Page 376 - 2018 Racecar Engineering Hot Rod and Early Muscle Car Parts and Accessories Catalog

QA152422
GM Suspension Quick Guide
Front Rear Upper QA15249 Sway
Control Arms Trailing Arms Bar
Upper Lower Tie Rod Adj. Rear
Make/Model Year Street Street Adj. Tubular Sleeves Frame Supports Front Rear Kit
A-Body 1964-67 QA152422 QA152437(A) QA15249(N) QA15269(N) QA15250 QA15283 QA152870 QA152871 QA152873
A-Body 1968-70 QA152422 QA152437(A) QA15248 QA15268 QA15250 QA15284 QA152870 QA152871 QA152873
A-Body 1971-72 QA152422 QA152437(A) QA15248 QA15268 QA15252 QA15284 QA152870 QA152871 QA152873
A/G-Body 1978-88 QA152435 QA152464(B) QA15247 QA15267 QA15250 QA15285 — — QA152879
F-Body 1967-69 QA152417 QA152419(A) — — QA15251 — QA152816 — —

Mopar Suspension Quick Guide
QA152303
Front
Control Arms
Dynamic Front
Make/Model Year Upper Lower K-Members Strut Bars Sway Bars
A-Body 1964-66 QA152303 QA152307(B) — QA152311 —
A-Body 1967-72 QA152303 QA152307(B) QA152313 QA152311 QA152861(F)
A-Body 1973-76 QA152301(A) QA152307(B) QA152311 —
A-Body 1977-79 — — — — —
QA152307
B-Body 1962-65 QA152305 QA152308(C) — QA152312 —
B-Body 1966-70 QA152305 QA152308(C,E) QA152315 QA152312 QA152861(F)
B-Body 1971-72 QA152305 QA152308(C) QA152314 QA152312 —
E-Body 1970-74 QA152305 QA152308(C) QA152314 QA152312 —
Footnotes For GM Suspensions
A Add Coil Spring Adapter part #7720-168 for control arm to accept stock springs
B Add Coil Spring Adapter part #7720-203 for control arm to accept stock springs
N 1964 GM A-Bodies require upper trailing arm bushing part #9032-383
Footnotes For Mopar Suspensions
A Fits A-body with 1973-76 disc brake spindles (large ball joint)
B Will work on 1967-72 A-body with QA1 K-member and sway bar, and 64-72 A-body without sway bar
C Direct fit for 1970-72 B-body. Will work on 1966-69 B-body with QA1 K-member and sway bar, and 1962-72 B-body without sway bar
E Only Remmended for use with #52315 abd 1971-72 B-Body ir E-Body sway bar or with factory K-member and no sway bar
F Fits with QA1 K-member only

1968-72 GM A-Body Suspension Kit 1970-81 GM F-Body Suspension Kit
Handling Level 2 Handling Level 2
INCLUDES THE FOLLOWING INCLUDES THE FOLLOWING SUSPENSION COMPONENTS:
SUSPENSION COMPONENTS: QA1GS501-10400C Front Single
QA1GS401-10400B Front Single Adjustable Pro Coil Shock System
Adjustable Pro Coil Shock System (2) QA1TS702 Rear Single Adjustable
QA1RCK52340 Rear Single Stocker Star Shocks
Adjustable Pro Coil Shock System QA17888-109 Thrust Bearing Kit
(2) QA17888-109 Thrust Bearing Kit QA152882 Front Sway Bar
QA152873 Front and Rear Sway Bars QA152422 Upper Street Control Arms
QA15205 Boxed Lower Trailing Arms QA152437 Lower Street Control Arms QA1HK12-GMF2
QA15268 Tubular Upper Trailing Arms QA15252 Tie Rod Adjuster Sleeves
QA152422 Upper Street Control Arms Part No. Description
QA152437 Lower Street Control Arms QA1HK02-GMF2 Handling Kit With Shocks
QA152399 Lower Control Arm Hardware Kit QA1HK02-GMA2 QA1HK12-GMF2 Handling Kit Without Shocks
QA15211 Tubular Braces
QA15217 Trailing Arm Hardware Kit
Part No. Description
QA1HK02-GMA2 Handling Kit With Shocks
QA1HK12-GMA2 Handling Kit Without Shocks

2018 HOT ROD AND EARLY MUSCLE 375
