Page 192 - 2020 Allstar Performance Parts and Equipment Catalog

SUSPENSION Steel Control Arm Bushings Roller Bearing

Lower Control Arm Bushings
Allstar Steel Control Arm Bushings replace
stock rubber bushings and eliminate
Free up stock front suspensions and help
deflection, a common problem with
prevent binding commonly found with
original equipment bushings.
ALL56230
stock rubber and steel insert bushings.
Steel bodied bushings are complete with
Lower Control Arm Bushing Applications
needle roller bearings and hardened ALL56223
Part No. Application Bushing Position O.D. UHL Hole Size inserts that are ready to install and do
Chevelle, Monte Carlo, GM Intermediates not require special mounting hardware.
1964-66 Front (2nd Design) 1.345" 2.100" .500"
ALL56230 All bushings have 1/2" I.D. mounting
1967-74 Front 1.345" 2.100" .500"
1964-66 Front (1st Design) 1.645" 2.100" .500" holes.
1975-77 Front 1.645" 2.100" .500"
ALL56232 Part No. Application Bushing Position O.D. UHL Hole Size
1964-72 Rear 1.645" 2.100" .500"
1978-88 Rear 1.645" 2.100" .500" Chevelle, Monte Carlo, GM Intermediates
ALL56233 – – 1.645" 2.100" .562" ALL56221 1964-66 Front (2nd Design) 1.345" 2.100" .500"
ALL56234 1973-77 Rear 1.900" 2.100" .500" 1967-74 Front 1.345" 2.100" .500"
ALL56235 – – 1.900" 2.100" .562" 1964-66 Front (1st Design) 1.645" 2.100" .500"
ALL56236 1978-88 Front 1.440" 2.750" .500" 1975-77 Front 1.645" 2.100" .500"
Camaro, Firebird ALL56222 1964-72 Rear 1.645" 2.100" .500"
ALL56230 1967-74 Front 1.345" 2.100" .500" 1978-88 Rear 1.645" 2.100" .500"
1975-81 Front 1.645" 2.100" .500" ALL56223 1973-77 Rear 1.900" 2.100" .500"
ALL56232
1967-72 Rear 1.645" 2.100" .500" ALL56224 1978-88 Front 1.440" 2.750" .500"
ALL56234 1973-88 Rear 1.900" 2.100" .500" Camaro, Firebird
ALL56236 1982-92 Front 1.440" 2.750" .500"
ALL56221 1967-74 Front 1.345" 2.100" .500"
1975-81 Front 1.645" 2.100" .500"
Upper Control Arm Bushing Applications ALL56222
1967-72 Rear 1.645" 2.100" .500"
Part No. Application Bushing Position O.D. UHL Hole Size ALL56223 1973-88 Rear 1.900" 2.100" .500"
Chevelle, Monte Carlo, GM Intermediates ALL56224 1982-92 Front 1.440" 2.750" .500"
ALL56238 1967-72 All 1.275" 1.250" .675"
ALL56240 1978-88 All 1.530" 1.500" .695" Replacement Parts
ALL56242 1973-77 Front 1.394" 1.500" .690" ALL99250 ..... Thrust Bearing Set
ALL56244 1973-77 Rear 1.311" 1.425" .690" Related Parts
Camaro, Firebird ALL56226 ..... Nylon Bushing Kit
ALL56238 1967-69 All 1.275" 1.250" .675" (Optional bushings to replace roller bearings when
ALL56242 1974-79 Front 1.394" 1.500" .690" conforming to some sanctioning body rules.)
ALL56244 1974-79 Rear 1.311" 1.425" .690"
Lightweight,
Low Friction Lower
Control Arm Bushings
Designed specifically for racing these
bushings feature a lightweight housing ALL56228
with 2 steel inner bushings, machined so they can be
tightened without binding. O-rings on each side help
keep the bushings in place while installing and also help
keep dirt out. Bushings should be disassembled and reas-
sembled with a good quality wheel bearing grease prior
to installation.
Chevelle 1964 - 1974
ALL56227 ..... Front
ALL56229 ..... Rear
Metric 1978 - 1988
ALL56228 ..... Front
ALL56229 ..... Rear ALL56229 Greg Brown Photo: RW Motorsports

190 www.allstarperformance.com
