Taking images of the ground from the air

Aerial photography (or airborne imagery) is the taking of photographs from an aircraft or other airborne platforms.^[1] When taking motion pictures, it is also known as aerial videography.

Platforms for aerial photography include fixed-wing aircraft, helicopters, unmanned aerial vehicles (UAVs or "drones"), balloons, blimps and dirigibles, rockets, pigeons, kites, or using action cameras while skydiving or wingsuiting. Handheld cameras may be manually operated by the photographer, while mounted cameras are usually remotely operated or triggered automatically.

Aerial photography typically refers specifically to bird's-eye view images that focus on landscapes and surface objects, and should not be confused with air-to-air photography, where one or more aircraft are used as chase planes that "chase" and photograph other aircraft in flight. Elevated photography can also produce bird's-eye images closely resembling aerial photography (despite not actually being aerial shots) when telephotoing from high vantage structures, suspended on cables (e.g. Skycam) or on top of very tall poles that are either handheld (e.g. monopods and selfie sticks), fixed firmly to the ground (e.g. surveillance cameras and crane shots) or mounted above vehicles.

History

[edit]

See also: Aerial reconnaissance § History

This section duplicates the scope of other articles, specifically Aerial reconnaissance#History. Please discuss this issue and help introduce a summary style to the section by replacing the section with a link and a summary or by splitting the content into a new article. (October 2020)

Early

[edit]

Aerial photography was first practiced by the French photographer and balloonist Gaspard-Félix Tournachon, known as "Nadar", in 1858 over Paris, France.^[3] However, the photographs he produced no longer exist and therefore the earliest surviving aerial photograph is titled 'Boston, as the Eagle and the Wild Goose See It.' Taken by James Wallace Black and Samuel Archer King on October 13, 1860, it depicts Boston from a height of 630m.^[4][5]

Kite aerial photography was pioneered by British meteorologist E.D. Archibald in 1882. He used an explosive charge on a timer to take photographs from the air.^[6] The same year, Cecil Shadbolt devised a method of taking photographs from the basket of a gas balloon, including shots looking vertically downwards.^[7][8] One of his images, taken from 2,000 feet (610 m) over Stamford Hill, is the earliest extant aerial photograph taken in the British Isles.^[7] A print of the same image, An Instantaneous Map Photograph taken from the Car of a Balloon, 2,000 feet high, was shown at the 1882 Photographic Society exhibition.^[8]

Frenchman Arthur Batut began using kites for photography in 1888, and wrote a book on his methods in 1890.^[9][10] Samuel Franklin Cody developed his advanced 'Man-lifter War Kite' and succeeded in interesting the British War Office with its capabilities.

In 1908, Albert Samama Chikly filmed the first ever aerial views using a balloon between Hammam-Lif and Grombalia.^[11] The first use of a motion picture camera mounted to a heavier-than-air aircraft took place on April 24, 1909, over Rome in the 3:28 silent film short, Wilbur Wright und seine Flugmaschine.

World War I

[edit]

The use of aerial photography rapidly matured during the war, as reconnaissance aircraft were equipped with cameras to record enemy movements and defenses. At the start of the conflict, the usefulness of aerial photography was not fully appreciated, with reconnaissance being accomplished with map sketching from the air.

Germany adopted the first aerial camera, a Görz, in 1913. The French began the war with several squadrons of Blériot observation aircraft equipped with cameras for reconnaissance. The French Army developed procedures for getting prints into the hands of field commanders in record time.

Frederick Charles Victor Laws started aerial photography experiments in 1912 with No.1 Squadron of the Royal Flying Corps (later No. 1 Squadron RAF), taking photographs from the British dirigible Beta. He discovered that vertical photos taken with a 60% overlap could be used to create a stereoscopic effect when viewed in a stereoscope, thus creating a perception of depth that could aid in cartography and in intelligence derived from aerial images. The Royal Flying Corps recon pilots began to use cameras for recording their observations in 1914 and by the Battle of Neuve Chapelle in 1915, the entire system of German trenches was being photographed.^[12] In 1916, the Austro-Hungarian Monarchy made vertical camera axis aerial photos above Italy for map-making.

The first purpose-built and practical aerial camera was invented by Captain John Moore-Brabazon in 1915 with the help of the Thornton-Pickard company, greatly enhancing the efficiency of aerial photography. The camera was inserted into the floor of the aircraft and could be triggered by the pilot at intervals. Moore-Brabazon also pioneered the incorporation of stereoscopic techniques into aerial photography, allowing the height of objects on the landscape to be discerned by comparing photographs taken at different angles.^[13][14]

