Tall Cabinets
F17
Tall Appliance Cabinets
Oven Cabinet–Combination w/3” Stiles
84” High
OC272484 (Butt)C
OC302484 (Butt)C
u
OC332484 C
OC332484 BUTTC
87” High
OC272487 (Butt)C
OC302487 (Butt)C
u
OC332487 C
OC332487 BUTTC
90” High
OC272490 (Butt)C
OC302490 (Butt)C
u
OC332490 C
OC332490 BUTTC
93” High
OC272493 (Butt)C
OC302493 (Butt)C
u
OC332493 C
OC332493 BUTTC
96” High
OC272496 (Butt)C
OC302496 (Butt)C
u
OC332496 C
OC332496 BUTTC
• Includes adjustable shelves in upper
section: 84˝, 87” & 90˝ high—no shelves;
93˝ & 96˝ high—one shelf
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• Center 10” rail can be removed for double
oven application
I
WR and RTK
not
available on 93” & 96”
high cabinets
• Toe kick is shipped separately on 93˝ & 96˝
high cabinets
I
VTK is
not
available on 93” and 96” high
cabinets
•
Not
available with knife hinge door option
•
Note
: When ordering glass doors in full overlay door
styles, a portion of the 3” face frame will be visible
Best used for appliance combinations such
as; microwave, single oven, and warming
drawer or double oven and warming
drawer
Remember to order a 3/16” skin (WSK) for
the exposed ends of 93” & 96” high cabinets
to conceal the seam between the loose toe
kick and the cabinet.
PE
l
APC
l
APFC
v
FPEB
l
MI
l
RD
IF
I
WR
l
XS
l
GD
I
RTK
I
VTK
24˝
84˝
87˝
90˝
93˝
96˝
12˝
15˝
18˝
21˝
23 ½˝
Top opening cut out dimensions
Cabinet
Width
1/2”
Overlay
Full
Overlay
Min.
Width
Max.
Width
Min.
Height
Max.
Height
Max.
Height
27˝
30˝
33˝
21˝
24˝
27˝
25˝
28˝
31˝
15˝
15˝
15˝
26
2
˝
26
2
˝
26
2
˝
25
2
˝
25
2
˝
25
2
˝
Center opening cut out dimensions
Cabinet
Width
1/2”
Overlay
Full
Overlay
Min.
Width
Max.
Width
Min.
Height
Max.
Height
Max.
Height
27˝
30˝
33˝
21˝
24˝
27˝
25˝
28˝
31˝
21
2
˝
21
2
˝
21
2
˝
27˝
27˝
27˝
27˝
27˝
27˝
Bottom opening cut out dimensions
Cabinet
Width
1/2”
Overlay
Full
Overlay
Min.
Width
Max.
Width
Min.
Height
Max.
Height
Max.
Height
27˝
30˝
33˝
21˝
24˝
27˝
25˝
28˝
31˝
9˝
9˝
9˝
13
2
˝
13
2
˝
13
2
˝
13
2
˝
13
2
˝
13
2
˝
u
3” center stile
Gray color coding indicates new product, size or code.
Oven Cabinet–Universal
84” High
u
OC272484 (Butt)U
i
OC302484 U
s
OC302484 BUTTU
i
OC332484 U
s
OC332484 BUTTU
87” High
u
OC272487 (Butt)U
i
OC302487 U
s
OC302487 BUTTU
i
OC332487 U
s
OC332487 BUTTU
90” High
u
OC272490 (Butt)U
i
OC302490 U
s
OC302490 BUTTU
i
OC332490 U
s
OC332490 BUTTU
93” High
u
OC272493 (Butt)U
i
OC302493 U
s
OC302493 BUTTU
i
OC332493 U
s
OC332493 BUTTU
96” High
u
OC272496 (Butt)U
i
OC302496 U
s
OC302496 BUTTU
i
OC332496 U
s
OC332496 BUTTU
• Includes adjustable shelves in upper
section: 84” & 87” high—no shelves; 90”
& 93” high—one shelf; 96” high—two
shelves
• Adjustable floor
• Three standard height drawers
• Drawers are removable to accommodate
increased oven height
• Oven Trim Kit (overlay panel) available
for a full overlay look; see Tall Accessories
section of this book
I
WR and RTK
not
available on 93” & 96” high
cabinets
• Toe kick is shipped separately on 93˝ & 96˝ high
cabinets
I
VTK is
not
available on 93” and 96” high cabinets
• One deep drawer
• Oven cutout requirements
must
be 1 1/2” less than
maximum allowable cutout in order to use Oven
Trim Kit (OTK)
Most major appliance manufacturers will
tell you that their 27” wide ovens will fit
into a 27” oven cabinet and their 30” wide
ovens will fit into a 30” cabinet. In most cases this is
true. However, the look this creates may
not
be
appealing because the stiles will be concealed by the
appliance. To solve this problem, you can order a 30”
oven cabinet for a 27” oven and a 33” oven cabinet
for a 30” oven, etc.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
RD
IF
I
WR
l
XS
l
GD
I
RTK
I
VTK
24˝
84˝
87˝
90˝
93˝
96˝
18˝
21˝
23 ½˝
27˝
30˝
23 ½˝
50 ½˝
44 ¼˝
60˝
30˝
38˝
cutout
dimensions
Cut out dimensions
Cabinet
Width
1/2”
Overlay
Full
Overlay
Min.
Width
Max.
Width
Min.
Height
Max.
Height
Max.
Height
27˝
30˝
33˝
21˝
21˝
24˝
25˝
28˝
31˝
23
2
˝
23
2
˝
23
2
˝
31˝
31˝
31˝
30˝
30˝
30˝
u
3˝ stiles
i
4 1/2˝ stiles routed to 1 1/2˝ in the door area with
3˝ center stile
s
4 1/2” stiles routed to 1 1/2” in the door area
Gray color coding indicates new product, size or code.
