F30
Tall Cabinet Accessories
Tall Cabinets
Matching Tall End Panel–Square Edges
60 1/2” High
MTEP1260 S
MTEP2460 S
84” High
MTEP1284 S
MTEP2484 S
87” High
MTEP1287 S
MTEP2487 S
90” High
MTEP1290 S
MTEP2490 S
93” High
MTEP1293 S
MTEP2493 S
96” High
MTEP1296 S
MTEP2496 S
• 3/4˝ thick panel with square edge front and
back
• Inside of matching panel bottom rail will line
up with inside bottom rail of door
• Field installation only
• Reversible, may be used on either right or left
end
• No frame recess dado
•
Not
available in Morrisbrook Oak Square
•
Not
available in High-Gloss Laminate, Laminate or
Woodgrain Laminate door styles
•
Not
available in mitered door styles; use End Panel–
Mitered
•
Not
available in slab door styles
I
Wide Bottom Rail—field notch for toe kick
PE
APC
APFC
FPEB
MI
RD
ID
I
WR
Will not fit flush against 1/2˝ end panel,
a 3/16˝ shim is recommended
60 ½˝
11 / ˝
23 / ˝
11 / ˝
23 / ˝
84˝
87˝
90˝
93˝
96˝
Furniture Matching Tall End Panel
Specify R or L
60 1/2” High
i
FMTEP1260 R or L
i
FMTEP2460 R or L
84” High
FMTEP1284 R or L
FMTEP2484 R or L
87” High
FMTEP1287 R or L
FMTEP2487 R or L
90” High
FMTEP1290 R or L
FMTEP2490 R or L
93” High
FMTEP1293 R or L
FMTEP2493 R or L
96” High
FMTEP1296 R or L
FMTEP2496 R or L
• 3/4” thick panel with matching door edge
profile on front edge only
• Inside of matching panel bottom rail will line
up with inside bottom rail of door
• Left shown
• Field installation only
• For use with Furniture Plywood Ends (FPEB)—flush ends
•
Not
available in Morrisbrook Oak Square
•
Not
available in High-Gloss Laminate, Laminate or
Woodgrain Laminate door styles
•
Not
available in mitered door styles; use End Panel–
Mitered
•
Not
available in slab door styles
I
Wide Bottom Rail—field notch for toe kick
PE
APC
APFC
FPEB
MI
RD
ID
I
WR
60 ½˝
11 / ˝
23 / ˝
11 / ˝
23 / ˝
84˝
87˝
90˝
93˝
96˝
i
Painted hardwood supplied for EverCore™
Matching Tall End Panel–Mitered
60 1/2” High
M•MTEP1260
M•MTEP2460
84” High
M•MTEP1284
M•MTEP2484
87” High
M•MTEP1287
M•MTEP2487
90” High
M•MTEP1290
M•MTEP2490
93” High
M•MTEP1293
M•MTEP2493
96” High
M•MTEP1296
M•MTEP2496
• 3/4˝ thick panel with matching door edge
profile on four sides
• Inside of matching panel bottom rail will line
up with inside bottom rail of door
• Field installation only
• Reversible, may be used on either right or left
end
• Top, bottom and toe kick shipped separately
• Available in mitered door styles only
•
Not
available in High-Gloss Laminate, Laminate or
Woodgrain Laminate door styles
PE
APC
APFC
FPEB
MI
RD
ID
WR
60 ½˝
Will not fit flush against 1/2˝ end panel,
a 3/16˝ shim is recommended
11 / ˝
23 / ˝
11 / ˝
23 / ˝
84˝
87˝
90˝
93˝
96˝
Corner Tall End Panel
Wood Veneer
Width x Height x Thickness
WCTEP84
23 1/8” x 84” x 1/2”
WCTEP87
23 1/8” x 87” x 1/2”
WCTEP90
23 1/8” x 90” x 1/2”
WCTEP93
23 1/8” x 93˝ x 1/2”
WCTEP96
23 1/8” x 96” x 1/2”
• See Option #2 in Diagonal Installation of
Standard Tall Cabinets in the back of the Tall
Cabinets section
• Painted hardwood supplied for EverCore™
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
• Corner Tall End Panel (CTEP) and Corner Tall
Molding (CTM8) are sold separately
PE
l
APC
APFC
FPEB
MI
RD
ID
WR
23
1
/
8
˝
CTEP
CTM8
CTEP
84˝
87˝
90˝
93˝
96˝
