F31
Tall Cabinet Accessories
Tall Cabinets
Toe Kick
Black
=
BLTK8
• 1/8” thick
hardboard, 4 1/2”
high
s
MTK8
• 1/8” thick
hardboard, 4 1/2”
high, laminated with
matching Viraguard
Aluminum finish
MTK8 •A
• 1/16˝ thick flexible
laminate, 4 1/2˝ high
Stainless finish
MTK8 •S
• 1/16˝ thick flexible
laminate, 4 1/2˝ high
in
WMTK8
• 3/16” thick wood
veneer, 4 1/2” high,
to match
• Edges are unfinished
• Field installation only
•
Note
: Matching toe kick is
not
automatically
supplied with cabinets. It
must
be ordered as
a separate item
Apply Quarter Round molding
(QR8) at the base of Matching Toe
Kicks or Wood Matching Toe Kicks
(MTK8 or WMTK8) for a nice, finished look.
PE
APC
APFC
FPEB
MI
RD
ID
WR
96˝
=
Painted hardwood supplied for EverCore™
s
Not
available in Morrisbrook; Durham and
Meredith supplied quartersawn
i
Painted hardwood supplied for EverCore™
and Laminate
n
Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
Diagonal Installation of Standard Tall Cabinets
CTM8
Solid Wood Molding
CTEP84
Note:
Fillers are always recommended at both sides of cabinet
junction points to allow for wall variations and drawer clearances.
Corner Tall End Panel (CTEP) and Corner Tall Molding (CTM8) are
sold separately
Cabinet Width “A”
Cabinet Depth “B” Wall Dimensions “C” Wall Dimensions “D” Cabinet Depth “B” Wall Dimensions “C” Wall Dimensions “D”
15”
12”
18 ¼”
23 ¼
”
24”
24 ⅜
”
34 ⅝
”
18”
12”
20 ⅜”
25 ⅜
”
24”
26 ¾
”
36 ¾
”
24”
12”
24 ⅝”
29 ⅝
”
24”
31”
40 ⁄
”
27”
N/A
N/A
N/A
24”
33 ⅛
”
43 ⁄
”
30”
12”
28 ⅞”
33 ⅞
”
24”
35 ¼
”
45 ⁄
”
33”
N/A
N/A
N/A
24”
37 ⅜
”
47 ⁄
”
36”
12”
33 ⅛”
38 ⅛
”
24”
39 ½
”
49 ½
”
Optional Wall
Option #1
D
C
D C
B
A
Option #2
D
D
B
A
