over 24˝ wide or 30˝
high or higher with a depth greater than
12˝ and/or with butt doors must be
installed between two (2) cabinets, a cabinet and a
wall or supported from below
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
OE
I
CW
l
RD
l
ID
I
CH
I
TWR
l
XS
I
XSG
I
GD