By the end of the war, aerial cameras had dramatically increased in size and focal power and were used increasingly frequently as they proved their pivotal military worth; by 1918, both sides were photographing the entire front twice a day and had taken over half a million photos since the beginning of the conflict. In January 1918, General Allenby used five Australian pilots from No. 1 Squadron AFC to photograph a 624 square miles (1,620 km²) area in Palestine as an aid to correcting and improving maps of the Turkish front. This was a pioneering use of aerial photography as an aid for cartography. Lieutenants Leonard Taplin, Allan Runciman Brown, H. L. Fraser, Edward Patrick Kenny, and L. W. Rogers photographed a block of land stretching from the Turkish front lines 32 miles (51 km) deep into their rear areas. Beginning 5 January, they flew with a fighter escort to ward off enemy fighters. Using Royal Aircraft Factory BE.12 and Martinsyde airplanes, they not only overcame enemy air attacks, but also had to contend with 65 mph (105 km/h) winds, antiaircraft fire, and malfunctioning equipment to complete their task.^[15]

Commercial

[edit]

The first commercial aerial photography company in the UK was Aerofilms Ltd, founded by World War I veterans Francis Wills and Claude Graham White in 1919. The company soon expanded into a business with major contracts in Africa and Asia as well as in the UK. Operations began from the Stag Lane Aerodrome at Edgware, using the aircraft of the London Flying School. Subsequently, the Aircraft Manufacturing Company (later the De Havilland Aircraft Company), hired an Airco DH.9 along with pilot entrepreneur Alan Cobham.^[16]

From 1921, Aerofilms carried out vertical photography for survey and mapping purposes. During the 1930s, the company pioneered the science of photogrammetry (mapping from aerial photographs), with the Ordnance Survey amongst the company's clients.^[17] In 1920, the Australian Milton Kent started using a half-plate oblique aero camera purchased from Carl Zeiss AG in his aerial photographic business.^[18]

Another successful pioneer of the commercial use of aerial photography was the American Sherman Fairchild who started with his own aircraft firm Fairchild Aircraft to develop and build specialized aircraft for high altitude aerial survey missions.^[19] One Fairchild aerial survey aircraft in 1935 carried a unit that combined two synchronized cameras. Utilizing two units of ten lenses each with a ten-inch lens, the aircraft took photos from 23,000 feet. Each photo covered two hundred and twenty-five square miles. One of its first government contracts was an aerial survey of New Mexico to study soil erosion.^[20] A year later, Fairchild introduced a better high altitude camera with a nine-lens in one unit that could take a photo covering 600 square miles with each exposure from 30,000 feet.^[21]

World War II

[edit]

In 1939, Sidney Cotton and Flying Officer Maurice Longbottom of the RAF were among the first to suggest that airborne reconnaissance may be a task better suited to fast, small aircraft which would use their speed and high service ceiling to avoid detection and interception. Although this seems obvious now, with modern reconnaissance tasks performed by fast, high flying aircraft, at the time it was radical thinking.^{[citation needed]}

They proposed the use of Spitfires with their armament and radios removed and replaced with extra fuel and cameras. This led to the development of the Spitfire PR variants. Spitfires proved to be extremely successful in their reconnaissance role and there were many variants built specifically for that purpose. They served initially with what later became No. 1 Photographic Reconnaissance Unit (PRU). In 1928, the RAF developed an electric heating system for the aerial camera. This allowed reconnaissance aircraft to take pictures from very high altitudes without the camera parts freezing.^[22] Based at RAF Medmenham, the collection and interpretation of such photographs became a considerable enterprise.^[23]

Cotton's aerial photographs were far ahead of their time. Together with other members of the 1 PRU, he pioneered the techniques of high-altitude, high-speed stereoscopic photography that were instrumental in revealing the locations of many crucial military and intelligence targets. According to R.V. Jones, photographs were used to establish the size and the characteristic launching mechanisms for both the V-1 flying bomb and the V-2 rocket. Cotton also worked on ideas such as a prototype specialist reconnaissance aircraft and further refinements of photographic equipment. At the peak, the British flew over 100 reconnaissance flights a day, yielding 50,000 images per day to interpret. Similar efforts were taken by other countries.^{[citation needed]}

While stationed on an aircraft carrier in Imperial Japan, FS Hussain, a pilot in the Royal Indian Air Force, was tasked with photographing the aftermath of the Atomic bombings of Hiroshima and Nagasaki.^[24] Unaware of the risks of exposure to radiation, it led to his death in 1969 at the age of 44.^[25]

Uses

[edit]

Vertical aerial photography is used in cartography^[26] (particularly in photogrammetric surveys, which are often the basis for topographic maps^[27][28]), land-use planning,^[26] aerial archaeology.^[26] Oblique aerial photography is used for movie production, environmental studies,^[29] power line inspection,^[30] surveillance, construction progress, commercial advertising, conveyancing, and artistic projects. An example of how aerial photography is used in the field of archaeology is the mapping project done at the site Angkor Borei in Cambodia from 1995 to 1996. Using aerial photography, archaeologists were able to identify archaeological features, including 112 water features (reservoirs, artificially constructed pools and natural ponds) within the walled site of Angkor Borei.^[31] In the United States, aerial photographs are used in many Phase I Environmental Site Assessments for property analysis.

