M2MB MQTT

This section describes the M2MB APIs to perform various MQTT client operations. More...

#define	M2MB_MQTT_MAX_SUBSCRIBE_TOPICS   32
enum	M2MB_MQTT_SUBSCRIBE_REASON_E {   M2MB_MQTT_SUBSCRIPTION_DENIED = 0,   M2MB_MQTT_SUBSCRIPTION_GRANTED,   M2MB_MQTT_SUBSCRIPTION_MSG }
	MQTT client subscribe reason. More...
enum	M2MB_MQTT_CONNECT_STATUS {   M2MB_MQTT_CONNECT_STATUS_UNKNOWN = -1,   M2MB_MQTT_CONNECT_STATUS_ACCEPTED = 0,   M2MB_MQTT_CONNECT_STATUS_REFUSED_PROTOCOL_VERSION = 1,   M2MB_MQTT_CONNECT_STATUS_REFUSED_IDENTIFIER = 2,   M2MB_MQTT_CONNECT_STATUS_REFUSED_SERVER = 3,   M2MB_MQTT_CONNECT_STATUS_REFUSED_USERNAME_PASS = 4,   M2MB_MQTT_CONNECT_STATUS_REFUSED_NOT_AUTHORIZED_ = 5,   M2MB_MQTT_CONNECT_STATUS_DISCONNECTED = 256,   M2MB_MQTT_CONNECT_STATUS_TIMEOUT = 257 }
typedef VOID *	M2MB_MQTT_CTXT_HANDLE
	MQTT context handle. This is obtained from m2mb_mqtt_open API and then used in subsequent MQTT APIs. More...
typedef enum M2MB_MQTT_SUBSCRIBE_REASON_E	M2MB_MQTT_SUBSCRIBE_REASON_E
	MQTT client subscribe reason. More...
typedef enum M2MB_MQTT_CONNECT_STATUS	M2MB_MQTT_CONNECT_STATUS_E
typedef VOID(*	M2MB_MQTT_CONNECT_CB_T) (M2MB_MQTT_CTXT_HANDLE handle, INT32 status)
	User registered callback for MQTT connection status, registered during m2mb_mqtt_connect call. More...
typedef VOID(*	M2MB_MQTT_MSG_HNDLR_CB_T) (M2MB_MQTT_CTXT_HANDLE handle, void *arg, INT32 reason, const UINT8 *topic, UINT16 topic_Length, const UINT8 *msg, UINT32 msg_Length, UINT32 QOS)
	User registered callback for incoming messages for subscribed topics. More...
typedef struct M2MB_MQTT_OPEN_PARAMS	M2MB_MQTT_OPEN_PARAMS_T
	MQTT client Open parameters. More...
typedef struct M2MB_MQTT_CONN_PARAMS	M2MB_MQTT_CONN_PARAMS_T
	MQTT connect parameters. More...
M2MB_STATUS_T	m2mb_mqtt_init (VOID)
	initializes MQTT module. More...
M2MB_STATUS_T	m2mb_mqtt_deinit (VOID)
	deinitializes MQTT module. More...
M2MB_STATUS_T	m2mb_mqtt_open (M2MB_MQTT_CTXT_HANDLE *handle, M2MB_MQTT_OPEN_PARAMS_T *p_open_params)
	Creates MQTT instance for the MQTT client. More...
M2MB_STATUS_T	m2mb_mqtt_close (M2MB_MQTT_CTXT_HANDLE mqtt_handle)
	closes MQTT instance. More...
M2MB_STATUS_T	m2mb_mqtt_connect (M2MB_MQTT_CTXT_HANDLE mqtt_handle, M2MB_MQTT_CONN_PARAMS_T *p_conn_params)
	performs MQTT connection to the server. More...
M2MB_STATUS_T	m2mb_mqtt_disconnect (M2MB_MQTT_CTXT_HANDLE mqtt_handle)
	Disconnect from the server(broker). More...
M2MB_STATUS_T	m2mb_mqtt_publish (M2MB_MQTT_CTXT_HANDLE mqtt_handle, INT32 qos, INT32 retain, UINT16 message_id, const UINT8 *topic, const UINT8 *data, INT32 data_len)
	Publishes a message on a given topic. More...
M2MB_STATUS_T	m2mb_mqtt_subscribe (M2MB_MQTT_CTXT_HANDLE mqtt_handle, UINT16 msg_id, const UINT8 *topic, INT32 qos, M2MB_MQTT_MSG_HNDLR_CB_T cbk, VOID *cbk_arg)
	m2mb_mqtt_subscribe is called to Subscribe. More...
M2MB_STATUS_T	m2mb_mqtt_unsubscribe (M2MB_MQTT_CTXT_HANDLE mqtt_handle, UINT16 msg_id, const UINT8 *topic)
	unsubscribe to a perticular topic. More...

Detailed Description

This section describes the M2MB APIs to perform various MQTT client operations.

MQTT

Macro Definition Documentation

M2MB_MQTT_MAX_SUBSCRIBE_TOPICS

#define M2MB_MQTT_MAX_SUBSCRIBE_TOPICS   32

Maximum number of topics can be subsribed per connection

Definition at line 66 of file m2mb_mqtt.h.

Typedef Documentation

M2MB_MQTT_CONN_PARAMS_T

typedef struct M2MB_MQTT_CONN_PARAMS M2MB_MQTT_CONN_PARAMS_T

MQTT connect parameters.

MQTT client connect parameters used in m2mb_mqtt_connect API.

M2MB_MQTT_CONNECT_CB_T

typedef VOID(* M2MB_MQTT_CONNECT_CB_T) (M2MB_MQTT_CTXT_HANDLE handle, INT32 status)

User registered callback for MQTT connection status, registered during m2mb_mqtt_connect call.

This callback function is called to notify the user about the connection request status. This callback function is called to notify the user if the connection status changes(asynchronous disconnect) after connection done. m2mb_mqtt_connect API is non blocking API, so after m2mb_mqtt_connect call returns success, user has to wait till the connect callback gets called to do further operations on perticular MQTT client.

Parameters

[out]	handle	Argument provided to the user during m2mb_mqtt_open()
[out]	status	Connection status, status values are explained in m2mb_net_status.h file

Example

void m2m_mqtt_connect_callback(       M2MB_MQTT_CTXT_HANDLE handle, INT32 status)
    {
      if(status == M2MB_NET_STATUS_MQTTC_CONNECT_SUCCEEDED)
              //connection success, here onwards user can do subscribe and publish.
      else
              //connection failed(status values are described in m2mb_net_status.h file
      return;
    }

Definition at line 140 of file m2mb_mqtt.h.

