Page 196 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Main Jet Removal Tool HLY26-68 Trick Kit
Removes Holley jets without damage. Kit includes the same gaskets and seal set as the Renew Kits, with
extra performance tuning parts.
Fast Kits
The economical way to rebuild any Holley carb.
Include fuel bowl gaskets, metering block gas-
kets, base gasket, throttle body gasket, accelera-
tor pump diaphragms, needle and seats, power
valves, bowl screw gaskets and instructions.
Part No. Description
HLY37-1543 Model 2300 2BBL
HLY37-1544 Model 4150 Double Pumper
HLY37-1546 Model 4150 HP Double Pumper
Part No. Fits These Carburetor Models
Renew Kits 4150HP
Kits include complete carburetor gasket and seal set,and instruc- 0-4295 0-4296 0-4493 0-4559 0-4776-1
tions. 0-4776-2 0-4776-3 0-4776-4 0-4777 0-4777-1
0-4777-2 0-4777-3 0-4777-4 0-4778 0-4778-1
0-4778-2 0-4778-3 0-4778-4 0-4779 0-4779-1
0-4779-2 0-4779-3 0-4779-4 0-4779-5 0-4780
0-4780-1 0-4780-2 0-4780-3 0-4780-4 0-4781
0-4781-1 0-4781-2 0-4781-3 0-4781-4 0-4788
HLY37-933
0-4788-1 0-4830 0-6109 0-8156 0-8162
0-8804 0-9379 0-9380 0-9381 0-80776
0-80777 0-80778 0-80779 0-80780 0-80781
0-7320-1 0-8082-1 0-8896 0-9375-1 0-9377-1
0-9645 0-9646 0-80186-1 0-80496-1 0-80498-1
Part No. Fits These Carburetor Models 0-80513-1 0-80514-1 0-80528-1 0-80529-1 0-80532-1
4150 Models including 0-80533-1 0-80535-1 0-80541-1 0-80542-1 0-80556-1
0-4295 0-4296 0-4493 0-4559 0-4776-1
0-4776-2 0-4776-3 0-4776-4 0-4777 0-4777-1 Air Cleaner, Throttle Body And Base Gaskets
0-4777-2 0-4777-3 0-4777-4 0-4778 0-4778-1
0-4778-2 0-4778-3 0-4778-4 0-4779 0-4779-1 Replacement air cleaner (air horn), throttle body and base gaskets
0-4779-2 0-4779-3 0-4779-4 0-4779-5 0-4780 HYL ZVSK PUKP]PK\HSS` \USLZZ ZWLJPÄLK
HLY37-485
0-4780-1 0-4780-2 0-4780-3 0-4780-4 0-4781
0-4781-1 0-4781-2 0-4781-3 0-4781-4 0-4788
0-4788-1 0-4830 0-6109 0-8156 0-8162
0-8804 0-9379 0-9380 0-9381 0-80776
0-80777 0-80778 0-80779 0-80780 0-80781
4150HP Models including
0-7320-1 0-8082-1 0-8896 0-9375-1 0-9377-1
0-9645 0-9646 0-80186-1 0-80496-1 0-80498-1
HLY37-1539 Part No. Description
0-80513-1 0-80514-1 0-80528-1 0-80529-1 0-80532-1 HLY108-4 Air Cleaner Gasket, 5" Dia., .060" Thick, 3-Pack
0-80533-1 0-80535-1 0-80541-1 0-80542-1 0-80556-1 HLY108-62 Air Cleaner Gasket, 5" Dia., .200" Thick
HLY108-5 Throttle Body Gasket, 4150/4160, 1-11/16" x 1-11/16" Bore Size
Gasket Assortment Kit HLY108-7 Throttle Body Gasket, 4150/4160, 1-3/4" x 1-3/4" Bore Size
HLY108-12 Base Gasket, 4010, 4150/4160, 5/16" Thick With Studs Included
HLY108-200 HLY108-10 Base Gasket, 4150/4160, 1/16" Thick
Includes (2) of each HLY108-83 fuel
bowl and HLY108-89 metering block
gaskets, packaged together. Covers Fuel Inlet Fitting Gaskets HLY108-1
most popular Holley 4BBL carburetors. Part No. Description
HLY108-1 9/16", Fuel Bowl Inlet Fitting Gasket
HLY108-8 7/8", Fuel Bowl Inlet Fitting Gasket
Fuel Bowl And Metering Block Gaskets HLY26-102 7/8" Nylon, Fuel Bowl Inlet Fitting Gasket
Gaskets to keep on hand for jet changes in the pits. Two per pack.
Part No. Description
Fuel Bowl Gaskets Bowl Screw Gaskets
HLY108-83-2 Blue Non-Stick For 2300, 4150/4160 And 4500 2-Circuit Carbs Part No. Description HLY26-102
HLY108-92-2 Blue Non-Stick For 4165, Some 4150/4160 Primary Side And 2300 Standard Replacement Paper Gaskets,
HLY108-120 Blue Non-Stick For 4150/4160 HLY108-2-20 Set of 20
Metering Block Gaskets HLY108-98-10 Reusable Nylon Gaskets, Set of 10
Blue Non-Stick, Most 4150’s, Some 4160’s, Early 4165’s,
HLY108-89-2*
Most 2300’s And all 4500’s Without Intermediate System
Blue Non-Stick, Most 4150’s, Some 4160’s, Early 4165’s, Fuel Bowl Sight Plug HLY26-13
HLY108-121* Most 2300’s And all 4500’s Without Intermediate Idle System,
Secondary Metering Block Gasket On Double Pumpers Sold in pair.
* Not used with accelerator pump transfer tube.