Aircraft

[edit]

In the United States, except when necessary for take-off and landing, full-sized manned aircraft are prohibited from flying at altitudes under 1000 feet over congested areas and not closer than 500 feet from any person, vessel, vehicle or structure over non-congested areas. Certain exceptions are allowed for helicopters, powered parachutes and weight-shift-control aircraft.^[32]

Radio-controlled

[edit]

Advances in radio controlled models have made it possible for model aircraft to conduct low-altitude aerial photography. This had benefited real-estate advertising, where commercial and residential properties are the photographic subject. In 2014, the US Federal Aviation Administration banned the use of drones for photographs in real estate advertisements.^[33] The ban has been lifted and commercial aerial photography using drones of UAS is regulated under the FAA Reauthorization Act of 2018.^[34][35] Commercial pilots have to complete the requirements for a Part 107 license,^[36] while amateur and non-commercial use is restricted by the FAA.^[37]

Small scale model aircraft offer increased photographic access to these previously restricted areas. Miniature vehicles do not replace full-size aircraft, as full-size aircraft are capable of longer flight times, higher altitudes, and greater equipment payloads. They are, however, useful in any situation in which a full-scale aircraft would be dangerous to operate. Examples would include the inspection of transformers atop power transmission lines and slow, low-level flight over agricultural fields, both of which can be accomplished by a large-scale radio-controlled helicopter. Professional-grade, gyroscopically stabilized camera platforms are available for use under such a model; a large model helicopter with a 26cc gasoline engine can hoist a payload of approximately seven kilograms (15 pounds). One example is the radio controlled Nitrohawk helicopter developed by Robert Channon between 1988 and 1998.^[38] In addition to gyroscopically stabilized footage, the use of RC copters as reliable aerial photography tools increased with the integration of FPV (first-person-view) technology. Many radio-controlled aircraft, in particular drones, are now capable of utilizing Wi-Fi to stream live video from the aircraft's camera back to the pilot's or pilot in command's (PIC) ground station.^[39]

Regulations

[edit]

In Australia, Civil Aviation Safety Regulation Part 101 (CASR Part 101)^[40] allows for commercial use of unmanned and remotely piloted aircraft. Under these regulations, unmanned remotely piloted aircraft for commercial are referred to as Remotely Piloted Aircraft Systems (RPAS), whereas radio-controlled aircraft for recreational purposes are referred to as model aircraft. Under CASR Part 101, businesses/persons operating remotely piloted aircraft commercially are required to hold an operator certificate, just like manned aircraft operators. Pilots of remotely piloted aircraft operating commercially are also required to be licensed by the Civil Aviation Safety Authority (CASA).^[41] While a small RPAS and model aircraft may actually be identical, unlike model aircraft, a RPAS may enter controlled airspace with approval, and operate close to an aerodrome.

Due to a number of illegal operators in Australia, making false claims of being approved, CASA maintains and publishes a list of approved remote operator's certificate (ReOC) holders.^[42] However, CASA has modified the regulations and from September 29, 2016, drones under 2 kg (4.4 lb) may be operated for commercial purposes.^[43]

2006 FAA regulations grounding all commercial RC model flights have been upgraded to require formal FAA certification before permission is granted to fly at any altitude in the US.

On June 25, 2014, the FAA, in ruling 14 CFR Part 91 [Docket No. FAA–2014–0396] "Interpretation of the Special Rule for Model Aircraft", banned the commercial use of unmanned aircraft over U.S. airspace.^[44] On September 26, 2014, the FAA began granting the right to use drones in aerial filmmaking. Operators are required to be licensed pilots and must keep the drone in view at all times. Drones cannot be used to film in areas where people might be put at risk.^[45]

The FAA Modernization and Reform Act of 2012 established, in Section 336, a special rule for model aircraft. In Section 336, Congress confirmed the FAA's long-standing position that model aircraft are aircraft. Under the terms of the Act, a model aircraft is defined as "an unmanned aircraft" that is "(1) capable of sustained flight in the atmosphere; (2) flown within visual line of sight of the person operating the aircraft; and (3) flown for hobby or recreational purposes."^[46]

Because anything capable of being viewed from a public space is considered outside the realm of privacy in the United States, aerial photography may legally document features and occurrences on private property.^[47]

The FAA can pursue enforcement action against persons operating model aircraft who endanger the safety of the national airspace system: Public Law 112–95, section 336(b).^[33]

On June 21, 2016, the FAA released its summary of small unmanned aircraft rules (Part 107). The rules established guidelines for small UAS operators including operating only during the daytime, a 400 ft (120 m). ceiling and pilots must keep the UAS in visual range.^[48]

On April 7, 2017, the FAA announced special security instructions under 14 CFR § 99.7. Effective April 14, 2017, all UAS flights within 400 feet of the lateral boundaries of U.S. military installations are prohibited unless a special permit is secured from the base and/or the FAA.^[49]

Aerial photography in the UK has tight regulations as to where a drone is able to fly.^[50]

Aerial Photography on Light aircraft under 20 kg (44 lb). Basic Rules for non commercial flying Of a SUA (Small Unmanned Aircraft).