M2MB_MQTT_CONNECT_STATUS_E

typedef enum M2MB_MQTT_CONNECT_STATUS M2MB_MQTT_CONNECT_STATUS_E

Connection status codes

M2MB_MQTT_CTXT_HANDLE

typedef VOID* M2MB_MQTT_CTXT_HANDLE

MQTT context handle.
This is obtained from m2mb_mqtt_open API and then used in subsequent MQTT APIs.

Definition at line 70 of file m2mb_mqtt.h.

M2MB_MQTT_MSG_HNDLR_CB_T

typedef VOID(* M2MB_MQTT_MSG_HNDLR_CB_T) (M2MB_MQTT_CTXT_HANDLE handle, void *arg, INT32 reason, const UINT8 *topic, UINT16 topic_Length, const UINT8 *msg, UINT32 msg_Length, UINT32 QOS)

User registered callback for incoming messages for subscribed topics.

This callback function is called to notify user about the incoming messages.

Parameters

[out]	handle	Argument provided to the user during m2mb_mqtt_open()
[out]	arg	user provided subscribe call back arguments.
[out]	reason	reason of incoming topic(M2MB_MQTT_SUBSCRIBE_REASON_E)
[out]	topic	incoming topic name.
[out]	topic_Length	incoming topic length.
[out]	msg	incoming message.
[out]	msg_Length	incoming message length.
[out]	QoS	Granted QOS for this subscription when 'reason' is M2MB_MQTT_SUBSCRIPTION_GRANTED or QOS for 'msg' delivered by the broker when 'reason' is M2MB_MQTT_SUBSCRIPTION_MSG.

Example

VOID m2m_s2w_mqtt_message_handler_cbk (void *handle, void* arg, INT32 reason, const char* topic,
                                                          UINT16 topic_Length, const char* msg, UINT32 msg_Length, UINT32 QOS )
{
  //there is an incoming message
}

Definition at line 183 of file m2mb_mqtt.h.

M2MB_MQTT_OPEN_PARAMS_T

typedef struct M2MB_MQTT_OPEN_PARAMS M2MB_MQTT_OPEN_PARAMS_T

MQTT client Open parameters.

MQTT client open parameters used in m2mb_mqtt_open API.

M2MB_MQTT_SUBSCRIBE_REASON_E

typedef enum M2MB_MQTT_SUBSCRIBE_REASON_E M2MB_MQTT_SUBSCRIBE_REASON_E

MQTT client subscribe reason.

MQTT client subscribe reason for use in M2MB_MQTT_CONNECT_CB_T callback.

Enumeration Type Documentation

M2MB_MQTT_CONNECT_STATUS

enum M2MB_MQTT_CONNECT_STATUS

Connection status codes

Enumerator
M2MB_MQTT_CONNECT_STATUS_UNKNOWN	Accepted
M2MB_MQTT_CONNECT_STATUS_ACCEPTED	Accepted
M2MB_MQTT_CONNECT_STATUS_REFUSED_PROTOCOL_VERSION	Refused protocol version
M2MB_MQTT_CONNECT_STATUS_REFUSED_IDENTIFIER	Refused identifier
M2MB_MQTT_CONNECT_STATUS_REFUSED_SERVER	Refused server
M2MB_MQTT_CONNECT_STATUS_REFUSED_USERNAME_PASS	Refused user credentials
M2MB_MQTT_CONNECT_STATUS_REFUSED_NOT_AUTHORIZED_	Refused not authorized
M2MB_MQTT_CONNECT_STATUS_DISCONNECTED	Disconnected
M2MB_MQTT_CONNECT_STATUS_TIMEOUT	Timeout

Definition at line 88 of file m2mb_mqtt.h.

M2MB_MQTT_SUBSCRIBE_REASON_E

enum M2MB_MQTT_SUBSCRIBE_REASON_E

MQTT client subscribe reason.

MQTT client subscribe reason for use in M2MB_MQTT_CONNECT_CB_T callback.

Enumerator
M2MB_MQTT_SUBSCRIPTION_DENIED	Subscription is denied by the broker.
M2MB_MQTT_SUBSCRIPTION_GRANTED	subscription is granted by the broker.
M2MB_MQTT_SUBSCRIPTION_MSG	Application message is received from the broker

Definition at line 79 of file m2mb_mqtt.h.

Function Documentation

m2mb_mqtt_close()

M2MB_STATUS_T m2mb_mqtt_close

(

M2MB_MQTT_CTXT_HANDLE

mqtt_handle

)

closes MQTT instance.

m2mb_mqtt_close frees all resources allocated by m2mb_mqtt_open.

Parameters

[in]

mqtt_handle

mqtt handle obtained from m2mb_mqtt_open API.

Returns

On success, M2MB_OK is returned. On error, non zero error code is returned.

Note

Example

      typedef struct M2M_S2W_MQTT_S
    {
        M2MB_MQTT_CTXT_HANDLE handle;
      UINT8 use_ssl;
      M2M_S2W_MQTT_MESSAGE_T *msg_ptr_head;
      M2M_S2W_MQTT_MESSAGE_T *msg_ptr_tail;
      M2MB_SSL_CTXT_HANDLE pM2mbSslHandle;
    }M2M_S2W_MQTT_T;
    void m2m_mqtt_connect_callback(   M2MB_MQTT_CTXT_HANDLE handle, INT32 status)
    {
      if(status == M2MB_NET_STATUS_MQTTC_CONNECT_SUCCEEDED)
              //connection success, here onwards user can do subscribe and publish.
      else
              //connection failed(status values are described in m2mb_net_status.h file
      return;
    }
void main(void)
    {
      M2MB_MQTT_OPEN_PARAMS_T open_params = {0};
      M2MB_MQTT_CONN_PARAMS_T connect_params = {0};
      INT8*   HOST = "192.168.1.120";
      INT32   PORT = 1883;
      INT8*   client_id = "mqttclient";
      INT8*   username = "username";
      INT8*   password = "password";
      UINT32  keepalive_in_sec = 180;
      UINT32  timeout_in_sec = 175;
      M2M_S2W_MQTT_T *pS2wMqttHandle = NULL;
      INT32 api_ret_code;
      VOID* pCid = NULL;
      char *cert_file = NULL;

