Tall Cabinets
F16
Tall Appliance Cabinets
Oven Cabinet–Double Extended Opening w/3” Stiles
60” High
OC242460 DE
OC272460 DE
OC302460 DE
OC332460 DE
84” High
i
OC242484 (Butt)DE
OC272484 (Butt)DE
OC302484 (Butt)DE
u
OC332484 DE
OC332484 BUTTDE
87” High
i
OC242487 (Butt)DE
OC272487 (Butt)DE
OC302487 (Butt)DE
u
OC332487 DE
OC332487 BUTTDE
90” High
i
OC242490 (Butt)DE
OC272490 (Butt)DE
OC302490 (Butt)DE
u
OC332490 DE
OC332490 BUTTDE
93” High
i
OC242493 (Butt)DE
OC272493 (Butt)DE
OC302493 (Butt)DE
u
OC332493 DE
OC332493 BUTTDE
96” High
i
OC242496 (Butt)DE
OC272496 (Butt)DE
OC302496 (Butt)DE
u
OC332496 DE
OC332496 BUTTDE
• Includes adjustable shelves in upper
section: 60”, 84” & 87” high—no shelves;
90” & 93” high—one shelf; 96” high—two
shelves
• Double Oven Opening Kit (DOK) shelf
available for two appliance installation;
see Tall Accessories section of this book
• Oven Trim Kit (overlay panel) available
for a full overlay look; see Tall Accessories
section of this book
I
WR and RTK
not
available on 93” & 96”
high cabinets
• Toe kick is shipped separately on 93˝ & 96˝ high
cabinets
I
VTK is
not
available on 93” and 96” high cabinets
•
Not
available with knife hinge door option
•
Note
: When ordering glass doors in full overlay door
styles, a portion of the 3” face frame will be visible
Remember to order a 3/16” skin (WSK) for
the exposed ends of 93” & 96” high cabinets
to conceal the seam between the loose toe
kick and the cabinet.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
RD
IF
I
WR
l
XS
l
GD
I
RTK
I
VTK
84˝
87˝
90˝
93˝
96˝
18˝
21˝
23 ½˝
27˝
30˝
10˝
24˝
24˝
60 ½˝
OC_60
OC_84-OC_96
Cut out dimensions
Cabinet
Width
60” H
Cabinet
84”-87 H
Cabinet
90”+ H
Cabinet
Min.
Width
Max.
Width
Min.
Height
Min.
Height
Max.
Height
Full Overlay
Max.
Height
1/2” Overlay
Max.
Height
Full Overlay
24˝
27˝
30˝
33˝
39˝
21˝
21˝
24˝
27˝
33˝
22˝
25˝
28˝
31˝
37˝
48
2
˝
48
2
˝
48
2
˝
48
2
˝
48
2
˝
Max.
Height
50
2
˝
50
2
˝
50
2
˝
50
2
˝
50
2
˝
43˝
43˝
43˝
43˝
43˝
59˝
59˝
59˝
59˝
59˝
Max.
Height
1/2” Overlay
58
2
˝
58
2
˝
58
2
˝
58
2
˝
58
2
˝
57
2
˝
57
2
˝
57
2
˝
57
2
˝
57
2
˝
58˝
58˝
58˝
58˝
58˝
Min.
Height
43˝
43˝
43˝
43˝
43˝
i
1 1/2˝ stiles
u
3” center stile
Gray color coding indicates new product, size or code.
