2″ Ajax Upsetter
- Header Slide Load Rating: 400 Tons
- Die Grip Rating: 248 Tons
- Approx. Total Weight: 39,000 lbs
- Floor Space (L-R x F-B): 7′ 0″ x 10′ 8″
- Height Above Floor: 6′ 8″
- Distance Below Floor: 0′ 6″
- Operating Air Pressure: 75 PSI
- Main Motor: 5 HP/900 RPM
- Gear Ratio: 18/77
- Strokes Per Minute: 55 SPM
- Header Slide Stroke: 9″
- Die Opening: 3 1/2″
- Stock Gather: 6″
- Hold-On: 2 1/2″
- Die Height: 14″
- Die Thickness: 6″
- Die Seat Length: 13″
- Tool and Die Space (max.): 28 1/2″
- Flywheel Diameter: 41″
- Clutch: 21″ – 4 Plate
- Journal Clearances: .008 – .010″
- Header Slide Clearances:
- Body: .011 – ,013″
- Tail: .007 – .009″
- Die Slide Clearances:
- Body: .016 – .018″
- Tail: .011 – .013″
- Cam Slide Clearances:
- Body: .008 – .010″
