Wall Hoods
Wall Cabinets
Peninsula Wall Hood Matching
Ogee Molding
PRH3024 •OG
PRH3624 •OG
• Solid wood/wood veneer construction
• Metal liner required
• Doors open to facilitate duct installation and
wiring
• Requires Wall Hood Component Package “C”
or “F”, located before the Wall Hood Designs
in this section
•
Not
available in Alder–Rustic door styles
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
• Painted hardwood supplied for EverCore™
•
Not
available in Morrisbrook; Durham and Meredith
supplied plain sawn
•
Note:
Wall hood
must
be securely anchored to ceiling or
soffit
PE
l
APC
APFC
FPEB
MI
DE
RD
ID
XS
XSG
GD
open
12˝
26˝
PRH•OG
23 ½˝
Wall Hood Classic Chimney
Plain
30 5/8” High
WHCC301930 •P
WHCC361930 •P
WHCC362430 •P
WHCC422430 •P
42 5/8” High
WHCC301942 •P
WHCC361942 •P
WHCC362442 •P
WHCC422442 •P
54 5/8” High
WHCC301954 •P
WHCC361954 •P
WHCC362454 •P
WHCC422454 •P
Beaded Panel
30 5/8” High
WHCC301930 •BE
WHCC361930 •BE
WHCC362430 •BE
WHCC422430 •BE
42 5/8” High
WHCC301942 •BE
WHCC361942 •BE
WHCC362442 •BE
WHCC422442 •BE
54 5/8” High
WHCC301954 •BE
WHCC361954 •BE
WHCC362454 •BE
WHCC422454 •BE
• Solid wood/wood veneer construction
• Check local building codes for required
clearances between the Wall Hood and
cooking surface
• A 3˝ space is recommended on the right and
left side of this unit before beginning the
adjacent cabinet runs
• 30 5/8˝ high hoods are designed for use with
8 foot ceilings
• 42 5/8˝ high hoods are designed for use with 9 ft.
ceilings
• 54 5/8˝ high hoods are designed for use with 10 ft.
ceilings
• Lower molding matches Beaded Panel Molding (BPM8)
profile, other molding matches Soffit Crown Molding
profile (SCM8)
• Chimney section shipped separately
• Will accept optional onlays, ordered separately; see
Molding Accents section of this book
•
Not
designed to be used with a soffit
• Painted hardwood supplied for EverCore™ and Laminate
• Painted or Stained hardwood supplied for Woodgrain
Laminate door styles
•
Not
available in Morrisbrook; Durham and Meredith
supplied plain sawn
• 19˝ deep requires Wall Hood Component Package “J”,
located before the Wall Hood Designs in this section
• 24˝ deep requires Wall Hood Component Package “G”
or “P”, located before the Wall Hood Designs in this
section
•
Note:
Cabinetry and appliances located below these
Wall Hoods
must
be pulled to a minimum of 27˝deep
and a maximum of 30˝ deep for improved function
•
Note:
Wall Hood
must
be securely anchored to wall
Select a Wall Hood, Chimney style when
designing with open soffits. A Chimney style
hood is selected when you want an unfitted
look; a design that looks great with your door style, but
matching or including the door style is
not
required.
