Universal Design Cabinets
J7
Universal Cabinets
Universal Sink Front Kit
USFCK30 BUTT•FH
USFCK33 BUTT•FH
USFCK36 BUTT•FH
USFCK42 •FH
• Full-height door
• Toe Kick Backer assembly shipped
unassembled to floor
• Includes floor
• 3/8” thick engineered wood bottom panel
with easy clean laminate on one side; back
side unfinished
• 1/2” thick engineered wood toeboard
PE
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
4ROT
1FWROT
2FWROT
2DROT
4DROT
2DFWROT
CFO
32 ½˝
24˝
Universal Removable Sink Front
URSF30 BUTT
URSF33 BUTT
URSF36 BUTT
URSF42
• Designed for easy field conversion from a
standard sink base functionality to universal
access open space
• Permanently installed countertop support rail
is 3-1/2” high x 3/4” thick solid wood
• Doors and frame are shipped pre-assembled
• 3/4” thick removable plywood bottom panel
with support hardware / leveling legs and a
removable clipped-on toe kick provided
• Matching solid wood baseboard provided for
bottom panel support along the kitchen wall
• Frame attached to bottom panel using quick
connect (cam-locks) fasteners providing a
solid tight joint
• Some field assembly required; instructions and hardware
included
• A Universal Access Panel (UAP) can be purchased separately
to conceal/protect the water and drain lines. See “Panels”
section. Please specify specie and finish
I
Regardless of construction option, sink front is constructed
and shipped the same
Complete flooring under Universal Access
Removable Sink Front to prepare for the future
when sink front and plywood bottom is removed.
PE
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
4ROT
1FWROT
2FWROT
2DROT
4DROT
2DFWROT
CFO
32 ½˝
24˝
Universal Toe Kick
Laminate
UMTK8
UMTK8 •4
Veneer
UWMTK8
UWMTK8 •4
• Laminate, 5 7/16” high x 96” long x 3/16”
thick MDF (Medium Density Fiberboard)
• Veneer, 5 7/16” high x 96” long x 5/32”
thick vennered plywood
•
Matching easy clean laminate on one side
• Grain direction runs lengthwise (when
applicable)
PE
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
4ROT
1FWROT
2FWROT
2DROT
4DROT
2DFWROT
CFO
96˝
5 / ˝