      pS2wMqttHandle = (M2M_S2W_MQTT_T *)MALLOC(sizeof(M2M_S2W_MQTT_T));
      memset(pS2wMqttHandle, 0, sizeof(M2M_S2W_MQTT_T));
      pS2wMqttHandle->use_ssl = 1;

      if (M2MB_OK != m2mb_mqtt_init())
      {
              return M2MB_ERROR;
      }

      open_params.client_id = client_id;
      open_params.keepalive_in_sec = keepalive_in_sec;
      open_params.username = username;
      open_params.password = password;
      open_params.timeout_in_sec = timeout_in_sec;

      if(pS2wMqttHandle->use_ssl == TRUE)
      {
              M2MB_SSL_OPEN_PARAMS_T params = {0};
              params.role = M2MB_SSL_SSL_ROLE_CLIENT_E;
              M2MB_STATUS_T ret_status =      m2mb_ssl_open(&pS2wMqttHandle->pM2mbSslHandle, params );
              if( (ret_status != M2MB_OK) || (pS2wMqttHandle->pM2mbSslHandle == NULL))
              {
                      FREE(pS2wMqttHandle);
                      return M2MB_ERROR;
              }
              open_params.pSslCfg = pS2wMqttHandle->pM2mbSslHandle;
      }

      if (M2MB_OK != m2mb_mqtt_open(&s2w_mqtt_handle->handle, &open_params)
      {
              return M2MB_ERROR;
      }
      connect_params.host = HOST;
      connect_params.port = PORT;
      connect_params.connectcb = m2m_mqtt_connect_callback;
      connect_params.connectcb_args = pCid;

      api_ret_code = m2mb_mqtt_connect(s2w_mqtt_handle->handle, &connect_params);
      if(api_ret_code != M2MB_OK)
      {
              return M2MB_ERROR;
      }
      if((pS2wMqttHandle->handle != NULL) && ( M2MB_OK != m2mb_mqtt_disconnect(pS2wMqttHandle->handle) ))
      {
              return M2MB_ERROR;
      }

      if(pS2wMqttHandle->use_ssl == 1)
      {
              if(pS2wMqttHandle->pM2mbSslHandle)
                      m2mb_ssl_close(pS2wMqttHandle->pM2mbSslHandle);
      }
      if((pS2wMqttHandle->handle != NULL) && ( M2MB_OK != m2mb_mqtt_close(pS2wMqttHandle->handle) ))
      {
              return M2MB_ERROR;
      }
    }

m2mb_mqtt_connect()

M2MB_STATUS_T m2mb_mqtt_connect	(	M2MB_MQTT_CTXT_HANDLE	mqtt_handle,
		M2MB_MQTT_CONN_PARAMS_T *	p_conn_params
	)

performs MQTT connection to the server.

m2mb_mqtt_connect API connects to the server.

Parameters

[in]	mqtt_handle	mqtt handle obtained from m2mb_mqtt_open API.
[in]	p_conn_params	pointer to connection parameters of type M2MB_MQTT_CONN_PARAMS_T.

Returns

On success, M2MB_OK is returned. On error, non zero error code is returned.

Note

Example

      typedef struct M2M_S2W_MQTT_S
    {
        M2MB_MQTT_CTXT_HANDLE handle;
      UINT8 use_ssl;
      M2M_S2W_MQTT_MESSAGE_T *msg_ptr_head;
      M2M_S2W_MQTT_MESSAGE_T *msg_ptr_tail;
      M2MB_SSL_CTXT_HANDLE pM2mbSslHandle;
    }M2M_S2W_MQTT_T;
    void m2m_mqtt_connect_callback(   M2MB_MQTT_CTXT_HANDLE handle, INT32 status)
    {
      if(status == M2MB_NET_STATUS_MQTTC_CONNECT_SUCCEEDED)
              //connection success, here onwards user can do subscribe and publish.
      else
              //connection failed(status values are described in m2mb_net_status.h file
      return;
    }
void main(void)
    {
      M2MB_MQTT_OPEN_PARAMS_T open_params = {0};
      M2MB_MQTT_CONN_PARAMS_T connect_params = {0};
      INT8*   HOST = "192.168.1.120";
      INT32   PORT = 1883;
      INT8*   client_id = "mqttclient";
      INT8*   username = "username";
      INT8*   password = "password";
      UINT32  keepalive_in_sec = 180;
      UINT32  timeout_in_sec = 175;
      M2M_S2W_MQTT_T *pS2wMqttHandle = NULL;
      INT32 api_ret_code;
      VOID* pCid = NULL;
      char *cert_file = NULL;

      pS2wMqttHandle = (M2M_S2W_MQTT_T *)MALLOC(sizeof(M2M_S2W_MQTT_T));
      memset(pS2wMqttHandle, 0, sizeof(M2M_S2W_MQTT_T));
      pS2wMqttHandle->use_ssl = 1;

      if (M2MB_OK != m2mb_mqtt_init())
      {
              return M2MB_ERROR;
      }

      open_params.client_id = client_id;
      open_params.keepalive_in_sec = keepalive_in_sec;
      open_params.username = username;
      open_params.password = password;
      open_params.timeout_in_sec = timeout_in_sec;

      if(pS2wMqttHandle->use_ssl == TRUE)
      {
              M2MB_SSL_OPEN_PARAMS_T params = {0};
              params.role = M2MB_SSL_SSL_ROLE_CLIENT_E;
              M2MB_STATUS_T ret_status =      m2mb_ssl_open(&pS2wMqttHandle->pM2mbSslHandle, params );
              if( (ret_status != M2MB_OK) || (pS2wMqttHandle->pM2mbSslHandle == NULL))
              {
                      FREE(pS2wMqttHandle);
                      return M2MB_ERROR;
              }
              open_params.pSslCfg = pS2wMqttHandle->pM2mbSslHandle;
      }

      if (M2MB_OK != m2mb_mqtt_open(&s2w_mqtt_handle->handle, &open_params)
      {
              return M2MB_ERROR;
      }
      connect_params.host = HOST;
      connect_params.port = PORT;
      connect_params.connectcb = m2m_mqtt_connect_callback;
      connect_params.connectcb_args = pCid;

      api_ret_code = m2mb_mqtt_connect(s2w_mqtt_handle->handle, &connect_params);
      if(api_ret_code != M2MB_OK)
      {
              return M2MB_ERROR;
      }
    }

m2mb_mqtt_deinit()

M2MB_STATUS_T m2mb_mqtt_deinit

(

VOID

)

deinitializes MQTT module.

deintializes mqtt module and frees all resources allocated by m2mb_mqtt_init API.

