Base Cabinets
E23
Base End Run Cabinets
Base End Run
Cabinets
Construction Options and
Modifications
I
Available with exceptions
l
Available with an upcharge
v
Included as standard
(Blank)
Not
Available
Material dimensions may vary slightly based on
lumber industry standards.
Specifications subject to change
without
notice.
APC All Plywood Construction
CFO Cabinet Front Only
BEA 12
R
code
depth
hinge
Base Corner Angle
BCA24 BUTT
• One adjustable shelf
• For use at the right or left end of cabinet run
or in a corner
l
APC
l
CFO
24˝
24˝
45
34 ½˝
24˝
24˝
Base End Corner
BEC24
• One adjustable shelf
• Two full-height doors
• For use at the right or left end of cabinet run
or in a corner
l
APC
l
CFO
34 ½˝
24˝
24˝
22½˝
24˝
24˝
17 / ˝
17 / ˝
63.5°
143˝
Base End Angle
Specify R or L
BEA12 R or L
• Two adjustable shelves
• Specify right or left hand to designate 12”
deep orientation
• Designed to transition from 24” deep base
cabinet to 12” deep base cabinet
• 24” deep end
not
designed to be exposed
• Full and Partial Overlay door widths are
similar to avoid interference with adjacent
cabinet doors
l
APC
l
CFO
12˝
12 / ˝
34 ½˝
24˝
/ ˝
12˝
24˝
12 / ˝
17˝
45°
