Page 417 - 2018 Racecar Engineering Hot Rod and Early Muscle Car Parts and Accessories Catalog

Stage 2 Boost Cooler For Low Level Indicator
Forced Induction Applications SNO40035
SNO20010 Provides notice when the reser-
Suited to forced induction YRLU LV UXQQLQJ ORZ RQ ÀXLG 6LPSOH
applications that are fuel to install and wire in any reservoir.
injected or carbureted,
Stage 2 methanol-water 2.5 Gallon Reservoir Upgrade
injection kit uses boost SNO40014
pressure to progressively
inject water-methanol into the Still fairly small in size,
engine, providing an improve- 2-1/2" gallon tank pro-
ment in horsepower and vides much more range
torque over a wide range of than standard 3 qt.
RPM. Cooler intake charge units. Tank is 13" long
combines to offer increased x 9-1/2" high x 7-1/2"
performance and detonation sup- wide and is sold complete
pression. Kit is sold complete with Ultra with mounting straps, 15'
High Output pump, three quart reservoir, digital variable controller, RI WXELQJ DQG UHTXLUHG ¿WWLQJV
nozzles, and necessary hardware. Includes a solenoid upgrade
(SNO40060) which
should be used with any
Gasoline Boost Cooler SNO310 application that uses a
Unmatched for accuracy and rear mounted reservoir.
adjustability, water-methanol
injection kit is applicable
to any forced induction Dual Nozzle Upgrade
or traditional EFI engine. SNO40040
System, which features an
LCD display screen and on- Kit allows adding another nozzle
WKH À\ DGMXVWDELOLW\ LV HDV\ to any Boost Cooler kit, often
to set-up right from the driver’s required when more volume than
seat. Kit includes Ultra High a single nozzle can provide, or
Output pump, three quart when dual plenum/throttle body/
reservoir, digital variable carburetor set-ups are employed.
mapping controller, nozzles Includes tee junction, quick con-
and necessary hardware. Offered QHFW ¿WWLQJV QR]]OH KROGHU DQG
LQ XQLYHUVDO RU DSSOLFDWLRQ VSHFL¿F NLWV hose.

Nozzle Mounting Bungs
Threaded bungs allow installing an injector Bulkhead Fitting SNO40080
nozzle directly into thin-wall intake tubing. Simply Snow Performance nickel plated 100% methanol
drill a hole and weld in the desired bung. Offered UHVLVWDQW %XONKHDG UHVHUYRLU ¿WWLQJ 7KLV VPDOO
in aluminum or steel, 1" diameter bungs are 1/4" EXONKHDG ¿WWLQJ HVWDEOLVKHV D VHFXUH FRQQHFWLRQ
thick and have 1/8"NPT threads. WR DQ\ 2(0 ZLQGVKLHOG ZDVKHU ÀXLG RU RWKHU H[LVW-
ing reservoir to water-methanol 1/4" High Temp Nylon Tubing.
Part No. Description
SNO40120 Aluminum Nozzle Mounting Bung
SNO40130 Steel Nozzle Mounting Bung
Solenoid Upgrade
SNO40060
Shut-off style solenoid is required when
mounting the injection nozzle lower than
the reservoir or when the reservoir is rear-
PRXQWHG WR SUHYHQW JUDYLW\ ÀRZLQJ 6ROHQRLG LV
also used to prevent siphoning when the injection
nozzle is mounted after the throttle body and is
exposed to vacuum.

416 2018 HOT ROD AND EARLY MUSCLE
