Headers
(YHU\ 'RXJ¶V KHDGHU LQFOXGHV PRXQWLQJ KDUGZDUH FROOHFWRU UHGXFHUV RU FRQQHFWRU SLSHV SUHPLXP JDVNHWV DQG
GHWDLOHG LQVWDOODWLRQ LQVWUXFWLRQV 7KH SUHPLXP JDVNHWV DUH H[WUD WKLFN DQG UDWHG XS WR ƒ) SUHVVXUHV WR 36,
EDU DQG KDYH DQ H[DFW SRUW PDWFK ZLWK 'RXJ¶V KHDGHUV $OO KHDGHUV DUH PHWDOOLF FHUDPLF WKHUPDO EDUULHU FRDWHG
Note: Listed headers are legal only for off-highway use, racing use or for use on pre-emission-controlled motor vehicles.
Auto Std. Tube Collector Port
Part No. Models And Years Engines Footnotes AC P/B P/S Col Flr Col Flr Size (In.) Size (In.) Shape
Chevy
DGHD368 Camaro 1967-69 265-400 36, 52, 92, 93 N Y Y N Y N Y 1-3/4 3 Same As Port
DGHD308 Camaro 1967-81 265-400 36, 61, 92, 93, 96 Y Y Y N Y N Y 1-5/8 3 Oval
DGHD313 Camaro 1967-74 396-502 52,69,202 Y Y Y N Y N N 1-3/4 3 SAP
DGHD319 Camaro 1967-69 396-502 69 N Y N Y Y N Y 2-1/8 3-1/2 Round
DGHD319-R Camaro 1967-69 396-502 69 N Y N Y Y N Y 2-1/8 3-1/2 Round
DGHD320 Camaro 1967-69 396-502 69,227 Y Y Y Y Y N Y 2 3-1/2 SAP
DGHD308 Chevelle/El Camino 1964-87 265-400 36, 92, 93, 96 Y Y Y N Y N Y 1-5/8 3 Oval
DGHD306 Chevelle/El Camino 1968-77 396-502 5, 52, 69 Y Y Y N Y N Y 1-3/4 3 Same As Port
DGHD316 Chevelle 1968-74 396-502 69 Y Y Y Y Y N Y 1-7/8 3-1/2 SAP
DGHD316-B Chevelle 1968-74 396-502 69 Y Y Y Y Y N Y 1-7/8 3-1/2 SAP
DGHD317 Chevy II 1962-67 265-400 17,60,96,205,222 Y Y Y Y Y N N 1-3/4 3 SAP
DGHD368 Chevy II, Nova 1968-74 265-400 36, 92, 93 N Y Y N Y N Y 1-3/4 3 Same As Port
DGHD308 Chevy II, Nova 1968-79 265-400 36, 92, 93, 96 Y Y Y Y Y N N 1-5/8 3 Oval
DGHD306 Chevy II, Nova 1968-79 396-502 5, 52, 69 Y Y N N Y N Y 1-3/4 3 Same As Port
DGHD3330 Corvette 1992-96 350 17,29,122,155 Y Y Y N Y N Y 1-3/4 3 Rectangle
DGHD308 Monte Carlo 1970-87 265-400 36, 92, 93, 96 Y Y Y Y Y N N 1-5/8 3 Oval
DGHD306 Monte Carlo 1970-77 396-502 5, 69, 93 Y Y Y N Y N Y 1-3/4 3 Same As Port
DGHD308 Passenger Car, Wagon 1965-89 265-400 36, 92, 93, 96 Y Y Y N Y Y Y 1-5/8 3 Oval
DGHD306 Passenger Car, Wagon 1965-74 396-502 5, 52, 69 Y Y Y N Y N Y 1-3/4 3 Same As Port
Dodge
DGHD452 Challenger 1970-74 426 WDG, 440 127, 215 Y Y Y N Y N Y 2 3-1/2 Same As Port
DGHD452 Charger 1966-72 426 WDG, 440 127, 215 Y Y Y Y Y Y Y 2 3-1/2 Same As Port
DGHD452 Coronet 1962-72 426 WDG, 440 127, 215 Y Y Y Y Y Y Y 2 3-1/2 Same As Port
DGHD452 Super Bee 1968-72 426 WDG, 440 127, 215 Y Y Y Y Y Y Y 2 3-1/2 Same As Port
Ford
DGHD625 Fairlane 1964-73 260-302
DGHD660YA Falcon 1960-65 260-302 90, 100, 126, 216 Y Y Y 41 41 N N 1-5/8-2 2-1/2 Same As Port
DGHD660YA Ranchero 1960-65 260-302 90, 100, 126, 216 Y Y Y 41 41 N N 1-5/8-2 2-1/2 Same As Port
Plymouth
DGHD452 Barracuda 1970-74 426 WDG, 440 127, 215 Y Y Y N Y N Y 2 3-1/2 Same As Port
DGHD452 Belvedere 1962-72 426 WDG, 440 127, 215 Y Y Y Y Y Y Y 2 3-1/2 Same As Port
