Roll-out Trays
Roll-out Trays
Construction Options and
Modifications
v
- - Included as standard
l
- - Available with an upcharge
I
- - Available with exceptions
(Blank)
Not
available
Material dimensions may vary slightly
based on lumber industry standards.
Specifications subject to change without
notice.
APC - All Plywood Construction
MI - - Matching Interior
DROT 12 •24
code
width
depth
Roll-out Tray Field Installation Chart
Cabinet
(Maximum)
#ROTs #DROTs #DXROTs #HBROTs
Base
5
3
3
2
Base•FH
7
4
4
3
Base•FH•40
7
5
5
3
Tall
10
10
10
5
Desk
3
2
2
1
Desk•FH 4
3
3
2
Vanity
5
3
3
2
Vanity•FH 7
4
4
3
VLC 88 ½˝ H 6 (Top)
7 (Bottom)
6 (Top)
4 (Bottom)
6 (Top)
4 (Bottom)
3 (Top)
3 (Bottom)
Roll-out Trays Factory Installed
i
1FWROT
i
2FWROT
i
3FWROT
i
4FWROT
i
5FWROT
i
6FWROT
1ROT
2ROT
3ROT
4ROT
5ROT
6ROT
• 2 1/4” high tray has 1/2” thick solid wood sides and
3⁄16” Viraguard laminated plywood bottom
• 18”, 21” and 24” depths only
• Shelves are eliminated when this option is selected
• Tray location is adjustable
• A maximum of two different Roll-out Tray (ROT) types
can be factory installed in a single cabinet. Example:
B30BUTT-1FWROT-1DXFWROT
• Full-width trays
not
available in 39”, 42”, 45” or 48”
• Trays are
not
evenly spaced
• Specify quantity
• Example:
Installed—U182484L-3ROT
Installed—B15L-3ROT
Installed—B36-3FWROT
APC
MI
i
When full-width Roll-out Trays (ROT) are
ordered for 30˝, 33˝ or 36˝ wide cabinets, the
double doors will have a mullion attached to
the left door. Full width Roll-out Trays (ROT)
are
not
available factory installed on Utility
cabinets (U) wider than 24˝.
