J4
Passport Cabinets
Passport cabinetry is available in 1/2” overlay door styles only.
Passport Cabinets
Passport Sink Front
ASF30
ASF36
• Includes floor; shipped loose
• UTK
not
available
• Unit is
not
trimmable
• Includes a Touch-Up Kit (TUK)
PE
l
APC
APFC
FPEB
MI
OE
RD
IF
TWR
l
XS
l
GD
RTK
32 ½˝
Passport Plumbing Skirt and Sink Collar Usage
ASRB
ABSR
24˝
12˝
27˝
34˝
5 ½˝
1 ½˝
Side view
For proper fit, install WSK or VSK on base
and tall cabinets next to ABSR
Top view
12˝
24˝
Passport Sink Collar
ASRB30
ASRB36
• Designed for use with ABSR
• For use with sink or cooktop
• Includes a Touch-Up Kit (TUK)
l
PE
l
APC
l
APFC
l
FPEB
MI
OE
l
RD
IF
TWR
l
XS
GD
RTK
5 ½˝
24˝
Passport Plumbing Skirt
ABSR30
ABSR36
• Install with back to wall, creates a 12” deep
knee space
• Removable front
• Water lines and drains including P-Trap
must
not
be installed any more than 6” from wall
• Be sure to check your local Accessible Design
codes for necessary clearances
• Cabinet Front Only (CFO) option is available
for clearance flexibility
• Includes a Touch-Up Kit (TUK)
• Painted hardwood supplied for EverCore™
•
Note:
Adjacent cabinets
must
have skins or
Furniture Plywood Ends (FPEB) applied
l
PE
l
APC
l
APFC
l
FPEB
MI
OE
l
RD
IF
TWR
l
XS
GD
RTK
27˝
12˝
Passport Base Microwave
Opening Width
ABMW21
18”
ABMW24
21”
ABMW27
24”
• One standard drawer
• Opening height 14”
• Designed for countertop style microwaves
l
PE
l
APC
l
APFC
l
FPEB
l
MI
OE
l
RD
IF
TWR
l
XS
GD
l
RTK
32 ½˝
24˝
