D34
Wall Hoods
Wall Cabinets
Peninsula Wall Hood Classic Chimney
Plain
30 5/8” High
PWHCC302830 •P
PWHCC363330 •P
PWHCC423330 •P
42 5/8” High
PWHCC302842 •P
PWHCC363342 •P
PWHCC423342 •P
54 5/8” High
PWHCC302854 •P
PWHCC363354 •P
PWHCC423354 •P
Beaded Panel
30 5/8” High
PWHCC302830 •BE
PWHCC363330 •BE
PWHCC423330 •BE
42 5/8” High
PWHCC302842 •BE
PWHCC363342 •BE
PWHCC423342 •BE
54 5/8” High
PWHCC302854 •BE
PWHCC363354 •BE
PWHCC423354 •BE
• Solid wood/wood veneer
construction
• Check local building codes for
required clearances between the
Wall Hood and cooking surface
• A 3˝ space is recommended on
the right and left side of this unit
before beginning the adjacent
cabinet runs
• 30 5/8˝ high hoods are designed
for use with 8 foot ceilings
• 42 5/8˝ high hoods are designed
for use with 9 ft. ceilings
• 54 5/8˝ high hoods are designed
for use with 10 ft. ceilings
• Lower molding matches Beaded
Panel Molding (BPM8) profile, other molding
matches Soffit Crown Molding profile (SCM8)
• Chimney section shipped separately
• Will accept optional onlays, ordered
separately; see Molding Accents section of this
book
•
Not
designed to be used with a soffit
• Painted hardwood supplied for EverCore™ and
Laminate
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
•
Not
available in Morrisbrook; Durham and
Meredith supplied plain sawn
• 30˝ wide requires Wall Hood Component
Package “K”, located before the Wall Hood
Designs in this section
• 36˝–42˝ wide requires Wall Hood Component
Package “H” or “O”, located before the Wall
Hood Designs in this section
•
Note:
Cabinetry and appliances located
below these Wall Hoods
must
be pulled to a
minimum of 27˝deep and a maximum of 30˝
deep for improved function
•
Note:
Wall hood
must
be securely anchored to
ceiling
Apply your molding of choice at the
ceiling along the top edge of the
Wall Hood Chimney to present a
finished look or to coordinate with
adjacent cabinetry.A beaded styled hood may
be selected to coordinate with
beaded/v-grooved paneling and doors, but is
not
required.
PE
v
APC
APFC
FPEB
MI
DE
RD
ID
XS
XSG
GD
Opening Sizes
Cabinet
Top Width
Top Depth BottomWidth Bottom Depth
PWHCC30
7 ⁄
˝
6 ⁄
˝
28 ½˝
24 ½˝
PWHCC36
14 ½˝
10 ½˝
34 ½˝
28 ⁄
˝
PWHCC42
20 ½˝
10 ½˝
40 ½˝
21 ⁄
˝
PWHCC•P
28
1
/
4
˝
32
11
/
32
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
30
5
/
8
˝
42
5
/
8
˝
54
5
/
8˝
11
15
/
16
˝
15
1
/
2
˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
6
5
/
16
˝
22
5
/
8
˝
8˝, 20˝, 32˝
28
1
/
4
˝
32
11
/
32
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
30
5
/
8
˝
42
5
/
8
˝
54
5
/
8˝
11
15
/
16
˝
15
1
/
2
˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
6
5
/
16
˝
22
5
/
8
˝
8˝, 20˝, 32˝
PWHCC•BE
Unless indicated, measurements include molding
Wall Hood Classic Chimney Flat Panel Valance
Plain
32” High
WHCCFPV301932 •P
WHCCFPV361932 •P
WHCCFPV362432 •P
WHCCFPV422432 •P
44” High
WHCCFPV301944 •P
WHCCFPV361944 •P
WHCCFPV362444 •P
WHCCFPV422444 •P
56” High
WHCCFPV301956 •P
WHCCFPV361956 •P
WHCCFPV362456 •P
WHCCFPV422456 •P
Beaded Panel
32” High
WHCCFPV301932 •BE
WHCCFPV361932 •BE
WHCCFPV362432 •BE
WHCCFPV422432 •BE
44” High
WHCCFPV301944 •BE
WHCCFPV361944 •BE
WHCCFPV362444 •BE
WHCCFPV422444 •BE
56” High
WHCCFPV301956 •BE
WHCCFPV361956 •BE
WHCCFPV362456 •BE
WHCCFPV422456 •BE
• Solid wood/wood veneer
construction
• Check local building codes for
required clearances between the
Wall Hood and cooking surface
• A 3˝ space is recommended on
the right and left side of this unit
before beginning the adjacent
cabinet runs
• 32˝ high hoods are designed for
use with 8 foot ceilings
• 44˝ high hoods are designed for
use with 9 ft. ceilings
• 56˝ high hoods are designed for
use with 10 ft. ceilings
• Decorative molding matches Soffit Crown
Molding profile (SCM8)
• Chimney section shipped separately
•
Not
designed to be used with a soffit
• Painted hardwood supplied for EverCore™ and
Laminate
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
•
Not
available in Morrisbrook; Durham and
Meredith supplied plain sawn
• 19˝ deep requires Wall Hood Component
Package “J”, located before the Wall Hood
Designs in this section
• 24˝ deep requires Wall Hood Component
Package “G” or “P”, located before the Wall
Hood Designs in this section
•
Note:
Cabinetry and appliances located
below these Wall Hoods
must
be pulled to a
minimum of 27˝deep and a maximum of 30˝
deep for improved function
•
Note:
Wall Hood
must
be securely anchored
to wall
A Wall Hood Classic Chimney Flat
Panel Valance coordinates best with
flat panel door styles. It may
not
match the door exactly, but will
blend into the design and enhance the
appearance of the entire room.
PE
v
APC
APFC
FPEB
MI
DE
RD
ID
XS
XSG
GD
WHCCFPV•P
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
32˝
44˝
56˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
20
3
/
16
˝
23
7
/
16
˝
32
7
/
32
˝
38
1
/
4
˝
44
1
/
4
˝
11
3
/
4
˝, 15˝
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
32˝
44˝
56˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
20
3
/
16
˝
23
7
/
16
˝
32
7
/
32
˝
38
1
/
4
˝
44
1
/
4
˝
11
3
/
4
˝, 15˝
WHCCFPV•BE
Unless indicated, measurements include molding
Opening Sizes
Cabinet
Top Width
Top Depth BottomWidth Bottom Depth
WHCCFPV30
8˝
7 ⁄
˝
28 ⅝˝
18 ⁄
˝
WHCCFPV36
14 ⁄
˝
10 ¾˝
34 ⅝˝
21 ⁄
˝
WHCCFPV42
20 ½˝
10 ¾˝
40 ⅝˝
21 ⁄
˝
