G24
Vanity Cabinets
Vanity Cabinets
Vanity Utility Cabinet 21” Deep w/Deluxe Dovetailed Roll-out Tray
Specify R or L
84” High
VU152184 R or L•4DXROT
VU182184 R or L•4DXROT
VU212184 R or L•4DXROT
VU242184 R or L•4DXROT
VU242184 BUTT•4DXROT
VU272184 (Butt)•4DXROT
VU302184 BUTT•4DXROT
VU332184 BUTT•4DXROT
VU362184 BUTT•4DXROT
87” High
VU152187 R or L•4DXROT
VU182187 R or L•4DXROT
VU212187 R or L•4DXROT
VU242187 R or L•4DXROT
VU242187 BUTT•4DXROT
VU272187 (Butt)•4DXROT
VU302187 BUTT•4DXROT
VU332187 BUTT•4DXROT
VU362187 BUTT•4DXROT
90” High
VU152190 R or L•4DXROT
VU182190 R or L•4DXROT
VU212190 R or L•4DXROT
VU242190 R or L•4DXROT
VU242190 BUTT•4DXROT
VU272190 (Butt)•4DXROT
VU302190 BUTT•4DXROT
VU332190 BUTT•4DXROT
VU362190 BUTT•4DXROT
93” High
VU152193 R or L•4DXROT
VU182193 R or L•4DXROT
VU212193 R or L•4DXROT
VU242193 R or L•4DXROT
VU242193 BUTT•4DXROT
VU272193 (Butt)•4DXROT
VU302193 BUTT•4DXROT
VU332193 BUTT•4DXROT
VU362193 BUTT•4DXROT
96” High
VU152196 R or L•4DXROT
VU182196 R or L•4DXROT
VU212196 R or L•4DXROT
VU242196 R or L•4DXROT
VU242196 BUTT•4DXROT
VU272196 (Butt)•4DXROT
VU302196 BUTT•4DXROT
VU332196 BUTT•4DXROT
VU362196 BUTT•4DXROT
• Four adjustable Roll-out Trays (ROT)
included in lower section
• Includes adjustable shelves in upper
section: 84” & 87” high—one shelf; 90” &
93” high—two shelves; 96” high—three
shelves
• Roll-out Trays (ROT) shipped separately
on 27˝–36˝ wide units
• Roll-out Trays (ROT)
cannot
be included
when a Reduced Depth (RD) option of
less than 18” is selected
• 27˝–36˝ wide units
not
available with
Reduced Depth (RD)
• Toe kick is shipped separately on 93˝ &
96˝ high cabinets
I
When Inverted Frame (IF) is chosen in arched door
styles, VU18, VU24, VU24BUTT and VU36 cabinets
will have arched doors. All other cabinet sizes will
be supplied with square doors
I
Wide Bottom Rail (WR) and Recessed Toe Kick
(RTK)
not
available on 93” & 96” high cabinets
I
Glass doors available for top doors only
I
Void Toe Kick (VTK) is
not
available on 93” and 96”
high cabinets
•
Not
available in Hollin door styles
Remember to remove the white plastic
”feet” from the bottom of all tall cabinets
before installation. Their sole purpose is
to protect the floor after the cabinets are unboxed.
Leaving them on will result in an uneven
installation.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
OE
l
RD
l
ID
I
IF
TWR
I
WR
l
XS
I
GD
I
RTK
I
VTK
VU15-24
VU24-36
21˝
21˝
84˝
87˝
90˝
93˝
96˝
23 ½˝
27˝
30˝
33˝
36˝
84˝
87˝
90˝
93˝
96˝
23 ½˝
27˝
30˝
33˝
36˝
New
Gray color coding indicates new product, size or code.
Vanity Wall Cabinet
Specify R or L
4 5/8” Deep
30” High
VW120430 R or L
VW150430 R or L
VW240430
VW270430
36” High
VW120436 R or L
VW150436 R or L
VW240436
VW270436
8” Deep
30” High
VW120830 R or L
VW150830 R or L
VW240830
VW270830
36” High
VW120836 R or L
VW150836 R or L
VW240836
VW270836
• Three adjustable 1/2˝ thick shelves
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
OE
RD
ID
IF
TWR
WR
l
XS
l
GD
RTK
VTK
30˝
36˝
4 / ˝, 8˝
4 / ˝, 8˝