Article 241 Endangering safety of any person or property states that a person must not recklessly or negligently cause or permit an aircraft to endanger any person or property.

Article 94 mentions the following about small unmanned aircraft:

1. A person must not cause or permit any article or animal (whether or not attached to a parachute) to be dropped from a small unmanned aircraft so as to endanger persons or property.
2. The person in charge of a small unmanned aircraft may only fly the aircraft if reasonably satisfied that the flight can safely be made.
3. The person in charge of a small unmanned aircraft must maintain direct, unaided visual contact with the aircraft sufficient to monitor its flight path in relation to other aircraft, persons, vehicles, vessels and structures for the purpose of avoiding collisions. (500 m (1,600 ft))
4. The person in charge of a small unmanned aircraft which has a mass of more than 7 kg (15 lb) excluding its fuel but including any articles or equipment installed in or attached to the aircraft at the commencement of its flight, must not fly the aircraft:
   1. In Class A, C, D or E airspace unless the permission of the appropriate air traffic control unit has been obtained;
   2. Within an aerodrome traffic zone during the notified hours of watch of the air traffic control unit (if any) at that aerodrome unless the permission of any such air traffic control unit has been obtained;
   3. At a height of more than 400 feet above the surface
5. The person in charge of a small unmanned aircraft must not fly the aircraft for the purposes of commercial operations except in accordance with a permission granted by the CAA.

Article 95 has the following to say about small unmanned surveillance aircraft:

1. You Must not fly your aircraft over or within 150 metres of any congested Area.
2. Over or within 150 m (490 ft) of an organised open-air assembly of more than 1,000 persons.
3. Within 50 m (160 ft) of any vessel, vehicle or structure which is not under the control of the person in charge of the aircraft.
4. Within 50 m of any person, during take-off or landing, a small unmanned surveillance aircraft must not be flown within 30 m (98 ft) of any person. This does not apply to the person in charge of the small unmanned surveillance aircraft or a person under the control of the person in charge of the aircraft.

Model aircraft with a mass of more than 20 kg are termed 'Large Model Aircraft' – within the UK, large model aircraft may only be flown in accordance with an exemption from the ANO, which must be issued by the CAA.

Photographs taken at an angle are called oblique photographs. If they are taken from a low angle relative to the earth's surface, they are called low oblique and photographs taken from a high angle are called high or steep oblique.^[51]

Vertical photographs are taken straight down.^[52] They are mainly used in photogrammetry and image interpretation. Pictures that will be used in photogrammetry are traditionally taken with special large format cameras with calibrated and documented geometric properties.

Aerial photographs are often combined. Depending on their purpose, it can be done in several ways, of which a few are listed below.

• Panoramas can be made by stitching several photographs taken in different angles from one spot (e.g. with a hand held camera) or from different spots at the same angle (e.g. from a plane).
• Stereo photography techniques allow for the creation of 3D-images from several photographs of the same area taken from different spots.
• In pictometry, five rigidly mounted cameras provide one vertical and four low oblique pictures that can be used together.
• In some digital cameras, for aerial photogrammetry images from several imaging elements, sometimes with separate lenses, are geometrically corrected and combined to one image in the camera.

Vertical photographs are often used to create orthophotos, alternatively known as orthophotomaps, photographs which have been geometrically "corrected" so as to be usable as a map. In other words, an orthophoto is a simulation of a photograph taken from an infinite distance, looking straight down to nadir. Perspective must obviously be removed, but variations in terrain should also be corrected for. Multiple geometric transformations are applied to the image, depending on the perspective and terrain corrections required on a particular part of the image.

Orthophotos are commonly used in geographic information systems, such as are used by mapping agencies (e.g. Ordnance Survey) to create maps. Once the images have been aligned, or "registered", with known real-world coordinates, they can be widely deployed.

Large sets of orthophotos, typically derived from multiple sources and divided into "tiles" (each typically 256 x 256 pixels in size), are widely used in online map systems such as Google Maps. OpenStreetMap offers the use of similar orthophotos for deriving new map data. Google Earth overlays orthophotos or satellite imagery onto a digital elevation model to simulate 3D landscapes.

Aerial photography may be labeled as either "leaf-off" or on "leaf-on" to indicate whether deciduous foliage is in the photograph. Leaf-off photographs show less foliage or no foliage at all, and are used to see the ground and things on the ground more closely. Leaf-on photographs are used to measure crop health and yield. For forestry purposes, some species of trees are easier to distinguish from other kinds of trees with leaf-off photography, while other species are easier to distinguish with leaf-on photography.^[53]

With advancements in video technology, aerial video is becoming more popular. Orthogonal video is shot from aircraft mapping pipelines, crop fields, and other points of interest. Using GPS, video may be embedded with meta data and later synced with a video mapping program.