Returns

returns M2MB_OK on success, M2MB_ERROR on error.

Note

this is the last API to call after finishing all MQTT operations. Example

typedef struct M2M_S2W_MQTT_S
{
  M2MB_MQTT_CTXT_HANDLE handle;
  UINT8 use_ssl;
  M2M_S2W_MQTT_MESSAGE_T *msg_ptr_head;
  M2M_S2W_MQTT_MESSAGE_T *msg_ptr_tail;
  M2MB_SSL_CTXT_HANDLE pM2mbSslHandle;
}M2M_S2W_MQTT_T;
void m2m_mqtt_connect_callback( M2MB_MQTT_CTXT_HANDLE handle, INT32 status)
{
  if(status == M2MB_NET_STATUS_MQTTC_CONNECT_SUCCEEDED)
          //connection success, here onwards user can do subscribe and publish.
  else
          //connection failed(status values are described in m2mb_net_status.h file
  return;
}
void main(void)
{
  M2MB_MQTT_OPEN_PARAMS_T open_params = {0};
  M2MB_MQTT_CONN_PARAMS_T connect_params = {0};
  INT8*   HOST = "192.168.1.120";
  INT32   PORT = 1883;
  INT8*   client_id = "mqttclient";
  INT8*   username = "username";
  INT8*   password = "password";
  UINT32  keepalive_in_sec = 180;
  UINT32  timeout_in_sec = 175;
  M2M_S2W_MQTT_T *pS2wMqttHandle = NULL;
  INT32 api_ret_code;
  VOID* pCid = NULL;
  char *cert_file = NULL;

  pS2wMqttHandle = (M2M_S2W_MQTT_T *)MALLOC(sizeof(M2M_S2W_MQTT_T));
  memset(pS2wMqttHandle, 0, sizeof(M2M_S2W_MQTT_T));
  pS2wMqttHandle->use_ssl = 1;

  if (M2MB_OK != m2mb_mqtt_init())
  {
          return M2MB_ERROR;
  }

  open_params.client_id = client_id;
  open_params.keepalive_in_sec = keepalive_in_sec;
  open_params.username = username;
  open_params.password = password;
  open_params.timeout_in_sec = timeout_in_sec;

  if(pS2wMqttHandle->use_ssl == TRUE)
  {
          M2MB_SSL_OPEN_PARAMS_T params = {0};
          params.role = M2MB_SSL_SSL_ROLE_CLIENT_E;
          M2MB_STATUS_T ret_status =      m2mb_ssl_open(&pS2wMqttHandle->pM2mbSslHandle, params );
          if( (ret_status != M2MB_OK) || (pS2wMqttHandle->pM2mbSslHandle == NULL))
          {
                  FREE(pS2wMqttHandle);
                  return M2MB_ERROR;
          }
          open_params.pSslCfg = pS2wMqttHandle->pM2mbSslHandle;
  }

  if (M2MB_OK != m2mb_mqtt_open(&s2w_mqtt_handle->handle, &open_params)
  {
          return M2MB_ERROR;
  }
  connect_params.host = HOST;
  connect_params.port = PORT;
  connect_params.connectcb = m2m_mqtt_connect_callback;
  connect_params.connectcb_args = pCid;

  api_ret_code = m2mb_mqtt_connect(s2w_mqtt_handle->handle, &connect_params);
  if(api_ret_code != M2MB_OK)
  {
          return M2MB_ERROR;
  }
  if((pS2wMqttHandle->handle != NULL) && ( M2MB_OK != m2mb_mqtt_disconnect(pS2wMqttHandle->handle) ))
  {
          return M2MB_ERROR;
  }

  if(pS2wMqttHandle->use_ssl == 1)
  {
          if(pS2wMqttHandle->pM2mbSslHandle)
                  m2mb_ssl_close(pS2wMqttHandle->pM2mbSslHandle);
  }
  if((pS2wMqttHandle->handle != NULL) && ( M2MB_OK != m2mb_mqtt_close(pS2wMqttHandle->handle) ))
  {
          return M2MB_ERROR;
  }
  if (M2MB_OK != m2mb_mqtt_deinit())
  {
          return M2MB_ERROR;
  }
}

m2mb_mqtt_disconnect()

M2MB_STATUS_T m2mb_mqtt_disconnect

(

M2MB_MQTT_CTXT_HANDLE

mqtt_handle

)

Disconnect from the server(broker).

m2mb_mqtt_disconnect API sends disconnect packet to the broker.

Parameters

[in]

mqtt_handle

mqtt handle obtained from m2mb_mqtt_open API.

Returns

On success, M2MB_OK is returned. On error, non zero error code is returned.

Note

Example

      typedef struct M2M_S2W_MQTT_S
    {
        M2MB_MQTT_CTXT_HANDLE handle;
      UINT8 use_ssl;
      M2M_S2W_MQTT_MESSAGE_T *msg_ptr_head;
      M2M_S2W_MQTT_MESSAGE_T *msg_ptr_tail;
      M2MB_SSL_CTXT_HANDLE pM2mbSslHandle;
    }M2M_S2W_MQTT_T;
    void m2m_mqtt_connect_callback(   M2MB_MQTT_CTXT_HANDLE handle, INT32 status)
    {
      if(status == M2MB_NET_STATUS_MQTTC_CONNECT_SUCCEEDED)
              //connection success, here onwards user can do subscribe and publish.
      else
              //connection failed(status values are described in m2mb_net_status.h file
      return;
    }
void main(void)
    {
      M2MB_MQTT_OPEN_PARAMS_T open_params = {0};
      M2MB_MQTT_CONN_PARAMS_T connect_params = {0};
      INT8*   HOST = "192.168.1.120";
      INT32   PORT = 1883;
      INT8*   client_id = "mqttclient";
      INT8*   username = "username";
      INT8*   password = "password";
      UINT32  keepalive_in_sec = 180;
      UINT32  timeout_in_sec = 175;
      M2M_S2W_MQTT_T *pS2wMqttHandle = NULL;
      INT32 api_ret_code;
      VOID* pCid = NULL;
      char *cert_file = NULL;

      pS2wMqttHandle = (M2M_S2W_MQTT_T *)MALLOC(sizeof(M2M_S2W_MQTT_T));
      memset(pS2wMqttHandle, 0, sizeof(M2M_S2W_MQTT_T));
      pS2wMqttHandle->use_ssl = 1;

      if (M2MB_OK != m2mb_mqtt_init())
      {
              return M2MB_ERROR;
      }

