Roll-out Trays
Roll-out Trays - Field Installation
18” Deep Trays
ROT12 •18
ROT15 •18
ROT18 •18
ROT24 •18
ROT27 •18
ROT30 •18
ROT33 •18
ROT36 •18
21” Deep Trays
ROT12 •21
ROT15 •21
ROT18 •21
ROT21 •21
ROT24 •21
ROT27 •21
ROT30 •21
ROT33 •21
ROT36 •21
24” Deep Trays
ROT9 •24
ROT12 •24
ROT14 •24
ROT15 •24
ROT16 •24
ROT18 •24
ROT19 •24
ROT21 •24
ROT22 •24
ROT24 •24
ROT27 •24
ROT30 •24
ROT33 •24
ROT36 •24
• Installs in base, universal base, utility and
vanity cabinets using pre-drilled holes
• See chart for cabinet availability
• 18”, 21” and 24” depths only
• Tray front is made of solid hardwood; tray
sides, back and bottom panel are made of
engineered wood covered with a moisture
and stain-resistant, easy clean laminate.
Top edge of sides and back finished with
matching edge banding
• Mounting hardware and runners included
• Natural finish
• Order Example:
For BBC39—order ROT9•24
For B12—order ROT12•24
For B18•FH—order ROT18•24
For U302496 BUTT—order ROT30•24
Determine the location of
plumbing and other obstructions
before ordering tray kits
18” depth
Item (by depth)
21” depth
24” depth
ROT12 •18
8 3/4”
VB121831, VB121834, VCD241831 DL2/DR2, VCD241834 DL3/DR3, VSB421831•2, VSB421834•2
ROT15 •18
11 3/4" VB151831, VB151834, VB481831•FH, VB481834•FH, VCD301831 DL2/DR2, VCD301834 DL3/DR3,
VSB481831•2, VSB481834•2, VSB601831•2, VSB601834•2
ROT18 •18
14 3/4" VB181831, VB181831•FH, VB181834, VB181834•FH, VB541831•FH, VB541834•FH, VCD361831 DL2/DR2,
VCD361834 DL3/DR3, VCD421834•8, VCD481834•8, VSB361831•2, VSB361834•2, VSB541831•2, VSB541834•2
ROT24 •18
20 3/4" VB241831, VB241831 BUTT, VB241831 BUTT•FH, VB241831•FH, VB241834, VB241834 BUTT, VB241834BUTT•FH,
VB241834•FH, VSB241831 BUTT, VSB241834 BUTT, VB271831•FH, VB271834•FH, VSB271831, VSB271834
ROT27 •18
23 3/4"
VB271831
•
FH, VB271834
•
FH
ROT30 •18
26 3/4" VB301831 BUTT•FH, VB301834 BUTT•FH, VSB301831 BUTT, VSB301834 BUTT
ROT33 •18
29 3/4" VB331831 BUTT•FH, VB331834 BUTT•FH, VSB331831 BUTT, VSB331834 BUTT
ROT36 •18
32 3/4" VB361831 BUTT•FH, VB361834 BUTT•FH, VSB361831 BUTT, VSB361834
ROT12 •21
8 3/4" VB122131, VB122134, VCD242131 DL/R2, VCD242134 DL/R3, VSB422131•2, VSB422134•2
ROT15 •21
11 3/4" VB152131, VB152134, VB482131•FH, VB482134•FH, VB602131•FH, VB602134•FH, VCD302131 DL/R2, VCD302134 DL/R3,
VLC152184, VLC152190, VLC152196, VSB482131•2, VSB482134•2, VSB602131•2, VSB602134•2
ROT18 •21
14 3/4" VB182131, VB182131•FH, VB182134, VB182134•FH, VB542131•FH, VB542134•FH, VCD362131 DL/R2, VCD362134 DL/R3,
VCD422134•8, VCD482134•8, VLC182184, VLC182190, VLC182196, VSB362131•2, VSB362134•2, VSB422131•2, VSB422134•2,
VSB482131•2, VSB482134•2, VSB542131•2, VSB542134•2
ROT21 •21
17 3/4" VB212131, VB212131•FH, VB212134, VB212134•FH, VB422131•FH, VB422134•FH, VSB422131, VSB422134
ROT24 •21
20 3/4"
VB241831, VB241834, VB241831BUTT, VB242131BUTT
•
FH, VB241834BUTT, VB242134BUTT
•
FH, VB241831
•
FH, VB242134
•
FH,
VLC241884, VLC241884BUTT, VLC241890, VLC241890BUTT, VLC241896, VLC241896BUTT, VSB241831BUTT, VSB241834BUTT
ROT27 •21
23 3/4" VB272131•FH, VB272134•FH, VSB272131 BUTT, VSB272134
ROT30 •21
26 3/4" VB302131 BUTT•FH, VB302134 BUTT•FH, VSB302131 BUTT, VSB302134 BUTT
ROT33 •21
29 3/4" VB332131 BUTT•FH, VB332134 BUTT•FH, VSB332131 BUTT, VSB332134 BUTT
ROT36 •21
32 3/4" VB362131 BUTT,•FH, VB362134 BUTT•FH, VSB362131 BUTT, VSB362134 BUTT
ROT9 •24
7 1/4"
BBC39
ROT12 •24
8 3/4"
B12, B12•FH, BCD24DL/R-4D, SB12, UB12, UB12•FH
ROT14 •24
10 1/4" BBC42
ROT15 •24
11 3/4" B15, B15•FH, BCD30DL/R-4D, DSB30, SB15, U152484, U152490, U152493, U152496, UB15, UB15•FH
ROT16 •24
13 1/4" BBC45, DSB33
ROT18 •24
14 3/4" B18, B18•FH, B54, BCD36DL/R-4D, DSB36, SB18, U182484, U182490, U182493, U182496, UB18, UB18•FH
ROT19 •24
16 1/4" B39, B39•FH, BBC48, SB39, SB39•FH, UB39•FH
ROT21 •24
17 3/4" B21, B21•FH, B42, B42•FH, SB21, SB42, SB42•FH, UB21, UB42, UB42•FH
ROT22 •24
19 1/4" B45, B45•FH, BBC51, UB45•FH
ROT24 •24
20 3/4" B24, B24 BUTT, B24•FH, B24 BUTT•FH, B48, B48•FH, PBBC27, PBBC27 BUTT, SB24, SB24 BUTT, SB24•FH, SB24 BUTT•FH,
SB48, SB48•FH, U242484, U242484 BUTT, U242490, U242490 BUTT, U242493, U242493 BUTT, U242496, U242496 BUTT,
UB24, UB24 BUTT, UB24•FH, UB24 BUTT•FH, UB48•FH, UBT24 BUTT
ROT27 •24
23 3/4" B27, B27•FH, SB27, SB27•FH, UB27, UB27•FH
ROT30 •24
26 3/4" B30 BUTT, B30 BUTT•FH, SB30 BUTT, SB30 BUTT•FH, U302484 BUTT, U302490 BUTT,
U302493 BUTT, U302496 BUTT, UB30 BUTT, UB30 BUTT•FH
ROT33 •24
29 3/4" B33 BUTT, B33 BUTT•FH, SB33 BUTT, SB33 BUTT•FH, UB33 BUTT, UB33 BUTT•FH
ROT36 •24
32 3/4" B36 BUTT, B36 BUTT•FH, SB36 BUTT, SB36 BUTT•FH, U362484 BUTT, U362490 BUTT,
U362493 BUTT, U362496 BUTT, UB36 BUTT, UB36 BUTT•FH
