Page 174 - 2018 Racecar Engineering Hot Rod and Early Muscle Car Parts and Accessories Catalog

NOTE: RED IS AVAILABLE. CHANGE “G” TO “R” WHEN ORDERING

Mustang II Control Arm Bushings l Arm BBususususususushihihihihhh ngngnggggggggssssssss Greaseable Type Sway Bar Bushing Sets
ENE4-3130G %XVKLQJV KDYH JUHDVH ¿WWLQJV DQG D
unique channel design which diverts
grease to all inner surfaces, virtually
eliminating squeaking. Use the dimen-
sional drawings to determine the proper
Mustang II Rack Mount Bushing ggggggg size for each application. The bolt slot
ENE4-10101G dimensions were designed for 10mm or
3/8" diameter mounting bolts. Choose the sway bar bracket size that
most closely matches existing bar.
Mustang II Bar Diameter “A” Greaseable Set
Strut Rod Bushings 5/8"/16mm ENE9-5154G
ENE4-7113G 11/16"/17.5mm ENE9-5155G
3/4"/19mm ENE9-5156G
13/16"/20.5mm ENE9-5157G
Mustang II Tie Rod Boots 7/8"/22mm ENE9-5158G
15/16"/24mm ENE9-5160G
Part No. Description
ENE9-13101G Black Mustang II Tie Rod Boots, Pair 1"/25mm ENE9-5161G
ENE9-13101R Red Mustang II Tie Rod Boots, Pair 1-1/16"/27mm ENE9-5162G
1-1/8"/28.5mm ENE9-5164G
Complete End Link Kits 1-1/4"/31.5mm ENE9-5165G
The set includes bushings, zinc plated 3/8" grade 5 bolts, “nylock” Non-Greaseable Type
nuts and heavy gauge washers.
To Determine Fit: Vehicle must be on level ground (not jacked up) Sway Bar Bushing Sets
with wheels supporting it. Make sure stabilizer bar and eyelet (B) Economical HYPER-FLEX bushings with matching heavy gauge
™
are parallel to control arm (C). Many times they are not. You may be brackets deliver maximum performance for a vehicle’s sway bar
required to use a slightly longer or shorter sleeve length than the system. Use the dimension drawings to determine the proper size
RULJLQDO 0HDVXUH VOHHYH OHQJWK $ DQG FRPSDUH WR WKH FKDUW WR ¿QG IRU DSSOLFDWLRQ 7KH EROW VORW GLPHQVLRQV ¿W PP RU GLDPHWHU
the correct set. mounting bolts. Choose the sway bar bracket size that most closely
“A” Length Set Number matches existing bar.
1" ENE9-8122G
1-5/8" ENE9-8120G
2" ENE9-8123G
2-3/8" ENE9-8125G
2-5/8" ENE9-8117G
2-7/8" ENE9-8118G
3-3/8" ENE9-8119G
3-9/16" ENE9-8124G
4-1/2" ENE9-8121G
Drawing 1 Drawing 2
Drawing 1 Type Drawing 2 Type
Bar Diameter “A” Non-Greaseable Non-Greaseable
5/8"/16mm — ENE9-5104G
1960-72 Chevy C-10 Truck 11/16"/17.5mm — ENE9-5105G
Rear Tracking Arm Bushing Set 3/4"/19mm ENE9-5123G ENE9-5106G
ENE3-7104G 13/16"/20.5mm — ENE9-5107G
21mm ENE9-5125G —
7/8"/22mm ENE9-5126G ENE9-5108G
23mm — —
15/16"/24mm ENE9-5128G ENE9-5109G
1"/25mm ENE9-5129G ENE9-5110G
1-1/16"/27mm — ENE9-5111G
1-1/8"/28.5mm — ENE9-5112G
1-1/4"/31.5mm — ENE9-5113G
32mm — ENE9-5116G
1 5/16"/33mm — ENE9-5114G