      open_params.client_id = client_id;
      open_params.keepalive_in_sec = keepalive_in_sec;
      open_params.username = username;
      open_params.password = password;
      open_params.timeout_in_sec = timeout_in_sec;

      if(pS2wMqttHandle->use_ssl == TRUE)
      {
              M2MB_SSL_OPEN_PARAMS_T params = {0};
              params.role = M2MB_SSL_SSL_ROLE_CLIENT_E;
              M2MB_STATUS_T ret_status =      m2mb_ssl_open(&pS2wMqttHandle->pM2mbSslHandle, params );
              if( (ret_status != M2MB_OK) || (pS2wMqttHandle->pM2mbSslHandle == NULL))
              {
                      FREE(pS2wMqttHandle);
                      return M2MB_ERROR;
              }
              open_params.pSslCfg = pS2wMqttHandle->pM2mbSslHandle;
      }

      if (M2MB_OK != m2mb_mqtt_open(&s2w_mqtt_handle->handle, &open_params)
      {
              return M2MB_ERROR;
      }
      connect_params.host = HOST;
      connect_params.port = PORT;
      connect_params.connectcb = m2m_mqtt_connect_callback;
      connect_params.connectcb_args = pCid;

      api_ret_code = m2mb_mqtt_connect(s2w_mqtt_handle->handle, &connect_params);
      if(api_ret_code != M2MB_OK)
      {
              return M2MB_ERROR;
      }
      if((pS2wMqttHandle->handle != NULL) && ( M2MB_OK != m2mb_mqtt_disconnect(pS2wMqttHandle->handle) ))
      {
              return M2MB_ERROR;
      }

      if(pS2wMqttHandle->use_ssl == 1)
      {
              if(pS2wMqttHandle->pM2mbSslHandle)
                      m2mb_ssl_close(pS2wMqttHandle->pM2mbSslHandle);
      }
      if((pS2wMqttHandle->handle != NULL) && ( M2MB_OK != m2mb_mqtt_close(pS2wMqttHandle->handle) ))
      {
              return M2MB_ERROR;
      }
    }

m2mb_mqtt_init()

M2MB_STATUS_T m2mb_mqtt_init

(

VOID

)

initializes MQTT module.

m2mb_mqtt_init intializes mqtt module resources required for MQTT.

Returns

returns M2MB_OK on success, M2MB_ERROR on error.

Note

this is the first API to call before calling any other MQTT APIs, this is one time call.

Example

typedef struct M2M_S2W_MQTT_S
{
  M2MB_MQTT_CTXT_HANDLE handle;
  UINT8 use_ssl;
  M2M_S2W_MQTT_MESSAGE_T *msg_ptr_head;
  M2M_S2W_MQTT_MESSAGE_T *msg_ptr_tail;
  M2MB_SSL_CTXT_HANDLE pM2mbSslHandle;
}M2M_S2W_MQTT_T;
void m2m_mqtt_connect_callback( M2MB_MQTT_CTXT_HANDLE handle, INT32 status)
{
  if(status == M2MB_NET_STATUS_MQTTC_CONNECT_SUCCEEDED)
          //connection success, here onwards user can do subscribe and publish.
  else
          //connection failed(status values are described in m2mb_net_status.h file
  return;
}
void main(void)
{
  M2MB_MQTT_OPEN_PARAMS_T open_params = {0};
  M2MB_MQTT_CONN_PARAMS_T connect_params = {0};
  INT8*   HOST = "192.168.1.120";
  INT32   PORT = 1883;
  INT8*   client_id = "mqttclient";
  INT8*   username = "username";
  INT8*   password = "password";
  UINT32  keepalive_in_sec = 180;
  UINT32  timeout_in_sec = 175;
  M2M_S2W_MQTT_T *pS2wMqttHandle = NULL;
  INT32 api_ret_code;
  VOID* pCid = NULL;
  char *cert_file = NULL;

  pS2wMqttHandle = (M2M_S2W_MQTT_T *)MALLOC(sizeof(M2M_S2W_MQTT_T));
  memset(pS2wMqttHandle, 0, sizeof(M2M_S2W_MQTT_T));
  pS2wMqttHandle->use_ssl = 1;

  if (M2MB_OK != m2mb_mqtt_init())
  {
          return M2MB_ERROR;
  }

  open_params.client_id = client_id;
  open_params.keepalive_in_sec = keepalive_in_sec;
  open_params.username = username;
  open_params.password = password;
  open_params.timeout_in_sec = timeout_in_sec;

  if(pS2wMqttHandle->use_ssl == TRUE)
  {
          M2MB_SSL_OPEN_PARAMS_T params = {0};
          params.role = M2MB_SSL_SSL_ROLE_CLIENT_E;
          M2MB_STATUS_T ret_status =      m2mb_ssl_open(&pS2wMqttHandle->pM2mbSslHandle, params );
          if( (ret_status != M2MB_OK) || (pS2wMqttHandle->pM2mbSslHandle == NULL))
          {
                  FREE(pS2wMqttHandle);
                  return M2MB_ERROR;
          }
          open_params.pSslCfg = pS2wMqttHandle->pM2mbSslHandle;
  }

  if (M2MB_OK != m2mb_mqtt_open(&s2w_mqtt_handle->handle, &open_params)
  {
          return M2MB_ERROR;
  }
  connect_params.host = HOST;
  connect_params.port = PORT;
  connect_params.connectcb = m2m_mqtt_connect_callback;
  connect_params.connectcb_args = pCid;

  api_ret_code = m2mb_mqtt_connect(s2w_mqtt_handle->handle, &connect_params);
  if(api_ret_code != M2MB_OK)
  {
          return M2MB_ERROR;
  }
  if((pS2wMqttHandle->handle != NULL) && ( M2MB_OK != m2mb_mqtt_disconnect(pS2wMqttHandle->handle) ))
  {
          return M2MB_ERROR;
  }

  if(pS2wMqttHandle->use_ssl == 1)
  {
          if(pS2wMqttHandle->pM2mbSslHandle)
                  m2mb_ssl_close(pS2wMqttHandle->pM2mbSslHandle);
  }
  if((pS2wMqttHandle->handle != NULL) && ( M2MB_OK != m2mb_mqtt_close(pS2wMqttHandle->handle) ))
  {
          return M2MB_ERROR;
  }
  if (M2MB_OK != m2mb_mqtt_deinit())
  {
          return M2MB_ERROR;
  }
}

m2mb_mqtt_open()

M2MB_STATUS_T m2mb_mqtt_open	(	M2MB_MQTT_CTXT_HANDLE *	handle,
		M2MB_MQTT_OPEN_PARAMS_T *	p_open_params
	)

Creates MQTT instance for the MQTT client.

m2mb_mqtt_open creates a new MQTT client instance.

