Base Blind Corner Cabinet Information
• All Base Blind Corner (BBC) cabinets
must
be pulled. Consult chart or pull dimensions and minimum wall
space requirements
• R or L indicates blind
• Door hinged on same side as blind on single door cabinets
• A 3” Base Filler (BF) is included with each Base Blind Corner (BBC) cabinet ordered, shipped separately. Base
cabinet adjacent to BBC may be ordered with an extended stile in lieu of installing supplied filler
• Base Blind Corner Universal (BBCU) cabinets are shipped blind right standard, and may be reversed in field
• Two 3” Base Fillers (BF) are included with each Peninsula Base Blind Corner (PBBC) ordered except the PBBC
27
• Optional Panel for Base Blind Corner Overlay (OPWBC) is recommended for full overlay door styles; see Base
Accessories section of this book
•
Note
: For Sink Base Blind Corner (SBBC) cabinet, see Base Cabinets section
A
B
C
Blind Right
Shown
Base Blind Cabinet/
Sink Base Blind Cabinet
Peninsula Base Blind Corner Cabinet
Base Blind Cabinet Universal
Optional
Blind
Corner
Overlay
3” Filler
BBC39-63
Base
Cabinet
3” Filler
B
A
C
Optional
Blind
Corner
Overlay
PBBC36-48
Base
Cabinet
B
A
C
Optional
Blind
Corner
Overlay
BBCU36-48
Base
Cabinet
3” Filler
B
A
C
Wall Space“A”
Exposed
Front“B”
Door
Open
Wall Space“A”
Exposed
Front“B”
Door
Open
Min
★
Max.
Min
★
Max
C
Cab.
Width Min
★
Max Min
★
Max
C
Cab.
Width
BBCU 36
36˝
40˝
12˝
16˝
6˝
24˝
36˝
40˝
12˝
16˝
6˝
24˝
PBBC 36 34 ½˝ 37 ¾˝ 10 ½˝ 13 ¾˝
6˝
33˝ 35 ¼˝ 38 ¾˝ 11 ¼˝ 14 ¾˝
6˝
33˝
BBC 39
37 ½˝ 40 ¾˝ 13 ½˝ 16 ¾˝
9˝
36˝ 38 ¼˝ 41 ¾˝ 14 ¼˝ 17 ¾˝
9˝
36˝
BBCU 39 37 ½˝ 40 ⅝˝ 13 ¾˝ 16 ⅜˝
9˝
27˝ 38 ¼˝ 39 ⅞˝ 13˝
15 ⅞˝
9˝
27˝
P/BBC 42 40 ½˝ 43 ¾˝ 16 ½˝ 19 ¾˝ 12˝
39˝ 41 ¼˝ 44 ¾˝ 17 ¼˝ 20 ¾˝
12˝
39˝
BBCU 42 40 ½˝ 43 ⅝˝ 16 ¾˝ 19 ⅜˝ 12˝
33˝ 41 ¼˝ 42 ⅞˝ 16˝
18 ⅞˝
12˝
33˝
BBC 45
43 ½˝ 46 ¾˝ 19 ½˝ 22 ¾˝ 15˝
42˝ 44 ¼˝ 47 ¾˝ 20 ¼˝ 23 ¾˝
15˝
42˝
BBCU 45 43 ½˝ 46 ⅝˝ 19 ¾˝ 22 ⅜˝ 15˝
39˝ 44 ¼˝ 45 ⅞˝ 19˝
21 ⅞˝
15˝
39˝
P/BBC 48 46 ½˝ 49 ¾˝ 22 ½˝ 25 ¾˝ 18˝
45˝ 47 ¼˝ 50 ¾˝ 23 ¼˝ 26 ¾˝
18˝
45˝
BBCU 48 46 ½˝ 49 ⅝˝ 22 ¾˝ 25 ⅜˝ 18˝
45˝ 47 ¼˝ 48 ⅞˝ 22˝
24 ⅞˝
18˝
45˝
BBC 51
49 ½˝ 52 ¾˝ 25 ½˝ 28 ¾˝
21"
48"
50 ¼˝ 53 ¾˝ 26 ¼˝ 29 ¾˝
21"
48"
SBB 51
49 ½˝ 52 ¾˝ 25 ½˝ 28 ¾˝
21"
48"
50 ¼˝ 53 ¾˝ 26 ¼˝ 29 ¾˝
21"
48"
BBC 54*
52 ½˝ 55 ¾˝ 28 ½˝ 31 ¾˝
24"
51"
53 ¼˝ 56 ¾˝ 29 ¼˝ 32 ¾˝
24"
51"
SBB 54*
52 ½˝ 55 ¾˝ 28 ½˝ 31 ¾˝
24"
51"
53 ¼˝ 56 ¾˝ 29 ¼˝ 32 ¾˝
24"
51"
BBC 57*
55 ½˝ 58 ¾˝ 31 ½˝ 34 ¾˝
27"
54"
56 ¼˝ 59 ¾˝ 32 ¼˝ 35 ¾˝
27"
54"
SBB 57*
55 ½˝ 58 ¾˝ 31 ½
˝
34 ¾˝
27"
54"
56 ¼˝ 59 ¾˝ 32 ¼˝ 35 ¾˝
27"
54"
BBC 60*
58 ½˝ 61 ¾˝ 34 ½
˝
37 ¾˝ 30˝
57"
59 ¼˝ 62 ¾˝ 35 ¼˝ 38 ¾˝
30"
57"
SBB 60*
58 ½˝ 61 ¾˝ 34 ½
˝
37 ¾˝
30"
57"
59 ¼˝ 62 ¾˝ 35 ¼˝ 38 ¾˝
30"
57"
BBC 63*
61 ½˝ 64 ¾˝ 37 ½
˝
40 ¾˝
33"
60"
62 ¼˝ 65 ¾˝ 38 ¼˝ 41 ¾˝
33"
60"
SBB 63*
61 ½˝ 64 ¾˝ 37 ½
˝
40 ¾˝
33"
60"
62 ¼˝ 65 ¾˝ 38 ¼˝ 41 ¾˝
33"
60"
★
Dimensions “A” and “B” minimum requirements include optional decorative hardware clearance. You may deduct 1 1/4˝ if hardware is not used.
Cabinets will have BUTT doors
*
½˝ Overlay
Full Overlay
