With our unsurpassed CNC Plasma Cutting Systems, we serve many industries. We tailor our systems to your needs.
* The cutting speed chart above includes preliminary data and is subject to change without notice, compare other data carefully. The above stated speeds are the best cut speeds, as is the case with all Thermal Dynamics competitors' cutting speed numbers. Much higher cutting speeds are possible, though edge quality and bevel angle may be compromised. The capabilities shown in this chart were obtained by using new consumables, correct gas and current settings, accurate torch height control and with the torch perpendicular to the workpiece. The operating chart does not list all processes available for the Auto- Cut 100.
Consider your application before choosing a laser cutter. What objects or materials will you cut? Do you only want to use laser cutting? Or do you want to drill and engrave items as well? You will need to consider your specific needs when choosing a laser cutter. Consider the size of your work area and laser specifications such as power, wavelength, repetition rates, as well as the integration and CNC capabilities. After you have established these parameters, you should also consider your budget and compare it with other technology options.
Hypertherm's standard definition Powermax or MAXPRO200 plasmas, or the high-definition HyPerformance and XPR families of plasmas, are all available. Hypertherm's excellent EDGE Connect controllers are also available.
Laser cutting is a precise cutting technology that uses a laser beam to drill, perforate, and depanel different materials. Laser cutters can make precise cuts due to the precision of laser deposition. Laser cutters are the most precise machines available, thanks to their CNC capabilities. Laser cutters produce very smooth edges and can cut various objects without damaging the surrounding material.
The Ultra-Cut 100 offers many benefits for shops and businesses whose quality standards and applications match those of the Ultra-Cut 100. It is easy to use, packed with advanced technology, and reliable for high precision cut. This will increase productivity and profitability.
Victory Rail & Gantry systems include True Hole, which was designed from the ground up to give you the best possible plasma-cut hole. Each of our industrial CNC Rail Systems are built in house and ships complete, with plasma cutter and controller installed and fully tested prior to shipment.
Victory Unitized CNC Plasma System has a worktable. It features a double-frame structural structure with a 3/16'' walled tub. Built on a W4x13 steel frame, it is designed to withstand the harsh industrial environment. It features a smooth, precise guide system with a combination of helical guide rails with a heavy 'T’ design and helical rail rack with 2'’ steel rollers at the rail axis.
The Auto-Cut O2 series systems can be added to any ezRouter CNC plasma machine. This allows for virtually dross-free cutting and high-speed oxygen cutting. Thermal Dynamics also used MaximumLife consumables in the design and construction of this plasma cutting machine. The Auto-Cut CNC plasma cutting systems offer the longest parts life in their category.
The addition of Autocut to your plasma CNC will allow you to achieve economic performance on both mild steels and non-ferrous metals. The power supplies have been designed to be reliable and cost-effective. Auto-Cut's easy-to-use operation is made possible by features like TD’s XT301 consumables parts cartridge and the machine status message central.
Victory Rail CNC plasma has floor-mounted, kneehigh rails. A dual-side steel gantry system supports full sheets (3") of plate, ranging from 5'x10’ to 10'x30’. The dual-side drive system is equipped with all Hypertherm components. This includes the EDGEConnect TC control and your choice of HPR, XPR, True Hole or plasma marking plasmas. These machines can also be fitted over existing cutting boards or bought cutting tables. Victory will send you drawings of the factory for your custom-made work table. Options include 3/4hp CNC, multiple oxy fuel torches with multiple plasma cutters and 12 inch outboard tube cutter. SnapLoc straight -line bevel and off-table trimming are also available. Systems start from $162,070 when you purchase XPR170.
With the addition of Auto-Cut to your plasma CNC you'll have economic performance on mild steel and non-ferrous materials. The power supplies are designed for low cost operation you can always rely on. Thanks to features like TD's XT-301 consumable parts cartridge and machine status message center the Auto-Cut systems are easy to operate.
Self-Centering Components : Precision engineering of torch bodies and consumable parts designed to lock in place for absolute alignment and stay perfectly positioned cut aftercut. Independently-aligned tip and electrode for reliable, accurate re-centering of the consumable cartridge after each parts change.
Victory Rail CNC plasma systems feature floor-mounted, knee high rails, dual side drive steel gantry systems that ride over a downdraft. They can support full sheets of 3' plate from 5' x 10’ to 10’ x 30’. The dual side drive system includes all Hypertherm components including the EDGE Connect TC Controller and your choice between HPR or XPR Plasmas with Autogas, True Hole and plasma engraving. These machines can be used over existing cutting tables and buyer-built cutting tables. Victory will provide drawings to help build buyer-built work tables. There are many options: 3/4hp CNC drilling, multiple oxyfuel torches and multiple plasma cutters. A 12" diameter outboard tube cutter, SnapLoc straight-line vel, and off-table cutting. Systems start at $162,000.70 with XPR170.
Any metal, including steel and stainless steel can be plasma-cut for any purpose. Depending on the plasma cutter used, any thickness can be cut from 30 gauges to 1 inch. Material can be up to 4ft wide and 20ft in length.
The most common mixture is 35% hydrogen and 65 argon, also known as H-35. Argon hydrogen, which is the most powerful plasma gas, is also the hottest and has the greatest cutting power. (Argon hydrogen can be used in water injection torch up to 1000 amps to cut up to 6" stainless steel
Amtec 8 is an electrode that can be used to groove, chamfer, cut, and gouge without oxygen or air. It's a fast and efficient tool for metal work. It can be used with all metals, including cast iron, manganese, stainless, and aluminum.
Re: Best Slat Shape - Pros and Cons Mine are all flat sheared slats, which are bent in a curve for additional stability.