Parameters

[out]	mqtt_handle	mqtt handle for a new MQTT client instance.
[in]	p_open_params	pointer to open parameters of type M2MB_MQTT_OPEN_PARAMS_T.

Returns

On success, M2MB_OK is returned. On error, non zero error code is returned.

Note

Example

typedef struct M2M_S2W_MQTT_S
{
  M2MB_MQTT_CTXT_HANDLE handle;
  UINT8 use_ssl;
  M2M_S2W_MQTT_MESSAGE_T *msg_ptr_head;
  M2M_S2W_MQTT_MESSAGE_T *msg_ptr_tail;
  M2MB_SSL_CTXT_HANDLE pM2mbSslHandle;
}M2M_S2W_MQTT_T;
void m2m_mqtt_connect_callback( M2MB_MQTT_CTXT_HANDLE handle, INT32 status)
{
  if(status == M2MB_NET_STATUS_MQTTC_CONNECT_SUCCEEDED)
          //connection success, here onwards user can do subscribe and publish.
  else
          //connection failed(status values are described in m2mb_net_status.h file
  return;
}
void main(void)
{
  M2MB_MQTT_OPEN_PARAMS_T open_params = {0};
  M2MB_MQTT_CONN_PARAMS_T connect_params = {0};
  INT8*   HOST = "192.168.1.120";
  INT32   PORT = 1883;
  INT8*   client_id = "mqttclient";
  INT8*   username = "username";
  INT8*   password = "password";
  UINT32  keepalive_in_sec = 180;
  UINT32  timeout_in_sec = 175;
  M2M_S2W_MQTT_T *pS2wMqttHandle = NULL;
  INT32 api_ret_code;
  VOID* pCid = NULL;
  char *cert_file = NULL;

  pS2wMqttHandle = (M2M_S2W_MQTT_T *)MALLOC(sizeof(M2M_S2W_MQTT_T));
  memset(pS2wMqttHandle, 0, sizeof(M2M_S2W_MQTT_T));
  pS2wMqttHandle->use_ssl = 1;

  if (M2MB_OK != m2mb_mqtt_init())
  {
          return M2MB_ERROR;
  }

  open_params.client_id = client_id;
  open_params.keepalive_in_sec = keepalive_in_sec;
  open_params.username = username;
  open_params.password = password;
  open_params.timeout_in_sec = timeout_in_sec;

  if(pS2wMqttHandle->use_ssl == TRUE)
  {
          M2MB_SSL_OPEN_PARAMS_T params = {0};
          params.role = M2MB_SSL_SSL_ROLE_CLIENT_E;
          M2MB_STATUS_T ret_status =      m2mb_ssl_open(&pS2wMqttHandle->pM2mbSslHandle, params );
          if( (ret_status != M2MB_OK) || (pS2wMqttHandle->pM2mbSslHandle == NULL))
          {
                  FREE(pS2wMqttHandle);
                  return M2MB_ERROR;
          }
          open_params.pSslCfg = pS2wMqttHandle->pM2mbSslHandle;
  }

  if (M2MB_OK != m2mb_mqtt_open(&s2w_mqtt_handle->handle, &open_params)
  {
          return M2MB_ERROR;
  }
  connect_params.host = HOST;
  connect_params.port = PORT;
  connect_params.connectcb = m2m_mqtt_connect_callback;
  connect_params.connectcb_args = pCid;

  api_ret_code = m2mb_mqtt_connect(s2w_mqtt_handle->handle, &connect_params);
  if(api_ret_code != M2MB_OK)
  {
          return M2MB_ERROR;
  }
}

m2mb_mqtt_publish()

M2MB_STATUS_T m2mb_mqtt_publish	(	M2MB_MQTT_CTXT_HANDLE	mqtt_handle,
		INT32	qos,
		INT32	retain,
		UINT16	message_id,
		const UINT8 *	topic,
		const UINT8 *	data,
		INT32	data_len
	)

Publishes a message on a given topic.

m2mb_mqtt_publish Publishes a message on a given topic.

Parameters

[out]	mqtt_handle	mqtt handle obtained from m2mb_mqtt_open API.
[in]	qos	Integer value 0, 1, or 2 indicating the QOS to be used for msg.
[in]	retain	Set to TRUE to make the message retained.
[in]	message_id	Message ID
[in]	topic	Topic name
[in]	data	Data to publish
[in]	data_len	Data length.

Returns

On success, M2MB_OK is returned. On error, non zero error code is returned.

Note

Example

      typedef struct M2M_S2W_MQTT_S
    {
        M2MB_MQTT_CTXT_HANDLE handle;
      UINT8 use_ssl;
      M2M_S2W_MQTT_MESSAGE_T *msg_ptr_head;
      M2M_S2W_MQTT_MESSAGE_T *msg_ptr_tail;
      M2MB_SSL_CTXT_HANDLE pM2mbSslHandle;
    }M2M_S2W_MQTT_T;
    void m2m_mqtt_connect_callback(   M2MB_MQTT_CTXT_HANDLE handle, INT32 status)
    {
      if(status == M2MB_NET_STATUS_MQTTC_CONNECT_SUCCEEDED)
              //connection success, here onwards user can do subscribe and publish.
      else
              //connection failed(status values are described in m2mb_net_status.h file
      return;
    }
void main(void)
    {
      M2MB_MQTT_OPEN_PARAMS_T open_params = {0};
      M2MB_MQTT_CONN_PARAMS_T connect_params = {0};
      INT8*   HOST = "192.168.1.120";
      INT32   PORT = 1883;
      INT8*   client_id = "mqttclient";
      INT8*   username = "username";
      INT8*   password = "password";
      UINT32  keepalive_in_sec = 180;
      UINT32  timeout_in_sec = 175;
      M2M_S2W_MQTT_T *pS2wMqttHandle = NULL;
      INT32 api_ret_code;
      VOID* pCid = NULL;
      char *cert_file = NULL;

      pS2wMqttHandle = (M2M_S2W_MQTT_T *)MALLOC(sizeof(M2M_S2W_MQTT_T));
      memset(pS2wMqttHandle, 0, sizeof(M2M_S2W_MQTT_T));
      pS2wMqttHandle->use_ssl = 1;

