Base Cabinets
E15
Base Cabinets
Removable Sink Front
One Drawer Front
RSF30 BUTT
RSF33 BUTT
RSF36 BUTT
Two Drawer Fronts
RSF42
• Designed for easy field conversion from
a standard sink base functionality to
universal access open space
• Permanently installed countertop support
rail is 6-1/2” high x 3/4” thick solid wood
with a factory installed standard height
matching false drawer front(s) providing
a seamless sink base appearance. (1) full-
width drawer front on 30”, 33” and 36”
widths; (2) false drawer fronts on 42” wide
• If a shorter countertop support is
required when used for universal access as
additional vertical clearance, a 3” filler can
be used in place of the 6 1/2” high support
rail. Order separately
• 3/4” thick removable plywood bottom
panel with support hardware / leveling
legs and a removable clipped-on toeboard
provided
• Matching solid wood baseboard provided for
bottom panel support along the kitchen wall
• Frame, doors, floor bottom and toeboard can
be flat packed for easy storage in a minimum
amount of space
• Frame attached to bottom panel using quick
connect (cam-locks) fasteners providing a
solid tight joint
• Some field assembly required; instructions and
hardware included
• Doors and frame are shipped pre-assembled
PE
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
CFO
34 ½˝
24˝
Universal Access Panel
UAP30
UAP33
UAP36
UAP42
• Designed for optional use with RSF and
URSF
• Conceals/protects drain and water lines
• Includes one 9” and one 15” high, 3/4”
thick laminate plywood panel
• Panels are held with hidden spring clips,
removable
without
tools for easy access to
plumbing
•
Must
be trimmed when Wood Veneer
Paneling (WSK) is used on adjacent
cabinets
• Installation instructions and mounting
hardware included
PE
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
CFO
New
New
Gray color coding indicates
new product, size or code
Gray color coding indicates
new product, size or code
