Plastic Tank Radiators Late Model COOLING
Uniquely designed plastic tank radiators with aluminum Radiator ALL30044
core offer over a 22% gross weight savings to comparable Aluminum dual pass
aluminum tank radiators when filled with coolant. These radiator has 16"x28"
performance radiators also provide 6% better cooling overall dimensions and
than aluminum tank radiators. Tanks are fastened to the does not have a filler neck.
core with multi-clamps and an o-ring gasket, a process The 1-3/4" bottom outlet is
similar in design to many of today’s high performance late welded 90° to the tank, not angled, as
model muscle cars. Corrosion resistant tanks have molded these radiators typically mount with the top leaned for-
in 1-1/2" inlet and 1-3/4" ward. Universal top inlet design accepts 1-1/2" standard
beaded hose outlets. Widths hose, 1-3/4" hose, -16 or -20an fittings (sold separately).
are overall including tanks. Includes a 1/4" petcock located near the top on the
driver’s side to release possible air in the system
Single Pass when filling.
Core WxH Overall
GM
ALL30050 17" x 18" 22" x 19" Sprint Radiator ALL30028
ALL30051 19" x 18" 24" x 19" Aluminum radiator with furnace
ALL30052 21" x 18" 26" x 19" ALL30052 brazed tanks provides superior
ALL30053 23" x 18" 28" x 19" cooling in sprint applications. Features
ALL30054 26" x 18" 31" x 19" machined filler neck, 1-1/2" RH
Ford bottom outlet and (4) female top
ALL30320 17" x 18" 22" x 19" outlet ports for use with -10AN
ALL30321 19" x 18" 24" x 19"
ALL30322 21" x 18" 26" x 19" O-ring fittings. Radiator uses a smaller
ALL30324 23" x 18" 28" x 19" diameter cap (not included) such as
ALL30326 26" x 18" 31" x 19" ALL30124 or ALL30125. 20" wide x 22"
tall x 2" wide. 9.7 lbs.

ALL30322
Sprint Cross Flow Radiator
Dual Pass
(Chassis Mount)
GM Core WxH Overall ALL30030
ALL30056 19" x 18" 24" x 19"
ALL30057 21" x 18" 26" x 19" Aluminum radiator with a
ALL30058 23" x 18" 28" x 19" unique black thermal coating
ALL30059 26" x 18" 31" x 19" provides superior cooling!
Built-in mounting brackets
enable the radiator to be quick-
turn fastened directly to frame
ALL30572
TECH TIP tabs. Radiator with -10AN O-ring
Radiators with plastic tanks are recommended inlets and 1-1/2" outlet is 20-1/2" wide x
to use radiator caps rated at 25 lbs. or less. 18-1/2" tall (including outlet neck) x 2-3/8" thick
core. Recommended radiator cap is ALL30126
Popular Radiator Caps (28-32 lbs.) sold separately. Approximate weight
For Plastic Tank Radiators
ALL30135 8.5 lbs.
ALL30135 ..... Stant Round 21–25psi Non-Recovery
ALL30137 ..... Stant Octagon 21–25psi Recovery
Wall Mount
Upper Mount Kit
Radiator Holder Kit ALL12216
For Plastic Tank Radiators ALL30152
Brackets fasten to trailer wall and
Channel rests on top of the core and two flat aluminum hold radiator safely in place to
straps may be bolted or welded to the channel. Hook the avoid damage during transport.
steel springs into provided hole and connect to a lower Kit includes two 29" long alu-
chassis location. Kit includes channel (1-1/2" x minum brackets with adjustment
21-1/2"), two straps (1" x 11-1/2") and holes at 2" increments and arms
two 17" springs. to fit radiator cores up to 2-1/4"
wide. Adjustable arms are slotted for quick
Replacement Parts
ALL30122 ..... Spring adjustment with included thumbscrew knobs
ALL30153 ..... Channel to fit a variety of radiator heights.