      if (M2MB_OK != m2mb_mqtt_init())
      {
              return M2MB_ERROR;
      }

      open_params.client_id = client_id;
      open_params.keepalive_in_sec = keepalive_in_sec;
      open_params.username = username;
      open_params.password = password;
      open_params.timeout_in_sec = timeout_in_sec;

      if(pS2wMqttHandle->use_ssl == TRUE)
      {
              M2MB_SSL_OPEN_PARAMS_T params = {0};
              params.role = M2MB_SSL_SSL_ROLE_CLIENT_E;
              M2MB_STATUS_T ret_status =      m2mb_ssl_open(&pS2wMqttHandle->pM2mbSslHandle, params );
              if( (ret_status != M2MB_OK) || (pS2wMqttHandle->pM2mbSslHandle == NULL))
              {
                      FREE(pS2wMqttHandle);
                      return M2MB_ERROR;
              }
              open_params.pSslCfg = pS2wMqttHandle->pM2mbSslHandle;
      }

      if (M2MB_OK != m2mb_mqtt_open(&s2w_mqtt_handle->handle, &open_params)
      {
              return M2MB_ERROR;
      }
      connect_params.host = HOST;
      connect_params.port = PORT;
      connect_params.connectcb = m2m_mqtt_connect_callback;
      connect_params.connectcb_args = pCid;

      api_ret_code = m2mb_mqtt_connect(s2w_mqtt_handle->handle, &connect_params);
      if(api_ret_code != M2MB_OK)
      {
              return M2MB_ERROR;
      }
      if((pS2wMqttHandle->handle != NULL) && ( M2MB_OK != m2mb_mqtt_disconnect(pS2wMqttHandle->handle) ))
      {
              return M2MB_ERROR;
      }

      if(pS2wMqttHandle->use_ssl == 1)
      {
              if(pS2wMqttHandle->pM2mbSslHandle)
                      m2mb_ssl_close(pS2wMqttHandle->pM2mbSslHandle);
      }
      if((pS2wMqttHandle->handle != NULL) && ( M2MB_OK != m2mb_mqtt_close(pS2wMqttHandle->handle) ))
      {
              return M2MB_ERROR;
      }
      publish_st = ( UINT32 )m2mb_mqtt_publish(pS2wMqttHandle->handle, QOS, retainFlag, message_id, topic,
                                                      buf, data_tlen);
      if( M2MB_OK == publish_st)
              return M2MB_OK;
      else
              return M2MB_ERROR;
    }

m2mb_mqtt_subscribe()

M2MB_STATUS_T m2mb_mqtt_subscribe	(	M2MB_MQTT_CTXT_HANDLE	mqtt_handle,
		UINT16	msg_id,
		const UINT8 *	topic,
		INT32	qos,
		M2MB_MQTT_MSG_HNDLR_CB_T	cbk,
		VOID *	cbk_arg
	)

m2mb_mqtt_subscribe is called to Subscribe.

m2mb_mqtt_subscribe Subscribes to one topic.

Parameters

[out]	mqtt_handle	mqtt handle obtained from m2mb_mqtt_open API.
[in]	msg_id	message id
[in]	topic	topic name
[in]	qos	Integer value 0, 1, or 2 indicating the QOS to be used for msg.
[in]	cbk	User callback for incoming messages
[in]	cbk_arg	User callback arguments for incoming messages.

Returns

On success, M2MB_OK is returned. On error, non zero error code is returned.

Note

Example

VOID m2m_s2w_mqtt_message_handler_cbk (INT32 handle, void* arg, INT32 reason, const char* topic,
                                                       UINT16 topic_Length, const char* msg, UINT32 msg_Length, UINT32 QOS )
      {
       UINT32 data_len;
       M2M_S2W_MQTT_T * s2w_mqtt_handle_ptr = (M2M_S2W_MQTT_T *)arg;
       if(0 == s2w_mqtt_handle_ptr->receive_request_present)
       {
               return;
       }

       m2m_s2w_mqtt_message_set(s2w_mqtt_handle_ptr,
                                                       reason, topic,
                                                       topic_Length,
                                                       msg,
                                                       msg_Length,
                                                       QOS );
          data_len = MSG_TO_HOST_LEN(topic_Length, msg_Length);
       //indicate to the user.
      }
       typedef struct M2M_S2W_MQTT_S
      {
          M2MB_MQTT_CTXT_HANDLE handle;
       UINT8 use_ssl;
       M2M_S2W_MQTT_MESSAGE_T *msg_ptr_head;
       M2M_S2W_MQTT_MESSAGE_T *msg_ptr_tail;
       M2MB_SSL_CTXT_HANDLE pM2mbSslHandle;
      }M2M_S2W_MQTT_T;
      void m2m_mqtt_connect_callback(  M2MB_MQTT_CTXT_HANDLE handle, INT32 status)
      {
       if(status == M2MB_NET_STATUS_MQTTC_CONNECT_SUCCEEDED)
               //connection success, here onwards user can do subscribe and publish.
       else
               //connection failed(status values are described in m2mb_net_status.h file
       return;
      }
  void main(void)
      {
       M2MB_MQTT_OPEN_PARAMS_T open_params = {0};
       M2MB_MQTT_CONN_PARAMS_T connect_params = {0};
       INT8*   HOST = "192.168.1.120";
       INT32   PORT = 1883;
       INT8*   client_id = "mqttclient";
       INT8*   username = "username";
       INT8*   password = "password";
       UINT32  keepalive_in_sec = 180;
       UINT32  timeout_in_sec = 175;
       M2M_S2W_MQTT_T *pS2wMqttHandle = NULL;
       INT32 api_ret_code;
       VOID* pCid = NULL;
       char *cert_file = NULL;

       pS2wMqttHandle = (M2M_S2W_MQTT_T *)MALLOC(sizeof(M2M_S2W_MQTT_T));
       memset(pS2wMqttHandle, 0, sizeof(M2M_S2W_MQTT_T));
       pS2wMqttHandle->use_ssl = 1;

       if (M2MB_OK != m2mb_mqtt_init())
       {
               return M2MB_ERROR;
       }

       open_params.client_id = client_id;
       open_params.keepalive_in_sec = keepalive_in_sec;
       open_params.username = username;
       open_params.password = password;
       open_params.timeout_in_sec = timeout_in_sec;

