Tall Appliance Cabinets
Oven Cabinet–Combination w/3” Stiles
84” High
OC272484 (Butt)C
OC302484 (Butt)C
u
OC332484 C
OC332484 BUTTC
87” High
OC272487 (Butt)C
OC302487 (Butt)C
u
OC332487 C
OC332487 BUTTC
90” High
OC272490 (Butt)C
OC302490 (Butt)C
u
OC332490 C
OC332490 BUTTC
93” High
OC272493 (Butt)C
OC302493 (Butt)C
u
OC332493 C
OC332493 BUTTC
96” High
OC272496 (Butt)C
OC302496 (Butt)C
u
OC332496 C
OC332496 BUTTC
• Includes adjustable shelves in upper
section: 84˝, 87” & 90˝ high—no
shelves; 93˝ & 96˝ high—one shelf
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB,
CPLB, CVGR)
not
available
• Center 10” rail can be removed for
double oven application
I
WR and RTK
not
available on 93” &
96” high cabinets
• Toe kick is shipped separately on 93˝
& 96˝ high cabinets
I
VTK is
not
available on 93” and 96”
high cabinets
•
Not
available with knife hinge door option
•
Note
: When ordering glass doors in full overlay
door styles, a portion of the 3” face frame will be
visible
Best used for appliance combinations
such as; microwave, single oven, and
warming drawer or double oven and
warming drawer
Remember to order a 3/16” skin (WSK)
for the exposed ends of 93” & 96” high
cabinets to conceal the seam between
the loose toe kick and the cabinet.
PE
l
APC
l
APFC
v
FPEB
l
MI
l
RD
IF
I
WR
l
XS
l
GD
I
RTK
I
VTK
24˝
84˝
87˝
90˝
93˝
96˝
12˝
15˝
18˝
21˝
23 ½˝
Maximum cutout opening is dependent on
appliance size and use of molding or trim kit.
Distance between top doors and bottom
drawer on full overlay styles is 30˝.
Cabinet
Width
Min.
Width
Max.
Width
Min.
Height
84˝-93˝
Min.
Height
96˝
Max.
Height
27˝
21˝ 25˝ 21 ½˝ 22˝
30˝
24˝ 28˝ 21 ½˝ 22˝
33˝
27˝ 31˝ 21 ½˝ 22˝
Center Opening cut out dimensions
Cabinet
Width
Min.
Width
Max.
Width
Min.
Height
Max.
Height
27˝
21˝ 25˝
9˝
13 ½˝
30˝
24˝ 28˝
9˝
13 ½˝
33˝
27˝ 31˝
9˝
13 ½˝
Bottom opening cut out dimensions
Cabinet
Width
Min.
Width
Max.
Width
Min.
Height
Max.
Height
27˝
21˝ 25˝
15˝
19˝
30˝
24˝ 28˝
15˝
19˝
33˝
27˝ 31˝
15˝
19˝
Top opening cut out dimensions
u
3” center stile
Gray color coding indicates new product, size or code.
Oven Cabinet–Universal
84” High
u
OC272484 (Butt)U
i
OC302484 U
s
OC302484 BUTTU
i
OC332484 U
s
OC332484 BUTTU
87” High
u
OC272487 (Butt)U
i
OC302487 U
s
OC302487 BUTTU
i
OC332487 U
s
OC332487 BUTTU
90” High
u
OC272490 (Butt)U
i
OC302490 U
s
OC302490 BUTTU
i
OC332490 U
s
OC332490 BUTTU
93” High
u
OC272493 (Butt)U
i
OC302493 U
s
OC302493 BUTTU
i
OC332493 U
s
OC332493 BUTTU
96” High
u
OC272496 (Butt)U
i
OC302496 U
s
OC302496 BUTTU
i
OC332496 U
s
OC332496 BUTTU
• Includes adjustable shelves in upper
section: 84” & 87” high—no shelves;
90” & 93” high—one shelf; 96”
high—two shelves
• Adjustable floor
• Three standard height drawers
• Drawers are removable to
accommodate increased oven
height
• Oven Trim Kit (overlay panel) available for a full
overlay look; see Tall Accessories section of this
book
I
WR and RTK
not
available on 93” & 96” high
cabinets
• Toe kick is shipped separately on 93˝ & 96˝ high
cabinets
I
VTK is
not
available on 93” and 96” high cabinets
• One deep drawer
• Oven cutout requirements
must
be 1 1/2” less
than maximum allowable cutout in order to use
Oven Trim Kit (OTK)
Most major appliance manufacturers
will tell you that their 27” wide ovens
will fit into a 27” oven cabinet and their
30” wide ovens will fit into a 30” cabinet. In most
cases this is true. However, the look this creates
may
not
be appealing because the stiles will be
concealed by the appliance. To solve this problem,
you can order a 30” oven cabinet for a 27” oven
and a 33” oven cabinet for a 30” oven, etc.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
RD
IF
I
WR
l
XS
l
GD
I
RTK
I
VTK
24˝
84˝
87˝
90˝
93˝
96˝
18˝
21˝
23 ½˝
27˝
30˝
23 ½˝
50 ½˝
44 ¼˝
60˝
30˝
38˝
cutout
dimensions
Cabinet
Width
Min
Width
Max.
Width
Min.
Height
Max.
Height
27˝
21˝
25˝
23 ½˝
30˝
24˝
28˝
23 ½˝
33˝
27˝
31˝
23 ½˝
Maximum cutout opening is dependent on
appliance size and use of molding or trim kit.
See drawing for details
Cut out dimensions
u
3˝ stiles
i
4 1/2˝ stiles routed to 1 1/2˝ in the door area with 3˝
center stile
s
4 1/2” stiles routed to 1 1/2” in the door area
Gray color coding indicates new product, size or code.