This "Spatial Multimedia" is the timely union of digital media including still photography, motion video, stereo, panoramic imagery sets, immersive media constructs, audio, and other data with location and date-time information from the GPS and other location designs.

Aerial videos are emerging Spatial Multimedia which can be used for scene understanding and object tracking. The input video is captured by low flying aerial platforms and typically consists of strong parallax from non-ground-plane structures. The integration of digital video, global positioning systems (GPS) and automated image processing will improve the accuracy and cost-effectiveness of data collection and reduction. Several different aerial platforms are under investigation for the data collection.

In film production, it is common to use a unmanned aerial vehicle with a mounted cine camera.^[54] For example, the AERIGON cinema drone is used for low aerial shots in big blockbuster movies.^[55]

Concepts and methods

Equipment and technology

Individuals, organizations, and history

• Price, Alfred (2003). Targeting the Reich: Allied Photographic Reconnaissance over Europe, 1939–1945. [S.l.]: Military Book Club. N.B.: First published 2003 by Greenhill Books, London. ISBN 0-7394-3496-9

Wikimedia Commons has media related to Aerial photography.

Look up aerial photography in Wiktionary, the free dictionary.

• Aerial Photography: An Overview on YouTube, from the Smithsonian National Air and Space Museum

Mosque in Abu Dhabi, the U.A.E.

"Sheikh Zayed Mosque" redirects here. For other uses, see Sheikh Zayed Mosque (disambiguation).

Location within the Middle East

Show map of Middle East

Sheikh Zayed Grand Mosque
جَامِع ٱلشَّيْخ زَايِد ٱلْكَبِيْر‎
View of the Sheikh Zayed Grand Mosque from the courtyard, 2018
Religion
Affiliation	Islam
Location
Location	Abu Dhabi
Country	United Arab Emirates
Location within the UAE Show map of United Arab Emirates

Coordinates 24°24′43.2″N 54°28′26.4″E / 24.412000°N 54.474000°E / 24.412000; 54.474000ArchitectureArchitectYusef AbdelkiStyleIslamicGroundbreaking1996Completed2007Construction costDhs2 billion (US$545 million)SpecificationsCapacity41,000+Length420 m (1,380 ft)Width290 m (950 ft)Dome82 domes of 7 different sizesDome height (outer)85 m (279 ft)Dome dia. (outer)32.2 m (106 ft)Minaret4Minaret height104 m (341 ft)Website

مركز جامع الشيخ زايد الكبير‎

The Sheikh Zayed Grand Mosque (Arabic: جَامِع ٱلشَّيْخ زَايِد ٱلْكَبِيْر Jāmiʿ Aš-Šaykh Zāyid Al-Kabīr) is a mosque located in Abu Dhabi, the capital city of the United Arab Emirates.^[1] It is the country's largest mosque, and is the key place of worship for daily Islamic prayers. There is a smaller replica of this mosque in Surakarta, a city in Indonesia.^[2]

The Grand Mosque was constructed between 1994 and 2007 and was inaugurated in December 2007.^[3] The building complex measures approximately 290 by 420 m (950 by 1,380 ft), covering an area of more than 12 hectares (30 acres), excluding exterior landscaping and vehicle parking. The main axis of the building is rotated about 12° south of true west, aligning it in the direction of the Kaaba in Mecca, Saudi Arabia.

The project was launched by the late president of the U.A.E., Sheikh Zayed bin Sultan Al Nahyan, who wanted to establish a structure that would unite the cultural diversity of the Islamic world with the historical and modern values of architecture and art.^[4] In 2004, Sheikh Zayed died and was buried in the courtyard of the mosque.

Sheikh Zayed Grand Mosque Center (SZGMC) offices are located in the west minarets. SZGMC manages the day-to-day operations and serves as a center of learning and discovery through its educational cultural activities and visitor programs. The library, located in the northeast minaret, serves the community with classic books and publications addressing a range of Islamic subjects: sciences, civilization, calligraphy, the arts, and coins, including some rare publications. The collection comprises material in a broad range of languages, including Arabic, English, French, Italian, Spanish, German, and Korean. For two years running, it was voted the world's second favourite landmark by TripAdvisor.^[5]

The Grand Mosque has been a significant destination for visiting foreign leaders during official state visits to the UAE. Notable visitors include Elizabeth II,^[6] the then US Vice President Joe Biden^[7] and Indian Prime Minister Narendra Modi.^[8]

The mosque was built under the guidance and supervision of Sheikh Zayed, who was buried here after his death in 2004. It features 82 domes, more than 1,000 columns, 24-carat-gold gilded chandeliers and the world's largest hand-knotted carpet. The main prayer hall is dominated by one of the largest chandeliers. The mosque was designed under the management of the Syrian architect Youssef Abdelke, and three other architectural designers from Syria who completed the design and worked on developing it, Basem Barghouti, Moataz Al-Halabi, and Imad Malas.^[9]

The mosque's architect Yusef Abdelki took inspiration from a number of sources: the Abu al-Abbas al-Mursi Mosque in Alexandria, designed by Mario Rossi in the 1920s;^[10] the Badshahi Mosque in Lahore, Pakistan;^[11] and other references of Persian, Mughal, and Indo-Islamic architecture. The dome layout and floorplan of the mosque was inspired by the Badshahi Mosque. Its archways are quintessentially Moorish, and its minarets classically Arab.

