Roll-out Trays
Base Pots and Pans Organizer Roll-out Field Installation
ROT30 •BPPSO
ROT36 •BPPSO
• 4˝ high Roll-out Tray with integrated shelf
system
• Roll-out sides, back and shelves are 1/2˝ wood
veneer plywood
• Mounting hardware and runners included
• 24˝ depth only
• Field installation only
APC
MI
High Back Roll-out Trays Factory Installed
i
1HBFWROT
i
2HBFWROT
i
3HBFWROT
i
4HBFWROT
i
5HBFWROT
1HBROT
2HBROT
3HBROT
4HBROT
5HBROT
• 4” high tray has 7” high back, 1/2” thick solid wood
front, back and sides and 3/16” Viraguard laminated
plywood bottom
• 18”, 21” and 24” depths only
• Shelves are eliminated when this option is selected
• Maximum of two can be installed vertically in a
standard base cabinet
• Maximum of three can be installed vertically in a full-
height door base cabinet
• A maximum of two different Roll-out Tray (ROT) types
can be factory installed in a single cabinet.
Example: B30BUTT-1FWROT-1DXFWROT
• Full-width trays
not
available in 39”, 42”, 45” or 48”
• Trays are
not
evenly spaced
• Specify quantity
• Example:
Installed—U182484L-3HBROT
Installed—B15L-2HBROT
Installed—B36-2HBFWROT
APC
MI
i
When full-width Roll-out Trays (ROT) are
ordered for 30˝, 33˝ or 36˝ wide cabinets, the
double doors will have a mullion attached to
the left door. Full width Roll-out Trays (ROT)
are
not
available factory installed on Utility
cabinets (U) wider than 24˝.
High Back Roll-out Trays Field Installation
HBROT12•24 •21 •18
HBROT15•24 •21 •18
HBROT16•24 •21 •18
HBROT18•24 •21 •18
HBROT19•24 •21 •18
HBROT21•24 •21 •18
HBROT22•24 •21 •18
HBROT24•24 •21 •18
HBROT27•24 •21 •18
HBROT30•24 •21 •18
HBROT33•24 •21 •18
HBROT36•24 •21 •18
• 4” high tray has 7” high back, 1/2” thick
solid wood front, back and sides and 3/16”
Viraguard laminated plywood bottom
• 18”, 21” and 24” depths only
• Tray location is adjustable
• Mounting hardware and runners included
• Example:
For U182484—order HBROT18•24
For B15L—order HBROT15•24
For VB1518R—order HBROT15•18
For VB15L—order HBROT15•21
