255 / 601
E32
Base End Run Cabinets
Base Cabinets
Base End Run
Cabinets
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
PE
Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI
Matching Interior
DE Integrated Decorative End
RD Reduced Depth
WR Wide Bottom Rail
GD Glass Doors
RTK Recessed Toe Kick
RTKP Recessed Toe Kick Peninsula
VTK Void Toe Kick
Material dimensions listed may vary slightly from actual dimensions of the product.
Specifications subject to change without notice.
BEOS 12
24
code
width
depth
Base Corner Angle
BCA24 BUTT
• One adjustable shelf
• Can be installed on either right or left end
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
l
PE
l
APC
APFC
FPEB
l
MI
DE
RD
WR
l
GD
RTK
RTKP
l
VTK
34 ½˝
23 / ˝
23 / ˝
23 / ˝
17 / ˝
23 / ˝
Base End Corner
BEC24
• One adjustable shelf
• Can be installed on either right or left end
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
l
PE
l
APC
APFC
FPEB
l
MI
DE
RD
WR
l
GD
RTK
RTKP
l
VTK
34
1
/
2
˝
135°
23
7
/
8
˝
23
7
/
8
˝
23
7
/
8
˝
23
7
/
8
˝
23
9
/
16
˝
67.5°
18
5
/
16
Base End Angle
Specify R or L
BEA12 R or L
• Right shown
• Two adjustable shelves
• Full-height door
• One optional tray divider available in center
location only
I
Recessed Toe Kick (RTK) available hinge side
only
I
Minimum Reduced Depth (RD) is 18˝
I
Wide Rail Plain only (WR)
I
Integrated Decorative End (DE) available on
12˝ deep side only
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
I
DE
I
RD
I
WR
l
GD
I
RTK
RTKP
l
VTK
34
1
/
2
˝
24˝
12˝ 12˝
12˝
12˝
24˝
17˝
45°
