Page 449 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

QUARTER MIDGET PARTS AND ACCESSORIES

SUSPENSION & BODY

Polished Radius Rods
Quarter Midget Springs Polished 6061 swaged aluminum radius rods are 1/2" OD x 5/16" x
/PNO X\HSP[` JOYVTL ZPSPJVU ZWYPUNZ OH]L H Z[LLS IS\L LWV_` ÄUPZO .080" wall thickness. Available in lengths from 7" to 20.75". For use
HUK HYL TL[HS [HNNLK MVY LHZ` PKLU[PÄJH[PVU (SS KPHTL[LYZ HUK YH[LZ with 5/16" left and right hand Heim ends.
are in stock. Length Part No.
7" MWASRE5-7-POL
Rate 3.5" Tall 5" Tall ID
70 — SSSUT5-070 1.7" 7.5" MWASRE5-7.5-POL
75 SSSTU3.5-075 SSSUT5-075 1.7" 8" MWASRE5-8-POL
80 SSSTU3.5-080 SSSUT5-080 1.7" 8.5" MWASRE5-8.5-POL
85 SSSTU3.5-085 SSSUT5-085 1.7" 9" MWASRE5-9-POL
90 SSSTU3.5-090 SSSUT5-090 1.7" 9.25" MWASRE5-9.25-POL
95 SSSTU3.5-095 SSSUT5-095 1.7" 10.25" MWASRE5-10.25-POL
100 SSSTU3.5-100 SSSUT5-100 1.7" 11" MWASRE5-11-POL
105 SSSTU3.5-105 SSSUT5-105 1.7" 11.75" MWASRE5-11.75-POL
110 SSSTU3.5-110 SSSUT5-110 1.7" 12" MWASRE5-12-POL
115 SSSTU3.5-115 SSSUT5-115 1.7" 13" MWASRE5-13-POL
120 SSSTU3.5-120 SSSUT5-120 1.7" 14" MWASRE5-14-POL
125 SSSTU3.5-125 SSSUT5-125 1.7" 14.5" MWASRE5-14.5-POL
130 SSSTU3.5-130 SSSUT5-130 1.7" 15" MWASRE5-15-POL
135 SSSTU3.5-135 SSSUT5-135 1.7" 15.5" MWASRE5-15.5-POL
140 SSSTU3.5-140 SSSUT5-140 1.7" 16" MWASRE5-16-POL
145 SSSTU3.5-145 SSSUT5-145 1.7" 17" MWASRE5-17-POL
150 SSSTU3.5-150 SSSUT5-150 1.7" 18.75" MWASRE5-18.75-POL
155 SSSTU3.5-155 SSSUT5-155 1.7" 19.5" MWASRE5-19.5-POL
160 — SSSUT5-160 1.7"
20.25" MWASRE5-20.25-POL
20.50" MWASRE5-20.5-POL
20.75" MWASRE5-20.75-POL

Aluminum Suspension Tubes
5V^ VɈLYLK PU ZTHSSLY KPHTL[LY 8\PJR*HY :\ZWLU-
ZPVU ;\ILZ HYL THU\MHJ[\YLK PU [OL <:( MYVT YPNPK HS\TPU\T
and are up to 35% stronger than traditional hex or round units.
Suspension tubes include precision machined ends, corrosion
YLZPZ[HU[ ISHJR HUVKPaLK ÄUPZO HUK PKLU[PÄJH[PVU VU [OL SLM[ OHUK
threaded end. Unique design allows easy adjustments by hand or 5/16"-24 8mm-1.25" 3/8"-24
^P[O H ^YLUJO ;\ILZ HYL VɈLYLK ^P[O TT VY
[OYLHKZ 4L[YPJ [OYLHKLK [\IL PUJS\KLZ ZWLJPHS PKLU[PÄJH[PVU
Length 5/16"-24 8mm-1.25" 3/8"-24 Length 5/16"-24 8mm-1.25" 3/8"-24
6" QRP31-060 — — 16.5" QRP31-165 QRP08-165 QRP38-165
7" QRP31-070 — — 17" QRP31-170 QRP08-170 QRP38-170
7.5" QRP31-075 — — 17.5" QRP31-175 QRP08-175 QRP38-175
8" QRP31-080 QRP08-080 QRP38-080 18" QRP31-180 QRP08-180 QRP38-180
8.5" QRP31-085 QRP08-085 QRP38-085 18.5" QRP31-185 QRP08-185 QRP38-185
9" QRP31-090 QRP08-090 QRP38-090 19" QRP31-190 QRP08-190 QRP38-190
9.5" QRP31-095 QRP08-095 QRP38-095 19.5" QRP31-195 QRP08-195 QRP38-195
10" QRP31-100 QRP08-100 QRP38-100 20" QRP31-200 QRP08-200 QRP38-200
10.5" QRP31-105 QRP08-105 QRP38-105 20.5" QRP31-205 — —
11" QRP31-110 QRP08-110 QRP38-110 21" QRP31-210 — —
11.5" QRP31-115 QRP08-115 QRP38-115 21.5" QRP31-215 — —
12" QRP31-120 QRP08-120 QRP38-120 22" QRP31-220 — —
12.5" QRP31-125 QRP08-125 QRP38-125 22.5" QRP31-225 — —
13" QRP31-130 QRP08-130 QRP38-130 23" QRP31-230 — —
13.5" QRP31-135 QRP08-135 QRP38-135 23.5" QRP31-235 — —
14" QRP31-140 QRP08-140 QRP38-140 24" QRP31-240 — —
14.5" QRP31-145 QRP08-145 QRP38-145 24.5" QRP31-245 — —
15" QRP31-150 QRP08-150 QRP38-150 25" QRP31-250 — —
15.5" QRP31-155 QRP08-155 QRP38-155 25.5" QRP31-255 — —
16" QRP31-160 QRP08-160 QRP38-160 26" QRP31-260 — —

448
