2016 KraftMaid Spec Book - Lowes - page 341

G21
Vanity Cabinets
Vanity Cabinets
Vanity Utility Cabinet 18” Deep
Specify R or L
84” High
i
VU91884 R or L
VU121884 R or L
VU151884 R or L
VU181884 R or L
VU211884 R or L
VU241884 R or L
VU241884 BUTT
VU271884 (Butt)
VU301884 BUTT
VU331884 BUTT
VU361884 BUTT
87” High
i
VU91887 R or L
VU121887 R or L
VU151887 R or L
VU181887 R or L
VU211887 R or L
VU241887 R or L
VU241887 BUTT
VU271887 (Butt)
VU301887 BUTT
VU331887 BUTT
VU361887 BUTT
90” High
i
VU91890 R or L
VU121890 R or L
VU151890 R or L
VU181890 R or L
VU211890 R or L
VU241890 R or L
VU241890 BUTT
VU271890 (Butt)
VU301890 BUTT
VU331890 BUTT
VU361890 BUTT
93” High
i
VU91893 R or L
VU121893 R or L
VU151893 R or L
VU181893 R or L
VU211893 R or L
VU241893 R or L
VU241893 BUTT
VU271893 (Butt)
VU301893 BUTT
VU331893 BUTT
VU361893 BUTT
96” High
i
VU91896 R or L
VU121896 R or L
VU151896 R or L
VU181896 R or L
VU211896 R or L
VU241896 R or L
VU241896 BUTT
VU271896 (Butt)
VU301896 BUTT
VU331896 BUTT
VU361896 BUTT
• Includes adjustable shelves in upper section:
84” & 87” high—one shelf; 90” & 93” high—
two shelves; 96” high—three shelves
• Factory installed Roll-out Trays (ROT) are
not
available on Utility Cabinets wider than 24˝
• Toe kick is shipped separately on 93˝ & 96˝
high cabinets
I
Glass doors available for top doors only
I
When Inverted Frame (IF) is chosen in arched
door styles, VU18, VU24, VU24BUTT and
VU36 cabinets will have arched doors. All
other cabinet sizes will be supplied with
square doors
I
Operational End (OE) is
not
available with
Increased Depth (ID) or Reduced Depth (RD)
options
I
Wide Bottom Rail (WR) and Recessed Toe Kick (RTK)
not
available on 93” & 96” high cabinets
I
Void Toe Kick (VTK) is
not
available on 93” and 96” high
cabinets
Not
available in Hollin door styles
Note:
Shelf Kit (SK) for lower section
must
be ordered
separately; see Shelving section of this book
Remember to order a 3/16” skin (WSK) for the
exposed ends of 93” & 96” high cabinets to
conceal the seam between the loose toe kick
and the cabinet.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
OE
l
RD
l
ID
I
IF
TWR
I
WR
l
XS
I
GD
I
RTK
I
VTK
84˝
87˝
90˝
93˝
96˝
18˝
VU9-24
18˝
23 ½˝
27˝
30˝
33˝
36˝
84˝
87˝
90˝
93˝
96˝
23 ½˝
27˝
30˝
33˝
36˝
VU24 BUTT -
VU27 BUTT
18˝
84˝
87˝
90˝
93˝
96˝
23 ½˝
27˝
30˝
33˝
36˝
VU30-36
New
i
Doors are square except full overlay arch door
styles. Laminate doors styles will always be
square. Hathaway, Southington and Vienna
doors will have a solid, recessed flat panel
Gray color coding indicates new product, size or code.
