C25
Construction Options
Specifications and Options
Reduce Depth & Change Height
Two Dimensions
RD.CH
• Many cabinets can be changed to your
desired depth and height. Consult chart
for suggested minimums that control the
functionality of cabinet
• Any cabinet reduced in depth to less than
4 5/8” will be shipped as a Cabinet Front
Only (CFO)
• To Change Height (CH) on wall cabinets
18 1/16” to 23 7/16” H, select a nominal
24” H cabinet (heights cannot be modified
on 21” H cabinets); for heights 23 9/16” to
29 15/16” H, select a nominal 30” H cabinet
(heights cannot be modified on 27” H
cabinets)
• 34 1/2” H Base Cabinets can be increased
in height to 42” H; height adjustments will
be made to the door section of the base
cabinet, therefore height adjustments are
not
available for
drawer stack cabinets
• For Tall 72 1/2”–83 15/16” H, select a nominal 84” H
cabinet; height adjustments will be made to the upper
section of the tall cabinet
•
Not
available in High-Gloss Laminate or Woodgrain
Laminate door styles
• Consult option availability chart for your desired cabinet
PE
APC
APFC
FPEB
MI
DE
OE
CW
l
RD
ID
l
CH
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
Change Height
Cabinet
Wall
12˝
54˝
Base
29 ⁄
˝
42˝
Tall
Vanity Base
72 ½˝
29 ⁄
˝
96˝
42˝
Max. Height
Min. Height
Cabinets
Reason for restrictions
4
⅝
˝
All
Minimum for shelf hole drilling
6˝
All except
walls
Minimum for toe kick notch Less than 6” WR is mandatory
9˝
PB
Minimum for toe kick notch Less than 9” WR is mandatory
10˝
WZA
Minimum allowed
10 ⅝˝
WZA
Minimum for shelf
12˝
BZA
Minimum allowed
12˝ All except
walls
18˝
BEA
WEA
Minimum allowed
12˝
WWH
Minimum for working drawer - less than 12” depth
will have false drawer
Wine Storage section always 12” deep
Reduced Depth
Min.
Depth
Cabinet
Drawer Box
Depth
24” >
20 ⁄
”
21”–23 ⁄
”
17 ⁄
”
18”–20 ⁄
”
14 ⁄
”
15”–17 ⁄
”
11 ⁄
”
12”–14 ⁄
”
8 ⁄
”
< 12”
No drawer