In a joint-venture between Italian contractors Impregilo and Rizzani de Eccher, more than 3,000 workers and 38 sub-contracting companies were conscripted in its construction. The mosque was completed under a second contract by a Joint Venture between ACC and Six Construct (part of Belgian company BESIX Group) between 2004 and 2007.^[12][13][14] Natural materials were chosen for much of its design and construction due to their long-lasting qualities, including marble stone, gold, semi-precious stones, crystals and ceramics. Artisans and materials came from many countries including Syria, especially from Damascus and Aleppo, and some other countries such as India, Italy, Germany, Turkey, Pakistan, Malaysia, Iran, China, United Kingdom, New Zealand, North Macedonia and the U.A.E.^{[citation needed]} The intricate flower mosaics decorating the courtyard was designed by the British artist Kevin Dean, who embraced Sheikh Zayed’s passionate vision to create a mosque that unites the world, as he chose flowers from the Middle East, such as Tulips, Lilys, and Irises. As inlays of colored marble form exuberant floral patterns that curl and twist gracefully from the edges towards the center adorn the courtyard. While the rest of the Sahan was inlaid with thousands of small pieces of white marble.

The mosque is large enough to accommodate over 40,100 worshippers, while the main prayer hall can hold over 7,000. There are two smaller prayer halls, with a capacity of 1,500 each, one of which is the women's prayer hall.^[1]

There are four minarets on the four corners of the courtyard which rise about 107 m (351 ft) in height. The courtyard, with its floral design, measures about 17,000 m² (180,000 sq ft), and is considered to be the largest example of marble mosaic in the world.^[1] The exterior and interior are adorned with white marble, giving the mosque a serene and majestic appearance. The marble is inlaid with precious stones like lapis lazuli, carnelian, amethyst, abalone shell, and mother of pearl.

Marble used in the construction included:

• Sivec from Prilep, North Macedonia was used on the external cladding (115,119 m² (1,239,130 sq ft) of cladding has been used on the mosque, including the minarets)
• Lasa from Laas, South Tyrol, Italy was used in the internal elevations
• Makrana from Makrana, India was used in the annexes and offices
• Acquabianca and Bianco P from Italy
• East White and Ming Green from China^[1]

To compare, the King Faisal Mosque of Sharjah, formerly the largest mosque in Sharjah^[15] and country, measures 10,000–12,000 m² (110,000–130,000 sq ft).^[16][17]

The carpet in the hall is considered by many ^{[by whom?]} to be the world's largest carpet made by Iran's Carpet Company and designed by Iranian artist Ali Khaliqi.^[18] It measures 5,627 m² (60,570 sq ft), and was made by around 1,200-1,300 carpet knotters. The weight of this carpet is 35 ton and is predominantly made from wool (originating from New Zealand and Iran). There are 2,268,000,000 knots within the carpet and it took approximately two years to complete.^[1]

The Grand Mosque has seven imported chandeliers from the company Faustig in Munich, Germany that incorporate millions of Swarovski crystals. The largest chandelier is the second largest known chandelier inside a mosque, the third largest in the world,^{[clarification needed]} and has a 10 m (33 ft) diameter and a 15 m (49 ft) height.^[1]

The pools along the arcades reflect the mosque's columns, which become illuminated at night. The unique lighting system was designed by lighting architects Speirs and Major Associates to reflect the phases of the moon. Beautiful bluish gray clouds are projected in lights onto the external walls and get brighter and darker according to the phase of the moon.^[19]

The 96 columns in the main prayer hall are clad with marble and inlaid with mother of pearl, one of the few places where one can see this craftsmanship.^{[citation needed]}

The 99 names (qualities or attributes) of God (Allah) are featured on the Qibla wall in traditional Kufic calligraphy, designed by the prominent UAE calligrapher — Mohammed Mandi Al Tamimi. The Qibla wall also features subtle fibre-optic lighting, which is integrated as part of the organic design.

