Elite Series Hedders
(OLWH KHGGHUV DUH EXLOW ZLWK WKH ¿QHVW PDWHULDOV LQFOXGLQJ KHDY\ JDXJH WXELQJ WKLFN ÀDQJHV FHUDPLF FRDWHG
DQG LQFOXGH JDVNHWV EROWV UHGXFHUV DQG LQVWUXFWLRQV
Auto Std.
Application Year Engine Part No Footnotes A/C P/S Column Auto Floor Column Std. Floor Tube Sizes
Buick
Regal 1978-87 283-400 HED68608* 1, 6, 15, 45, 103, 131, 212 Y Y Y Y Y Y 1-5/8", 3"
Chevrolet
Camaro 1967-81 283-400 HED68278* 1, 6, 45, 49, 104, 121, 212 7, 26 Y Y Y N Y 1-5/8", 3"
Camaro 1967-81 283-400 HED68608* 1,6,15,45,49,103,121, 212 7, 26 Y Y Y N N 1-5/8", 3"
Camaro 1967-69 396-502 HED68198* 1, 20, 45, 49, 208, 213 Y N Y Y Y Y 1-3/4", 3"
Camaro 1967-81 396-502 HED68618* 1, 6, 15, 20, 45, 49, 208, 213 Y Y N Y N Y 1-3/4", 3"
Camaro 1982-92 283-400 HED68478* 1, 6, 15, 45, 103, 121, 212 Y Y Y Y N N 1-5/8", 3"
Chevelle 1964-77 283-400 HED68298* 1, 6, 45, 49, 103, 212 26 Y Y Y N Y 1-5/8", 3"
Chevelle 1964-87 283-400 HED68608* 1, 6, 15, 45, 49, 103, 121, 212 26 Y Y Y N N 1-5/8", 3"
Chevelle 1964-77 396-502 HED68198* 1, 6, 20, 45, 49, 208, 213 Y Y Y Y N Y 1-3/4", 3"
Chevelle 1968-77 396-502 HED68618* 1, 6, 15, 20, 45, 49, 208, 213 Y Y N Y N Y 1-3/4", 3"
Nova 1968-79 283-400 HED68608* 1, 6, 15, 45, 49, 103, 212 N Y N Y N N 1-5/8", 3"
Nova 1968-74 396-502 HED68198* 1, 6, 20, 45, 49, 208, 213 Y N Y Y N Y 1-3/4", 3"
Nova 1968-79 396-502 HED68618* 1, 6, 15, 20, 45, 49, 208, 213 N N N Y N Y 1-3/4", 3"
Monte Carlo 1970-77 283-400 HED68298* 1, 6, 45, 103, 212 26 Y Y Y N Y 1-5/8", 3"
Monte Carlo 1970-87 283-400 HED68608* 1, 6, 15, 45, 103, 121, 212 26 Y Y Y N N 1-5/8", 3"
Monte Carlo 1970-77 396-502 HED68618* 1, 6, 15, 20, 25, 45, 208, 213 Y Y Y Y N Y 1-3/4", 3"
Full Size 1958-64 283-400 HED68238 103, 212 26 Y Y Y Y Y 1-5/8", 3"
Full Size 1965-70 396-502 HED68198 1, 20, 208, 213 Y Y Y Y Y Y 1-3/4", 3"
Full Size 1965-74 396-502 HED68618 1, 6, 15, 20, 45, 208, 213 Y Y N Y N Y 1-3/4", 3"
Full Size 1971-94 283-400 HED68298* 1, 6, 45, 103, 121, 212 26 Y Y Y N N 1-5/8", 3"
Full Size 1971-94 283-400 HED68608* 1, 6, 15, 45, 49, 103, 121, 212 26 Y Y Y N N 1-5/8", 3"
Corvette 1963-82 283-400 HED68308* 1, 6, 45, 100, 103, 212 26 Y Y Y N Y 1-5/8", 3"
Dodge And Plymouth
Barracuda 1970-74 361-440 HED78038 1, 129 Y Y Y Y Y Y 1-3/4", 3"
Belvedere 1967-74 361-440 HED78038 1, 129 Y Y N Y N Y 1-3/4", 3"
Challenger 1970-74 361-440 HED78038 1, 129 Y Y Y Y Y Y 1-3/4", 3"
Charger 1966-74 361-440 HED78038 1, 129 Y Y Y Y Y Y 1-3/4", 3"
Road Runner 1968-74 361-440 HED78038 1, 129 Y Y Y Y Y Y 1-3/4", 3"
Super Bee 1967-74 361-440 HED78038 1, 129 Y Y Y Y Y Y 1-3/4", 3"
Ford
Fairlane 1966-73 260-351W HED88308 1, 108, 204 Y 27 N Y N Y 1-5/8", 3"
Fairlane 1966-73 260-351W HED88408 1, 6, 15, 42 Y Y N Y N N 1-1/2", 2-1/2"
