253 / 601
E30
Peninsula Base Corner Cabinets
Base Cabinets
Peninsula Base
Corner Cabinets
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
PE
Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI
Matching Interior
RD Reduced Depth
IF
Inverted Frame
TWR Top Wide Rail
WR Wide Bottom Rail
XS
Extended Stile
GD Glass Doors
RTK Recessed Toe Kick
RTKP Recessed Toe Kick Peninsula
VTK Void Toe Kick
Material dimensions may vary slightly from actual dimensions of the product.
Specifications subject to change without notice.
PEZR 36 R L
code
width
kitchen
side hing-
ing
rear frame
position
Peninsula Easy Reach
Specify R or L Rear Frame Position
Iu
%
PEZR33 RR or L
Iu
%
PEZR33 LR or L
i
PEZR36 RR or L
i
PEZR36 LR or L
• One fixed shelf
• Frame opening, from left to right edge is
10 1/2˝ for EZR33 and 14 3/4˝ for EZR36
• Doors are profiled on one long and two short
edges and are connected with hinges
• The first R or L designates kitchen side door
hinging
• The second R or L designates rear (peninsula)
frame position
• Butt doors on peninsula side
• Toe kick is detachable
• 31˝ door clearance recommended for
delivery
•
Note:
Kitchen side does
not
include Soft-Close feature.
Peninsula side doors feature Soft-Close hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
RD
IF
TWR
WR
l
XS
I
GD
RTK
RTKP
VTK
34
1
/
2
˝
24˝
33˝, 36˝
33˝, 36˝
33 / ˝
6 / ˝, 8 / ˝
33˝
36˝
33˝, 36˝
24˝
All dimensions are to
outside of frame
I
Glass doors
not
available on kitchen side
u
Huntley, Scarbourough and Veranda doors
will have a solid, recessed flat panel on
kitchen side. Castlewood doors will have a
veneer, recessed flat panel on kitchen side
i
Not
available with Aluminum Frame glass
doors on kitchen side
%
Woodgrain Laminate door styles will be
supplied as vertical grain slabs
Peninsula Easy Reach Wood Super Susan
Specify R or L Rear Frame Position
Iu
%
PEZR33 RR or L•WSS
Iu
%
PEZR33 LR or L•WSS
i
PEZR36 RR or L•WSS
i
PEZR36 LR or L•WSS
• Two pie-cut shelves rotate individually
• EZR33 has 28˝ diameter shelves; EZR36 has
32˝ diameter shelves
• Rotating shelves are attached to cabinet floor
and fixed shelf
• Shelves rotate independently
• Lazy Susan
cannot
be turned from peninsula
side with kitchen side doors in closed
position
• Frame opening, from left to right edge is
10 1/2˝ for EZR33 and 14 3/4˝ for EZR36
• Doors are profiled on one long and two short
edges and are connected with hinges
• The first R or L designates kitchen side door hinging
• The second R or L designates rear (peninsula) frame
position
• Butt doors on peninsula side
• 31˝ door clearance recommended for delivery
• Toe kick is detachable
•
Note:
Kitchen side does
not
include Soft-Close feature.
Peninsula side doors feature Soft-Close hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
RD
IF
TWR
WR
l
XS
I
GD
RTK
v
RTKP
VTK
34
1
/
2
˝
24˝
33˝, 36˝
33˝, 36˝
33 / ˝
6 / ˝, 8 / ˝
33˝
36˝
33˝, 36˝
24˝
All dimensions are to
outside of frame
I
Glass doors
not
available on kitchen side
u
Huntley, Scarbourough and Veranda doors
will have a solid, recessed flat panel on
kitchen side. Castlewood doors will have a
veneer, recessed flat panel on kitchen side
%
Woodgrain Laminate door styles will be
supplied as vertical grain slabs
i
Not
available with Aluminum Frame glass
doors on kitchen side
