While multiple rows are not necessary when following the guidelines above, they should still be considered if load tipping may be a concern. If a vacuum lifter is intended for up-ending (tilting), it is necessary to specify an even number.
An electrical switch is attached to the lifting bail that controls the vacuum attach/release cycle. After the unit is dropped onto the load and its suspension chain has slowed, the switch starts the attachment process. Once the proper vacuum level was achieved, a green indicator will light up to indicate that it is safe for you to lift. Once you are ready to lower the load, turn the switch to release the vacuum. Once vacuum has been released from the unit, you can raise it with the hoist controls.
ANVER Vacuum Lifters comply fully with and meet the standards of US ANSI ASME Standard B30.20 for below-the-hook lifting devices, as well as complying with OSHA and most European requirements. Click here for more information on these safety standards.$50 Amazon gift card for your photo submission or a $150 Amazon gift card for your video submission if we use it for advertising purposes. Click here for details.
The beam length can be calculated by subtraction of 2L from the maximum loads length, and then adding 6 in to it. With a max load length of 120 ins and a 2L of 60 ins, the minimum beam would be 66ins (120-60+6). If this length is not standard, you can choose the next-longest standard beam length.
BMC-Series lifters are equipped with removable pad extensions. Vacuum pads can be installed inline to handle long or narrow loads, or without extensions to handle short or narrow loads. This equipment is constructed with an ergonomic lifter handlebar, a welded steel lifting framework and can be used with ease for handling a variety of loads and applications.
Identify the weight of the material you wish to lift. Determine the load's minimum and maximum dimensions as well as its maximum weight. You must also determine the minimum and maximum thickness.
The entire ANVER line of powered vacuum generators comes with a range of electrical specifications. The vacuum generator's web page contains all relevant electrical information. Notice: All ANVER components, controls, and wiring comply with international standards: UL. CSA. NFPA. NEC. It is the responsibility of the user to adhere to any additional local electrical codes that may apply to their installation. North American Standard Electricity Requirements. To be Festooned (wire loops hanging from overhead crane trolleys) to the Lifter. Power should be brought to the hoist, and then to the lifter via a retractable cable/coil cord. It is only a matter of adding power to the lifter, as you are already attached to the hoist. As they came from the factory, it is best to keep the lifter pendant controls and the hoist separate. Additional Voltages and Phases: Generators are available in the following voltages. A transformer can be added to supply these voltages: 208V. Circuit breakers or fuses are used to protect generator motors that have a voltage less than 120V. Motors and other devices that consume more than 200V are fused or use thermal overload with a contractor.
Notice: Any side panels, hardware or assembly that support loads need to be strong enough to be lifted out from the sides. It is the responsibility and obligation of the customers to ensure that their products can be lifted without any damage.
A vacuum lifter should have enough capacity to lift your heaviest and most difficult load. See how we calculate it.
Determine the Required Crossarm Length.Subtract 2L of the maximum load width, and add 6 inches. If the crossarm length is not standard, you can choose the next longest length.
Your crane and hoist should have sufficient lifting capacity. To get the total capacity, subtract the vacuum lifter weight from your hoist and crane. Do you have any spare parts, such as seals or vacuum cups? They may last for a while, but this is likely to be the first item that needs service.
GSS Machinery offers a complete selection of vacuum lifters. These include horizontal lifters, powered lifters, and battery powered lifters.
EMC-Series lifters come equipped with removeable pad extensions. The vacuum pads can be mounted inline for handling long and narrow loads or without the extensions for handling short and narrow loads. Constructed with an ergonomic lifter handlebar and a welded steel lifting frame, operators can use this equipment with ease and comfort for a wide range of loads and applications.
NOTE: While multiple rows are not required for the following guidelines, they should be considered in case load tipping is a concern. A vacuum lifter for up-ending (tilting) must have an even number and number of cross-arms. This will prevent interference with its up-ending yoke.
