Tall Cabinets
F15
Tall Appliance Cabinets
Oven Cabinet–Double w/3” Stiles–Deep Drawer
84” High
i
OC242484 (Butt)D•DD
OC272484 (Butt)D•DD
OC302484 (Butt)D•DD
u
OC332484 D•DD
OC332484 BUTTD•DD
87” High
i
OC242487 (Butt)D•DD
OC272487 (Butt)D•DD
OC302487 (Butt)D•DD
u
OC332487 D•DD
OC332487 BUTTD•DD
90” High
i
OC242490 (Butt)D•DD
OC272490 (Butt)D•DD
OC302490 (Butt)D•DD
u
OC332490 D•DD
OC332490 BUTTD•DD
93” High
i
OC242493 (Butt)D•DD
OC272493 (Butt)D•DD
OC302493 (Butt)D•DD
u
OC332493 D•DD
OC332493 BUTTD•DD
96” High
i
OC242496 (Butt)D•DD
OC272496 (Butt)D•DD
OC302496 (Butt)D•DD
u
OC332496 D•DD
OC332496 BUTTD•DD
• Includes adjustable shelves in upper
section: 84” high—no shelves; 87”,
90” & 93” high—one shelf; 96”
high—two shelves
• Oven Trim Kit (overlay panel)
available for a full overlay look; see
Tall Accessories section of this book
• Double Oven Opening Kit (DOK)
shelf available for two appliance
installation; see Tall Accessories
section of this book
I
WR and RTK
not
available on 93” & 96” high
cabinets
I
VTK is
not
available on 93” and 96” high cabinets
I
Glass doors available for top doors only
•
Not
available with knife hinge door option
•
Note
: When ordering glass doors in full overlay
door styles, a portion of the 3” face frame will be
visible
Remember to order a 3/16” skin (WSK)
for the exposed ends of 93” & 96” high
cabinets to conceal the seam between
the loose toe kick and the cabinet.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
RD
IF
I
WR
l
XS
I
GD
I
RTK
I
VTK
7˝
24˝
84˝
87˝
90˝
93˝
96˝
18˝
21˝
23 ½˝
27˝
30˝
Cut out dimensions
Cabinet
Width
1/2” Overlay
Full Overlay
Min.
Width
Max.
Width
Min.
Height
Max.
Height
84”-87” H
Max.
Height
90” H +
Max.
Height
84”-87” H
Max.
Height
90” H +
24˝
27˝
30˝
33˝
21˝
21˝
24˝
27˝
22˝
25˝
28˝
31˝
36
2
˝
36
2
˝
36
2
˝
36
2
˝
49
2
˝
49
2
˝
49
2
˝
49
2
˝
48
2
˝
48
2
˝
48
2
˝
48
2
˝
49˝
49˝
49˝
49˝
48˝
48˝
48˝
48˝
i
1 1/2˝ stiles
u
3” center stile
Gray color coding indicates new product, size or code.
