Tall Appliance Cabinets
Oven Cabinet–Single Oven/Microwave Combination w/3” Stiles–Bottom Drawer
4” High Drawer
i
OC242460 (Butt)
OC272460 (Butt)
OC302460 (Butt)
OC332460
7” High Deep Drawer
i
OC242460 (Butt)•DD
OC272460 (Butt)•DD
OC302460 (Butt)•DD
OC332460 •DD
• No shelf
• Oven Trim Kit (overlay panel)
available for a full overlay look; see Tall
Accessories section of this book
• Double Oven Opening Kit (DOK) shelf
available for two appliance installation;
see Tall Accessories section of this book
I
Change Height modifications will
be made in the upper door section,
appliance cutout dimensions are
not
affected
•
Not
available with knife hinge door
option
Remember to order a 3/16” skin (WSK)
for the exposed ends of 93” & 96” high
cabinets to conceal the seam between
the loose toe kick and the cabinet.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
CW
l
RD
I
CH
IF
l
WR
l
XS
GD
l
RTK
l
VTK
Cut out dimensions
Cabinet
Width
4” Bottom
Drawer
7” Bottom
Drawer
Min.
Width
Max.
Width
Min.
Height
Min.
Height
Max.
Height
Max.
Height
24˝
27˝
30˝
33˝
21˝
21˝
24˝
27˝
22˝
25˝
28˝
31˝
44˝
44˝
44˝
44˝
41˝
41˝
41˝
41˝
33
2
˝
33
2
˝
33
2
˝
33
2
˝
34
2
˝
34
2
˝
34
2
˝
34
2
˝
24˝
4˝
7˝
24˝
60 ½˝
60 ½˝
OC_60
OC_60 •DD
i
1 1/2˝ stiles
Gray color coding indicates new product, size or code.
Oven Cabinet–Double w/3” Stiles
84” High
i
OC242484 (Butt)D
OC272484 (Butt)D
OC302484 (Butt)D
u
OC332484 D
OC332484 BUTTD
87” High
i
OC242487 (Butt)D
OC272487 (Butt)D
OC302487 (Butt)D
u
OC332487 D
OC332487 BUTTD
90” High
i
OC242490 (Butt)D
OC272490 (Butt)D
OC302490 (Butt)D
u
OC332490 D
OC332490 BUTTD
93” High
i
OC242493 (Butt)D
OC272493 (Butt)D
OC302493 (Butt)D
u
OC332493 D
OC332493 BUTTD
96” High
i
OC242496 (Butt)D
OC272496 (Butt)D
OC302496 (Butt)D
u
OC332496 D
OC332496 BUTTD
• Includes adjustable shelves in upper
section: 84” & 87” high—no shelves; 90”
& 93” high—one shelf; 96” high—two
shelves
• Oven Trim Kit (overlay panel)
available for a full overlay look; see Tall
Accessories section of this book
• Double Oven Opening Kit (DOK) shelf
available for two appliance installation;
see Tall Accessories section of this book
I
Change Height modifications will
be made in the upper door section,
appliance cutout dimensions are
not
affected
I
WR and RTK
not
available on 93” & 96” high cabinets
• Toe kick is shipped separately on 93˝ & 96˝ high
cabinets
I
VTK is
not
available on 93” and 96” high cabinets
•
Not
available with knife hinge door option
•
Note
: When ordering glass doors in full overlay door
styles, a portion of the 3” face frame will be visible
l
PE
l
APC
l
APFC
l
FPEB
l
MI
CW
l
RD
I
CH
IF
I
WR
l
XS
l
GD
I
RTK
I
VTK
4˝
24˝
84˝
87˝
90˝
93˝
96˝
18˝
21˝
23 ½˝
27˝
30˝
Cut out dimensions
Cabinet
Width
1/2” Overlay
Full Overlay
Min.
Width
Max.
Width
Min.
Height
Max.
Height
84”-87” H
Max.
Height
90” H +
Max.
Height
84”-87” H
Max.
Height
90” H +
24˝
27˝
30˝
33˝
21˝
21˝
24˝
27˝
22˝
25˝
28˝
31˝
36
2
˝
36
2
˝
36
2
˝
36
2
˝
51
2
˝
51
2
˝
51
2
˝
51
2
˝
51
2
˝
51
2
˝
51
2
˝
51
2
˝
52˝
52˝
52˝
52˝
51˝
51˝
51˝
51˝
i
1 1/2˝ stiles
u
3” center stile
Gray color coding indicates new product, size or code.