Falcon 1962-70 260-302W HED88408 1, 6, 15, 42 Y Y N Y N N 1-1/2", 2-1/2"
Falcon 1966-69 260-302W HED88308 1, 108, 204 Y 27 N Y N Y 1-5/8", 3"
Maverick 1969-77 260-302W HED88308 1, 6 Y 27 N Y N Y 1-5/8", 3"
Maverick 1969-77 260-302W HED88408 1, 6, 15, 42 Y 27 N Y N N 1-1/2", 2-1/2"
Mustang 1964-73 260-302W HED88308 1, 19, 108 Y 27 N Y N Y 1-5/8", 3"
Mustang 1969-73 351W HED88308 1, 108 Y Y N Y N N 1-5/8", 3"
Mustang 1964-73 260-302W HED88408 1, 6, 15, 42 Y Y N Y N N 1-1/2", 2-1/2"
Torino 1966-73 260-351W HED88308 1, 108 Y 27 N Y N Y 1-5/8", 3"
Cougar 1964-73 260-302W HED88408 1, 6, 15, 42 Y Y N Y N Y 1-1/2", 2-1/2"
Cougar 1967-73 260-302W HED88308 1, 19, 108 Y 27 N Y N N 1-5/8", 3"
Pontiac
Firebird 1982-91 283-400 HED68478* 1, 6, 15, 45, 103, 121, 131, 212 Y Y Y Y N Y 1-5/8", 3"
Grand Prix 1978-87 283-400 HED68608* 1, 6, 15, 45, 103, 131, 212 Y Y Y Y N N 1-5/8", 3"
* Not applicable or intended for street or highway use. Legal only for racing vehicles.
Footnotes: 103 Will Fit With Angle Plug Heads. (Chevy Aluminum Only.)
0 T.e.m.s.tm Tubular Exhaust Manifold System. 104 On Some Models It May Be Necessary To Remove Z Bars (Ss Series).
1 Without Smog Injection Or Injection Heads. 108 With Automatic Transmission, C-4 Only.
6 Modification To Stock Exhaust Required To Retain Catalytic Converter. 109 Dual Exhaust Only, Limited Ground Clearance.
7 Will Not Fit 1967-69 Camaro With A/C. 121 Must Modify Rotary A/C Bracket.
9 Factory Side Exhaust, Cut And Welding Required. Fits 1964-67 Models With
13 A-Type Engine Only. 128 Factory Stock Transmissions And 153 Tooth Flywheel Only.
15 Shortie Style Hedder (Maximum Ground Clearance). 129 Modification To Shift Linkage May Be Required.
19 Will Not Fit 1971-73 With Stick Shift. 131 Chevy Engine
20 Not Recommended For Use With Aluminum Heads. 135 Transmission Limited To 700R-4 Or Th-350.
25 Engine Swap, All Parts Must Be Factory Stock. 157 When Equipped With 4-Speed, Will Not Fit Top Loader.
A/C Equipped Vehicles Require Bracket Hed20110. 204 With Egr.
26
(Large Piston Type Compressor) Due To Cylinder Heads (Aluminum), Gen 6 Engines,
27 Power Steering Bracket Hed20120 Required. 208 502 Big Block Chevy May Have Clearance Problems. Bottom Of
30 Dog Leg Port Only. Header Flanges May Hit Head Bolts (Notching May Be Necessary).
42 Square Port Hedder, Will Not Fit D-Port. 212 Use Elite Replacement Gasket HED27520.
Not Legal For Sale Or Use In California 213 Use Elite Replacement Gasket HED27550.
45
On Pollution Controlled Motor Vehicles. 221 Engine Must Be Centered Between The Rails.
49 Will Not Fit (Saginaw) P/S Close Ratio. 222 Modifications To Clutch Linkage May Be Required.
100 Will Not Fit With Steering Damper Inside Front Crossmember.