DGHD452 Fury 1962-72 426 WDG, 440 127, 215 Y Y Y Y Y Y Y 2 3-1/2 Same As Port
DGHD452 GTX 1966-72 426 WDG, 440 127, 215 Y Y Y Y Y Y Y 2 3-1/2 Same As Port
DGHD452 Roadrunner 1968-72 426 WDG, 440 127, 215 Y Y Y Y Y Y Y 2 3-1/2 Same As Port
Pontiac
DGHD569 Firebird, Trans Am 1967-69 326-455 93, 104 Y Y Y N Y N Y 1-3/4 3 D-Port
DGHD568 Firebird, Trans Am 1967-69 326-455 93, 132, 136, 191 Y Y Y N Y N Y 1-7/8 3-1/2 Round
DGHD581 Firebird, Trans Am 1970-81 326-455 93, 132, 191 Y Y Y N Y N Y 1-7/8 3-1/2 Round
DGHD564 GTO/Lemans/Tempest 1964-67 326-455 93, 104, 134, 136, 191 Y Y Y N Y N Y 1-3/4 3 D-Port
DGHD567 GTO/Lemans/Tempest 1964-72 326-455 93, 104, 132, 134, 136, 190, 191 Y Y Y N Y N Y 1-7/8 3-1/2 Round
DGHD569 GTO/Ventura 1974 326-455 93 Y Y Y N Y N Y 1-3/4 3 D-Port
Footnotes: Some Factory Heads Do Not Have End Bolt Holes
R Raw Steel 104 And Should Be Drilled And Tapped To Assure Sealing.
B Hi-Temp Black 126 Y Indicates Tri-Y Design.
5 Shorty Design For Maximum Ground Clearance. 127 Fits With Mopar Mini-Starter Pn P5249644.
36 Fits D-Port Cylinder Heads Including Zz4 Crate Engines. 132 Fits Edelbrock Performer, Ram-Air, Super Duty And H.o. Heads Only.
52 Will Not Fit Saginaw Close Ratio With 825 Power Steering Box. 133 Does Not Fit With Powerglide Transmission.
60 Will Not Fit 168-Tooth Flywheels Or Kickout Aftermarket Starters. 134 4-Speed Applications Must Use ’64-65 Z-Bar Pn 9776376.
61 Does Not Fit 67-69 Camaro With Ac. Application With Scatter Shield Or Factory Bell Housings With Dual
Big Block Frame Stands And Motor Mounts 136 Starter Pockets Must Use Fram Oil Filter Pn. Ph3675 Or Equivalent.
69
Must Be Used To Insure Proper Engine Location And Header Fit. Will Work With Column Shift,
90 Will Not Fit With C-6 Transmission. 183 Must Use “Chevy Ii Only” Conversion Kit Pn 01036.
92 Will Fit Most Angle Plug Heads Including Factory Chevrolet “Bow Tie”. Turbo 400 Equipped Applications
Requires Removal Or Modification 190 Must Use Shorter Aftermarket Modulator Valve (2-3/4" Long).
93
Of Locking Steering Columns If Equipped. 191 Header Fits With Milodon Oil Pans 30355, 31660 And 31665.
Installation Requires Left Side Ac Bracket Part Number H7608. Designed For Original Heads. 1975 And Later Models
96 1979 And Later Vehicles With Short Compressors 215 May Require Modification Tp Flange.
Can Use The Stock Bracket. 216 Will Not Fit New Cast Iron Ford Dart Engine Blocks.
100 Will Not Fit Models With Air Injection Hoods.
Electric Exhaust Cut-Out Kits
8QFRUN WKH H[KDXVW V\VWHP ZLWK WKH ÀLS RI D VZLWFK +L WHFK VWDLQOHVV VWHHO FXW RXWV DUH EXLOW WR ODVW DQG IHDWXUH 'D\WRQ
JHDU UHGXFWLRQ PRWRUV UDFN DQG SLQLRQ GULYH PHFKDQLVPV VHOI FOHDQLQJ NQLIH HGJH VHDWV IRU OHDN SURRI VHDO DQG ZLULQJ
KDUQHVVHV IRU HDV\ LQVWDOODWLRQ .LWV LQFOXGH WZR FXW RXWV DQG WZR KDUQHVVHV
Part No. Tube Diameter
DGHDEC250A 2-1/2"
DGHDEC300A 3"
