J1
Passport Cabinets
Passport cabinetry is available in 1/2” overlay door styles only.
Passport Cabinets
Passport Cabinets
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
PE
Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI
Matching Interior
OE Operational End
RD Reduced Depth
IF
Inverted Frame
TWR Top Wide Rail
XS
Extended Stile
GD Glass Doors
RTK Recessed Toe Kick
Material dimensions listed may vary slightly from actual dimensions of the product.
Specifications subject to change without notice.
AU 18 12 84
code
width depth height
Passport Series
Oven accessible
from seated
position
Standard 84”
installation
Install cooktops
at any height
Special sink base
conceals plumbing
Raised dishwasher enclosure for
easier loading & unloading
9˝ high, 6˝ deep
toe kick allows
wheelchair access
32 ½˝ cabinet height
Unique tambour
unit for
unimpaired access
Fully lighted
interior option
Recommendations for Maximum Accessibility:
• Order 36˝ high wall cabinets installed at 82˝ or 84˝ height
• Minimize use of Base cabinets with doors, select drawer or tambour cabinets
Door Style Availability:
• Passport SKU’s are available in all 1/2˝ overlay door styles and are now available with your choice of Whisper Touch™ or knife hinges (see
door style availability below). Whisper Touch™ hinge features an integrated mechanism that closes doors softly and quietly and is
adjustable six ways for perfect alignment. Knife hinge, which open 180 degrees, are recommended to accommodate wheelchair users.
• 1/2” overlay door styles with Whisper Touch™ hinge:
• 1/2” overlay door styles with knife hinge:
Deveron–Half
Hanover Square
Gentry Cherry Roman–Half
Fox Ridge Roman–Half
Montclair Roman–Half
Gentry Cherry Square–Half
Fox Ridge Square–Half
Montclair Square–Half
Hanover Roman
Gentry Roman–Half
Wickstrom Roman
Hanover Square
Gentry Square–Half
Wickstrom Square
Wickstrom Roman
Hanover Roman
Wickstrom Square
Design Recommendations:
• Consider specifying Under Cabinet Panels for wall cabinets available for wheelchair users
