Tall Cabinets
F8
Tall Cabinets
Tall Corner Angle
TCA242484 BUTT
TCA242487 BUTT
TCA242490 BUTT
TCA242493 BUTT
TCA242496 BUTT
• Includes adjustable shelves in upper section:
84” & 87” high—one shelf; 90” & 93” high—
two shelves; 96” high—three shelves
• Four adjustable bottom shelves; shipped
separately
• No center rail on tall door for Argonne,
Astoria, Avery, Brockton, Chadwick, Cornell,
Courtney, Eldridge, Evana, Evana Cathedral,
Findlay, Findlay Cathedral, Garrison,
Harrington, Jamison, Judson, Kendrick,
Lindsay, Lockeford, Maxton, Northwicke,
Parker House, Rutherford, Sheridan, Sydney,
Tennyson and Vanderbilt door styles
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• Can be installed on either right or left end
• Toe kick is shipped separately on 93˝ & 96˝ high cabinets
• Replacement shelf available; specify BCAS2424
I
VTK is
not
available on 93” and 96” high cabinets
End panels are unfinished; cabinet is intended to
be used with a Utility or Oven Cabinet. A panel
must
be used to cover the exposed side if
installing without an adjacent tall cabinet.
l
PE
l
APC
APFC
FPEB
l
MI
DE
CW
RD
l
CH
IF
WR
XS
l
GD
RTK
I
VTK
23½˝
27˝
30˝
33˝
36˝
84˝
87˝
90˝
93˝
96˝
Gray color coding indicates new product, size or code.
Tall End Angle
Specify R or L
TEA122484 R or L
TEA122487 R or L
TEA122490 R or L
TEA122493 R or L
TEA122496 R or L
• Includes adjustable shelves in upper section:
84” & 87” high—one shelf; 90” & 93” high—
two shelves; 96” high—three shelves
• Four adjustable bottom shelves; shipped
separately
• No center rail for Astoria, Argonne,
Chadwick, Courtney, Evana, Evana Cathedral,
Findlay, Findlay Cathedral, Lindsay, Lockeford,
Northwicke, Parker House, Rutherford,
Sheridan and Sydney door styles
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• Toe kick is shipped separately on 93˝ & 96˝
high cabinets
• Replacement shelf available specify BEA12 R or L
I
Integrated Decorative Ends available on 12” Deep side only
I
Minimum Reduced Depth (RD) is 18˝
I
Wide Rail Plain only (WR)
I
Recessed Toe Kick (RTK) available hinge side only
I
VTK is
not
available on 93” and 96” high cabinets
•
Note
: 24 in. end panels are unfinished; cabinet is intended
to be used with a Utility or Oven Cabinet. A panel
must
be used to cover the exposed side if installing without an
adjacent tall cabinet. 12 in. deep end panels are finished.
•
Note
: Full overlay door styles use a 1/2” overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
I
DE
CW
I
RD
l
CH
IF
I
WR
XS
l
GD
I
RTK
l
VTK
12
˝
24
˝
23
½
˝
27
˝
30
˝
33
˝
36
˝
84˝
87˝
90˝
93˝
96˝
Gray color coding indicates new product, size or code.
