Round Chrome Moly Steel Tubing (4130N)
Sold only in pre-cut lengths (4, 8, 12, or 17 ft.). Always check wall thickness tolerance before cutting or welding, especially if the
FDU LV WR EH FHUWL¿HG 7XELQJ ZDOO WKLFNQHVV ZLOO YDU\
Description 4' Length 8' Length 12' Length 17' Length
1/4" x .035" ALL22000-4 ALL22000-8 ALL22000-12 ALL22000-17
3/8" x .058" ALL22005-4 ALL22005-8 ALL22005-12 —
1/2" x .049" ALL22010-4 ALL22010-8 ALL22010-12 ALL22010-17
1/2" x .058" ALL22012-4 ALL22012-8 ALL22012-12 ALL22012-17
5/8" x .049" ALL22015-4 ALL22015-8 ALL22015-12 ALL22015-17
5/8" x .058" ALL22017-4 ALL22017-8 ALL22017-12 —
3/4" x .049" ALL22020-4 ALL22020-8 ALL22020-12 —
3/4" x .058" ALL22022-4 ALL22022-8 ALL22022-12 —
3/4" x .095" ALL22024-4 ALL22024-8 ALL22024-12 ALL22024-17
3/4" x .120" ALL22026-4 ALL22026-8 ALL22026-12 —
7/8" x .058" ALL22030-4 ALL22030-8 ALL22030-12 ALL22030-17
7/8" x .095" ALL22032-4 ALL22032-8 ALL22032-12 ALL22032-17
1" x .049" ALL22040-4 ALL22040-8 ALL22040-12 —
1" x .058" ALL22042-4 ALL22042-8 ALL22042-12 —
1" x .065" ALL22044-4 ALL22044-8 ALL22044-12 —
1" x .083" ALL22045-4 ALL22045-8 ALL22045-12 —
1" x .095" ALL22046-4 ALL22046-8 ALL22046-12 —
1-1/8" x .058 ALL22050-4 ALL22050-8 ALL22050-12 ALL22050-17
1-1/8" x .083" ALL22054-4 ALL22054-8 ALL22054-12 —
1-1/4" x .058" ALL22060-4 ALL22060-8 ALL22060-12 —
1-1/4" x .065" ALL22062-4 ALL22062-8 ALL22062-12 —
1-1/4 x .083" ALL22061-4 ALL22061-8 ALL22061-12 —
1-1/4" x .095" ALL22063-4 ALL22063-8 ALL22063-12 —
1-1/4" x .120" ALL22064-4 ALL22064-8 ALL22064-12 ALL22064-17
1-3/8" x .058" ALL22070-4 ALL22070-8 ALL22070-12 —
1-3/8" x .095" ALL22072-4 ALL22072-8 ALL22072-12 —
1-1/2" x .058" ALL22080-4 ALL22080-8 ALL22080-12 ALL22080-17
1-1/2" x .065" ALL22082-4 ALL22082-8 ALL22082-12 —
1-1/2" x .083" ALL22084-4 ALL22084-8 ALL22084-12 —
1-1/2" x .095" ALL22086-4 ALL22086-8 ALL22086-12 —
1-3/4" x .083" ALL22093-4 ALL22093-8 ALL22093-12 —
1-5/8" x .083" ALL22090-4 ALL22090-8 ALL22090-12 —
2-1/4" x .120" ALL22095-5*
* Part is 5 Ft. length.

Threaded Tubing Ends
&KURPH PRO\ VWHHO WXELQJ HQGV DUH LGHDO IRU EXLOGLQJ FXVWRP OHQJWK VXVSHQVLRQ WXEHV $YDLODEOH LQ 5+ DQG /+ WKUHDGV
Thread Size Tubing Size Tube End Insert O.D. RH Part No. LH Part No.
10-32 3/8" x .058" .259" ALL22500 –
5/16"-24 1/2" x .058" .384" ALL22504 –
3/8"-24 5/8" x. 058" .509" ALL22508 ALL22509
3/8"-24 3/4" x .058" .634" ALL22512 ALL22513
1/2"-20 7/8" x .058" .759" ALL22518 ALL22519
1/2"-20 1" x .058" .884" ALL22522 ALL22523
1/2"-20 1" x .065" .870" ALL22526 ALL22527
1/2"-20 1-1/8" x .058" 1.00" ALL22530 ALL22531
5/8"-18 1" x .058" .884" ALL22534 ALL22535
5/8"-18 1" x .095" .810" ALL22538 ALL22539
5/8"-18 1-1/4" x .095" 1.060" ALL22542 ALL22543*
5/8"-18 1-1/4" x .120" 1.010" ALL22546 ALL22547*
3/4"-16 1-1/4" x .065" .995" ALL22548 ALL22549*
3/4"-16 1-1/4" x .095" 1.060" ALL22550 ALL22551*
3/4"-16 1-1/4" x .120" 1.010" ALL22554 ALL22555*
3/4"-16 1-3/8" x .095" 1.185" ALL22558 ALL22559*
* Tube end has built-in hex for adjusting.