In total, three calligraphy styles — Naskhi, Thuluth and Kufic — are used throughout the mosque and were drafted by Mohammed Mandi Al Tamimi of the UAE, Farouk Haddad of Syria and Mohammed Allam of Jordan.^[1]

•
  View from Wahat Al Karama
•
  Exterior
•
  Water mirror and columns
•
  Inner courtyard with minaret
•
  Interior of the main prayer hall
•
  The mosque in 2022
•
  The mosque at night
•
  Outside of the Sheikh Zayed Grand Mosque (left)
•
  Mosque walkway
•
  Sheikh Zayed Grand Mosque At Night

• List of mosques in the United Arab Emirates
• List of cultural property of national significance in the United Arab Emirates
  • Qasr Al Watan
  • The Founder's Memorial
• Sultan Qaboos Grand Mosque
• Sheikh Zayed Mosque, Fujairah
• Zayed bin Sultan Al Nahyan's Mosque in Stockholm, Sweden
• Emir Abdelkader Mosque

Wikimedia Commons has media related to Sheikh Zayed Mosque.

• The Official Sheikh Zayed Grand Mosque Center website
• The Official Abu Dhabi Tourism Authority website
• Shah, Pino (2020-03-14). Rood, Carrie (compiler) (ed.). Sheikh Zayed Grand Mosque: Heaven's Waiting Room. Vol. 1 (of World Heritage Series). Pharr, Texas, the U.S.A.: ArtByPino.com. ISBN 978-0-9979-9844-3. Retrieved 2020-07-09.

Tidal creek in Dubai, United Arab Emirates



Dubai Creek خُوْر دُبَيّ
Abras on the creek
Details
Location	Dubai,  United Arab Emirates
Coordinates	25°15′21″N 55°19′0″E / 25.25583°N 55.31667°E / 25.25583; 55.31667
Length	Total 24 kilometres (15 mi) of which natural length is 14 kilometres (8.7 mi)
North end	Al Shindagha
South end	Beach of Jumeirah

Dubai Creek (Arabic: خُوْر دُبَيّ, romanized: Khūr Dubayy) is a natural saltwater creek in Dubai. It extends about 9 miles (14 km) inwards and forms a natural port that has traditionally been used for trade and transport.^[1] The creek ranges from 200 to 1,200 metres (660 to 3,940 ft) in width while the average depth is about 6.5 to 7 metres (21 to 23 ft). Previously, it extended to Ras Al Khor Wildlife Sanctuary but as part of the new Business Bay Canal and Dubai Canal, it extends a further 13 km (8.1 mi)^[2] to the Persian Gulf.^[3]

In the 1950s, extensive development of the creek began, including dredging and construction of breakwaters. A number of bridges allow movement of vehicles across the creek while abras are used as taxis. The banks and route alongside the creek houses notable government, business and residential areas. A number of tourist locations and hotels are situated along the creek. The Dubai Creek, a vital waterway in the heart of the city, plays a significant role in Dubai's growth by handling the passage of more than 13,000 ships annually. As a major artery for maritime trade, it supports the city's commercial operations. Enhancements to the Creek's infrastructure are being made through a project aimed at improving safety and security measures for maritime traffic and commercial activities. These improvements are expected to strengthen the city's role as a regional hub for trade and ensure smoother, more secure operations for the numerous ships passing through each year.^[4]

History

[edit]

See also: History of Dubai and History of the United Arab Emirates

The creek in 1964

The creek in 2007

Historically, the creek divided the city into two main sections – Deira and Bur Dubai. It was along the Bur Dubai creek area that members of the Bani Yas tribe first settled in the 19th century, establishing the Al Maktoum dynasty in the city.^[5] In the early 20th century, the creek, though incapable then of supporting large scale transportation, served as a minor port for dhows coming from as far away as India or East Africa. Although it impeded the entry of ships due to current flow, the creek remained an important element in establishing the commercial position of Dubai, being the only port or harbour in the city.^[6] Dubai's pearling industry, which formed the main sector of the city's economy, was based primarily on expeditions in the creek, prior to the invention of cultured pearls in the 1930s. Fishing, also an important industry at the time, was also based along the creek, whose warm and shallow waters supported a wide variety of marine life. Dhows used for purposes of fishing were also built on the foreshore of the creek.^[7]

The importance of the creek as a site of commercial activity was a justification to introduce improvements to allow larger vessels to transit, as well as to facilitate loading and unloading activities. This led, in 1955, to a plan to develop the creek, which involved dredging shallow areas, building of breakwaters, and developing its beach to become a quay suitable for loading and unloading of cargo.^[8] The creek was first dredged in 1961 to permit 7-foot (2.1 m) draft vessels to cross through the creek at all times.^[9] The creek was dredged again in the 1960s and 1970s so that it could offer anchorage for local and coastal shipping of up to about 500 tons.^[10] The dredging opened up the creek to much more continuous traffic of merchandise, including the development of re-export, and gave Dubai an advantage over Sharjah, the other dominant trading centre in the region at the time.^[10]

Al Maktoum Bridge, the first bridge connecting Bur Dubai and Deira was constructed in 1963. Although the importance of the creek as a port has diminished with the development of the Jebel Ali Port, smaller facilities, such as Port Saeed, continue to exist along the creek, providing porting to traders from the region and the subcontinent.

