G2
Vanity Cabinets
Vanity Cabinets
U-Shaped Deluxe Roll-out Tray
Field Installation
18” Deep
UDXROT24 .18
UDXROT30 .18
UDXROT36 .18
21” Deep
UDXROT24 .21
UDXROT30 .21
UDXROT36 .21
Factory Installation
18”-21” Deep
1UDXROT
• Designed specifically for Wall Hung
Vanity (WHVOR, WHVC and
WHVCD) cabinets
• Full extension runner, pulls out past
the face frame
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
GD
RTK
VTK
UDXROT UNIT
D
C
B
A
12 ˝
UDXROT24.21
UDXROT24.18
UDXROT30.21
UDXROT30.18
UDXROT36.21
UDXROT36.18
¼
15 ˝¼
18 ˝¼
12 ˝¼
15 ˝¼
18 ˝¼
7 ⅓ ˝
10 ⅓ ˝
13 ⅓ ˝
7 ⅓ ˝
10 ⅓ ˝
13 ⅓ ˝
5 ⁄
˝
8 ⁄
˝
11 ⁄
˝
5 ⁄
˝
8 ⁄
˝
11 ⁄
˝
17 ⁄
˝
17 ⁄
˝
17 ⁄
˝
14 ¾˝
14 ¾˝
14 ¾˝
1˝
DIM B
DIM A
3˝
4˝
DIM D
DIM C
FRONT VIEW
TOP VIEW
BACK VIEW
19 / ˝
(30
˝
Unit)
25 / ˝
(36
˝
Unit)
31 / ˝
(42
˝
Unit)
3 / ˝
7˝
(6 / ˝
Interior Height)
3 / ˝
7˝
5¼˝
19 / ˝
(30
˝
Unit)
25 / ˝
(36
˝
Unit)
31 / ˝
(42
˝
Unit)
New
Gray color coding indicates new product, size or code.
Wall Hung Vanity Drawer
18” Deep
WHVD3018
WHVD3618
21” Deep
WHVD3021
WHVD3621
• False front top
• 7” U-shaped bottom drawer
scooped to 3” in the back
• 11/16” full plywood back panel
• Installation instructions included
PE
APC
v
APFC
FPEB
l
MI
DE
OE
RD
ID
IF
TWR
WR
XS
GD
RTK
VTK
20 ½˝
18˝ 21˝
30˝ 36˝
New
Gray color coding indicates new product, size or code.
Vanity Sink Base Single Door
Specify R or L
31 1/2” High, 18˝ Deep
VSB181831 R or L
VSB211831 R or L
31 1/2” High, 21˝ Deep
VSB182131 R or L
VSB212131 R or L
34 1/2” High, 16˝ Deep
n
VSB181634 R or L
n
VSB211634 R or L
34 1/2” High, 18˝ Deep
VSB181834 R or L
VSB211834 R or L
34 1/2” High, 21˝ Deep
VSB182134 R or L
VSB212134 R or L
• Single door and drawer front
• Optional Utensil Trays (UT and
SUT) are available
I
Operational End (OE) is
not
available with Reduced Depth (RD)
options
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
OE
l
RD
ID
IF
l
TWR
l
WR
l
XS
l
GD
l
RTK
l
VTK
18˝, 21˝
31 ½˝
34 ½˝
n
Not
available with Operational End Door
(OE) option
Gray color coding indicates new product, size or code.
