Base Cabinets
E28
Base Corner Cabinets
Lazy Susan Angle
Specify R or L
LSA36 R or L
• Two 28˝ diameter rotating shelves
• Angled back provides clearance for
installation
• 30 1/2˝ door clearance recommended for
delivery
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
•
Note
: Full overlay door styles use a 1/2”
overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
CW
RD
l
CH
TWR
l
WR
XS
l
GD
l
RTK
RTKP
l
VTK
34
1
/
2
˝
24˝
24˝
17˝
Wood Lazy Susan Angle
Specify R or L
LSA36 R or L•WLS
• Two 28˝ diameter rotating shelves
• Rotating shelves have plywood floor and
solid wood trim
• Shelves rotate independently
• Angled back provides clearance for
installation
• 30 1/2˝ door clearance recommended for
delivery
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
•
Note
: Full overlay door styles use a 1/2”
overlay hinge
Do
not
design a corner cabinet
adjacent to an object deeper than
the end panel. The door of the
corner cabinet may
not
function properly.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
CW
RD
l
CH
TWR
l
WR
XS
l
GD
l
RTK
RTKP
l
VTK
34
1
/
2
˝
24˝
24˝
17˝
Base Drawer Angle Information
22¾˝
20 ½˝
24˝
24˝
24˝
40˝
40˝
24˝
18˝
All dimensions are to outside of frame
BDA 40 •3
BDA 40 •4
Base Drawer Angle
BDA40 •3
BDA40 •4
• Deep drawers will accept optional Bread Box
(BB)
• Angled frame designed for diagonal corner
installation only
• Requires 40 3/32˝ of wall space
l
PE
l
APC
l
APFC
l
FPEB
MI
DE
CW
RD
CH
l
TWR
WR
XS
GD
RTK
RTKP
l
VTK
BDA 40 •3
BDA 40 •4
34 ½˝
34 ½˝
