181 / 601
D22
Wall End Run Cabinets
Wall Cabinets
Wall Corner Angle Double Panel 54˝ H
WCADP1254 R or L
• Adjustable shelves
• Shelves shipped separately
• Available in full overlay door styles only
•
Not
available in mitered door styles
•
Not
available in slab door styles
•
Not
available in Woodgrain Laminate door
styles
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB, CVGR)
not
available
I
Glass doors available for top section only
I
A solid raised center panel machined to match the
veneer raised center panel will be supplied when glass
doors are selected on full overlay veneer raised panel
door styles.
I
Not
available with Mullion glass doors (GD) option
l
PE
l
APC
APFC
FPEB
l
MI
DE
RD
ID
XS
I
GD
12˝
12˝
54˝
12˝
12˝
Wall End Corner
Two shelves
WEC1230
WEC1233
Three shelves
WEC1236
WEC1239
WEC1242
• Adjustable shelves
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• Doors are square except full overlay arch
door styles. Laminate door styles will always
be square. Huntley, Scarbourough and
Veranda doors will have a solid, recessed flat
panel.
l
PE
l
APC
APFC
FPEB
l
MI
DE
RD
ID
XS
GD
12˝
30˝
33˝
36˝
39˝
42˝
12˝
12˝
12˝
11
1
/
2
˝
Wall Z-Angle
Specify R or L
Two shelves
30” High
WZA1230 R or L
Three shelves
42” High
WZA1242 R or L
• Right shown
• Adjustable shelves
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
•
Not
available in High-Gloss Laminate,
Laminate or Woodgrain Laminate door styles
I
Reduced Depth (RD) available to 10” without
shelves; 10 5/8” with shelves
• Doors will
not
receive pegs when ordered in
Sturbridge door style
• Outside profile will contain eased edges and will
not
match straight doors for Newburgh door styles
•
Not
available in Burnaby, Fielding, Fox Hill Roman
(Half & Full), Fox Hill Square (Half & Full), Grange,
Hayward Oak, Holace, Huntley, Jackson, Jasper,
Kensie, Lansing, Sarasota, Scarbourough, Torrington
& Veranda
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
I
RD
ID
XS
GD
12˝
12˝
3˝
3˝
8
1
/
2
˝
6˝
12˝
30˝
42˝
6˝
Wall End Angle
Specify R or L
One shelf
WEA1224 R or L
Two shelves
WEA1230 R or L
WEA1233 R or L
Three shelves
WEA1236 R or L
WEA1239 R or L
WEA1242 R or L
• Designed to be a transition cabinet between
a 12˝ deep wall cabinet and a 24˝ deep tall or
Wall Refrigerator cabinet
• Right shown
• Adjustable shelves
I
Minimum Reduced Depth (RD) is 18˝
I
Integrated Decorative End (DE) available on
12˝ deep side only
•
Note:
Full overlay door styles use a 1/2” overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
I
DE
I
RD
ID
XS
l
GD
12˝
45°
17˝
24˝
12˝
24˝
30˝
33˝
36˝
39˝
42˝