       if(pS2wMqttHandle->use_ssl == TRUE)
       {
               M2MB_SSL_OPEN_PARAMS_T params = {0};
               params.role = M2MB_SSL_SSL_ROLE_CLIENT_E;
               M2MB_STATUS_T ret_status =      m2mb_ssl_open(&pS2wMqttHandle->pM2mbSslHandle, params );
               if( (ret_status != M2MB_OK) || (pS2wMqttHandle->pM2mbSslHandle == NULL))
               {
                       FREE(pS2wMqttHandle);
                       return M2MB_ERROR;
               }
               open_params.pSslCfg = pS2wMqttHandle->pM2mbSslHandle;
       }

       if (M2MB_OK != m2mb_mqtt_open(&s2w_mqtt_handle->handle, &open_params)
       {
               return M2MB_ERROR;
       }
       connect_params.host = HOST;
       connect_params.port = PORT;
       connect_params.connectcb = m2m_mqtt_connect_callback;
       connect_params.connectcb_args = pCid;

       api_ret_code = m2mb_mqtt_connect(s2w_mqtt_handle->handle, &connect_params);
       if(api_ret_code != M2MB_OK)
       {
               return M2MB_ERROR;
       }

       ret_val = m2mb_mqtt_subscribe(s2w_mqtt_handle->handle, message_id, topic, QOS, m2m_s2w_mqtt_message_handler_cbk, s2w_mqtt_handle);
       if(ret_val < 0)
       {
               return M2MB_ERROR;
       }
       m2mb_os_taskSleep(100);
      }

m2mb_mqtt_unsubscribe()

M2MB_STATUS_T m2mb_mqtt_unsubscribe	(	M2MB_MQTT_CTXT_HANDLE	mqtt_handle,
		UINT16	msg_id,
		const UINT8 *	topic
	)

unsubscribe to a perticular topic.

unsubscribe to a given topic.

Parameters

[out]	mqtt_handle	mqtt handle obtained from m2mb_mqtt_open API.
[in]	msg_id	message id
[in]	topic	topic name

Returns

On success, M2MB_OK is returned. On error, non zero error code is returned.

Note

Example

      VOID m2m_s2w_mqtt_message_handler_cbk (INT32 handle, void* arg, INT32 reason, const char* topic,
                                                          UINT16 topic_Length, const char* msg, UINT32 msg_Length, UINT32 QOS )
{
        UINT32 data_len;
        M2M_S2W_MQTT_T * s2w_mqtt_handle_ptr = (M2M_S2W_MQTT_T *)arg;
        if(0 == s2w_mqtt_handle_ptr->receive_request_present)
        {
          return;
        }

        m2m_s2w_mqtt_message_set(s2w_mqtt_handle_ptr,
                                                  reason, topic,
                                                  topic_Length,
                                                  msg,
                                                  msg_Length,
                                                  QOS );
        data_len = MSG_TO_HOST_LEN(topic_Length, msg_Length);
        //indicate to the user.
}
typedef struct M2M_S2W_MQTT_S
{
        M2MB_MQTT_CTXT_HANDLE handle;
        UINT8 use_ssl;
        M2M_S2W_MQTT_MESSAGE_T *msg_ptr_head;
        M2M_S2W_MQTT_MESSAGE_T *msg_ptr_tail;
        M2MB_SSL_CTXT_HANDLE pM2mbSslHandle;
}M2M_S2W_MQTT_T;
void m2m_mqtt_connect_callback( M2MB_MQTT_CTXT_HANDLE handle, INT32 status)
{
        if(status == M2MB_NET_STATUS_MQTTC_CONNECT_SUCCEEDED)
          //connection success, here onwards user can do subscribe and publish.
        else
          //connection failed(status values are described in m2mb_net_status.h file
        return;
}
void main(void)
{
        M2MB_MQTT_OPEN_PARAMS_T open_params = {0};
        M2MB_MQTT_CONN_PARAMS_T connect_params = {0};
        INT8*   HOST = "192.168.1.120";
        INT32   PORT = 1883;
        INT8*   client_id = "mqttclient";
        INT8*   username = "username";
        INT8*   password = "password";
        UINT32  keepalive_in_sec = 180;
        UINT32  timeout_in_sec = 175;
        M2M_S2W_MQTT_T *pS2wMqttHandle = NULL;
        INT32 api_ret_code;
        VOID* pCid = NULL;
        char *cert_file = NULL;

        pS2wMqttHandle = (M2M_S2W_MQTT_T *)MALLOC(sizeof(M2M_S2W_MQTT_T));
        memset(pS2wMqttHandle, 0, sizeof(M2M_S2W_MQTT_T));
        pS2wMqttHandle->use_ssl = 1;

        if (M2MB_OK != m2mb_mqtt_init())
        {
          return M2MB_ERROR;
        }

        open_params.client_id = client_id;
        open_params.keepalive_in_sec = keepalive_in_sec;
        open_params.username = username;
        open_params.password = password;
        open_params.timeout_in_sec = timeout_in_sec;

        if(pS2wMqttHandle->use_ssl == TRUE)
        {
          M2MB_SSL_OPEN_PARAMS_T params = {0};
          params.role = M2MB_SSL_SSL_ROLE_CLIENT_E;
          M2MB_STATUS_T ret_status =  m2mb_ssl_open(&pS2wMqttHandle->pM2mbSslHandle, params );
          if( (ret_status != M2MB_OK) || (pS2wMqttHandle->pM2mbSslHandle == NULL))
          {
                  FREE(pS2wMqttHandle);
                  return M2MB_ERROR;
          }
          open_params.pSslCfg = pS2wMqttHandle->pM2mbSslHandle;
        }

        if (M2MB_OK != m2mb_mqtt_open(&s2w_mqtt_handle->handle, &open_params)
        {
          return M2MB_ERROR;
        }
        connect_params.host = HOST;
        connect_params.port = PORT;
        connect_params.connectcb = m2m_mqtt_connect_callback;
        connect_params.connectcb_args = pCid;

        api_ret_code = m2mb_mqtt_connect(s2w_mqtt_handle->handle, &connect_params);
        if(api_ret_code != M2MB_OK)
        {
          return M2MB_ERROR;
        }

        ret_val = m2mb_mqtt_subscribe(s2w_mqtt_handle->handle, message_id, topic, QOS, m2m_s2w_mqtt_message_handler_cbk, s2w_mqtt_handle);
        if(ret_val < 0)
        {
          return M2MB_ERROR;
        }
        m2mb_os_taskSleep(100);
        ret_val = m2mb_mqtt_unsubscribe(s2w_mqtt_handle->handle, message_id, topic);
      if(ret_val < 0)
      {
        return M2MB_ERROR;
      }
}

      }