2000s

[edit]

In September 2007, a Dhs. 484 million (US$ 132 million) extension of the creek was finished, which now ends just south of the Metropolitan Hotel and projects on Shaikh Zayed Road. A final 2.2-kilometre extension, called the Dubai Water Canal was inaugurated 9 November 2016, crossing Shaikh Zayed Road in a northerly route, passing through Safa Park and then through Jumeirah 2. The channel is expected to continue through Jumeirah Beach Park where it will reach the shores of the Persian Gulf.^[11] The extension is part of the Dubai's Business Bay development. Additionally, a new project consisting of seven islands known as Dubai Creek Harbour was proposed to be built on Dubai Creek. The centerpiece of this project would be the Dubai Creek Tower, which is set to become the tallest building in the world. Three additional bridges are being planned for Dubai Creek, which are the Seventh Crossing, the Al Shindagha Bridge, and the Fifth Bridge.^[12][13]

The Dubai Festival City Mall on Dubai Creek opened in 2007. Mohammed Bin Rashid Library is being built in the Al Jaddaf area on the Creek. Dhows are constructed in this area too on the bankside. The Green Line of the Dubai Metro terminates at the Dubai Creek metro station. Close to this metro station is the Al Jaddaf Marine Station, operating ferries on the Creek, including across the Creek to the Dubai Festival City Mall.

The Dubai Creek Harbour development is set to launch in 2025, home to Dubai Creek Tower, with residential units and parks constructed.^[14]

Route

[edit]

Original

[edit]

The creek's initial inlet into mainland Dubai is along the areas of Deira Corniche and Al Ras in eastern Dubai and along the area of Al Shindagha in western Dubai. It then progresses south-eastward through the mainland, passing through Port Saeed and Dubai Creek Park. The creek's natural ending is at the Ras Al Khor Wildlife Sanctuary, 14 kilometres (8.7 mi) from its origin at the Persian Gulf. The traditional form of transport between the eastern and western sections of Dubai via the creek was through abras, which continue to operate in Dubai. In addition, the eastern and western sections are linked via four bridges (Al Maktoum Bridge, Al Garhoud Bridge, Business Bay Crossing, and Floating Bridge) and one tunnel (Al Shindagha Tunnel).

•
  Original route of Dubai Creek is highlighted in blue. The new extension is highlighted in red.
•
  Coast of Dubai from the International Space Station. Dubai Creek is visible.
•
  Dubai International Airport and Dubai Creek figure prominently in this photograph from the International Space Station.

Extensions

[edit]

25°16′02″N 55°18′24″E / 25.267236°N 55.306675°E / 25.267236; 55.306675)

The creek has been extended by 13 km (8.1 mi) through Business Bay, Dubai Canal and through Jumeirah into the Arabian Gulf.

Buildings and structures along Dubai creek. Hover and click on the map and then on the points for details.

Including the most remarkable buildings alongside the Deira side of the Creek are the Deira Twin Towers, the old Dubai Creek Tower, Sheraton Dubai Creek, National Bank of Dubai, and Chamber of Commerce.^[15] On the other side of Al Maktoum Bridge along Dubai Creek is Dubai Creek Park, one of the largest parks in Dubai.^[16]

The creek is also home to the Dubai Creek Golf & Yacht Club, comprising an 18-hole tournament golf course, clubhouses, residential development, and the Park Hyatt hotel.

Present crossings, in order from northwest to southeast

• Al Shindagha Tunnel
• Al Maktoum Bridge
• Floating Bridge (temporary; to be replaced by the "Dubai Smile" in the future)
• Al Garhoud Bridge
• Business Bay Crossing
• Infinity Bridge

Future/planned crossings

• Dubai Smile (to replace the Floating Bridge)
• Sheikh Rashid bin Saeed Crossing (to link Al Jaddaf and Bur Dubai)

Port Saeed

Abra station in Deira

• Port Saeed
• Dubai Creek Harbour
• Al Jaddaf Marine Station
• Business Bay Marina

Bibliography

• Hammad, Ahmed (June 2019). "Business Bay – Dubai Creek Extension -Construction Management, Challenges and Results. Part II – Project Details" (PDF). Journal of Engineering and Architecture. 7 (1): 100–109. doi:10.15640/jea.v7n1a11 (inactive 12 July 2025). eISSN 2334-2994. ISSN 2334-2986. S2CID 191180349. Archived from the original on 6 March 2020.cite journal: CS1 maint: DOI inactive as of July 2025 (link)
• Gupte, Pranay (2011). Dubai: The Making of a Megapolis. Viking. Penguin Books India. ISBN 9780670085170.

• Ahmad Makia (April 2015) "Dubai Creek as an Island City-State: Free Zones, Canals, and City Doppelgängers." Avery Review:7
