Base Cabinets
E22
Base Appliance Cabinets
Base Dishwasher Cabinet
BDW272446
• Allows for 11” raised installation of standard
dishwashers
• False drawer front
• Finished top required
• Plywood floor
• Top rail is removable (used for shipping
purposes only)
I
Only available with Recessed Toe Kick
Peninsula Back (RTKP);
cannot
accommodate
Recessed Toe Kick for sides (RTKPB, RTKPL,
RTKPR)
Consider ordering 46 1/2” high Base
Microwave (BMC) and Dishwasher
(BDW) Cabinets with Furniture
Plywood Ends (FPEB) to bring the sides flush
with the face frame. This will prevent having
to notch the countertop of an adjacent
cabinet to fit behind the face frame.
l
PE
l
APC
l
APFC
l
FPEB
MI
DE
CW
RD
CH
IF
TWR
l
WR
l
XS
GD
RTK
I
RTKP
l
VTK
46
1
/
2
˝
24˝
Dishwasher Panel
DWP
• 3/16” thick, plain panel
• Quartersawn Cherry and Maple door styles
supplied plain sawn
• Painted hardwood supplied for EverCore™
• Matching wood veneer or laminate
•
Must
be trimmed to fit
PE
APC
APFC
FPEB
MI
DE
CW
RD
CH
IF
TWR
WR
XS
GD
RTK
RTKP
VTK
30˝
24˝
Dishwasher Raised Panel
DWP •RP
• Full Overlay door styles receive one door. All
other overlays receive two doors (style and
color to match kitchen)
• Mounted to matching 3/16” wood veneer or
laminate panel
• Quartersawn door styles are mounted to
matching 3/16˝ quartersawn wood veneer
panel
• Universally sized,
must
be trimmed to fit
PE
APC
APFC
FPEB
MI
DE
CW
RD
CH
IF
TWR
WR
XS
GD
RTK
RTKP
VTK
30˝
24˝
