AN Flare Bulkhead Adapters AN Flare To ORB Adapters
“A” “B” Black Blue “A” “B”
Black Blue Dash Dash Part No. Part No. Dash Size SAE Size A B
Part No. Part No. Size Size Aluminum O-Ring Boss
Aluminum FRG495124-BL — -4 3/8"-24 (-3)
Straight Bulkhead A B FRG495125-BL — -4 7/16"-20 (-4)
FRG483203-BL FRG483203 -3 -3 FRG495110-BL — -4 9/16"-18 (-6)
FRG483204-BL FRG483204 -4 -4 FRG495111-BL — -4 3/4"-16 (-8)
FRG483206-BL FRG483206 -6 -6 A B FRG495112-BL — -4 7/8"-14 (-10) A B
FRG483208-BL FRG483208 -8 -8 FRG495100-BL FRG495100 -6 9/16"-18 (-6)
FRG483210-BL FRG483210 -10 -10 FRG495101-BL FRG495101 -6 3/4"-16 (-8)
A
FRG483212-BL FRG483212 -12 -12 FRG495113-BL FRG495113 -6 7/8"-14 (-10)
FRG483216-BL — -16 -16 FRG495114-BL — -6 1-1/16"-12 (-12)
FRG483220-BL FRG483220 -20 -20 B FRG495102-BL FRG495102 -8 9/16"-18 (-6)
Aluminum 45° Bulkhead FRG495103-BL FRG495103 -8 3/4"-16 (-8)
FRG483703-BL — -3 -3 FRG495104-BL FRG495104 -8 7/8"-14 (-10)
Aluminum 90° Bulkhead A FRG495115-BL — -8 1-1/16"-12 (-12)
FRG483303-BL FRG483303 -3 -3 FRG495116-BL — -8 1-5/16"-12 (-16)
FRG483304-BL FRG483304 -4 -4 A FRG495105-BL FRG495105 -10 3/4"-16 (-8)
FRG483306-BL FRG483306 -6 -6 FRG495106-BL FRG495106 -10 7/8"-14 (-10)
FRG483308-BL FRG483308 -8 -8 B FRG495107-BL FRG495107 -10 1-1/16"-12 (-12)
FRG483310-BL FRG483310 -10 -10 FRG495117-BL — -10 1-5/16"-12 (-16)
FRG483312-BL — -12 -12 FRG495122-BL — -12 3/4"-16 (-8)
FRG483316-BL — -16 -16 B FRG495108-BL FRG495108 -12 7/8"-14 (-10)
FRG495109-BL FRG495109 -12 1-1/16"-12 (-12)
FRG495118-BL — -12 1-5/16"-12 (-16)
“A” “B” “C” FRG495120-BL — -16 1-1/16"-12 (-12)
Black Blue Dash Dash Dash A B FRG495119-BL — -16 1-5/16"-12 (-16)
Part No. Part No. Size Size Size
A B FRG495123-BL — -20 1-5/16"-12 (-16)
Aluminum
Bulkhead Tee On-The-Side
FRG483403-BL FRG483403 -3 -3 -3 C NPT Adapters
FRG483404-BL — -4 -4 -4 Black Blue “A” “B”
C
FRG483406-BL — -6 -6 -6 C Part No. Part No. NPT Size NPT Size B A
FRG483408-BL FRG483408 -8 -8 -8 Aluminum NPT Reducer
FRG483410-BL — -10 -10 -10 FRG491201-BL FRG491201 1/8" 1/4"
B A FRG491202-BL FRG491202 1/4" 3/8"
Aluminum
Bulkhead Tee On-The-Run C FRG491203-BL FRG491203 1/8" 3/8"
FRG491204-BL FRG491204 3/8" 1/2"
FRG480403-BL FRG480403 -3 -3 -3 B A
FRG491205-BL FRG491205 1/4" 1/2"
FRG491206-BL FRG491206 1/8" 1/2"
B A
FRG491207-BL FRG491207 1/2" 3/4"
Black Blue “A” FRG491208-BL FRG491208 3/8" 3/4"
Part No. Part No. Dash Size
FRG491209-BL FRG491209 1/4" 3/4"
Fuel Cell Bulkhead
FRG483108-BL — -8
FRG483110-BL — -10 A B
Blue
Black
“A”
FRG483112-BL — -12 Part No. Part No. NPT Size
Aluminum Bulkhead Nut Aluminum
FRG492403-BL FRG492403 -3 Male NPT Nipple
FRG492404-BL FRG492404 -4 FRG491101-BL FRG491101 1/8"
FRG492406-BL FRG492406 -6 FRG491102-BL FRG491102 1/4"
FRG492408-BL FRG492408 -8 FRG491103-BL FRG491103 3/8"
FRG492410-BL FRG492410 -10 FRG491104-BL FRG491104 1/2"
FRG492412-BL FRG492412 -12 Aluminum
FRG492416-BL — -16 Female NPT Coupler
FRG492420-BL FRG492420 -20
FRG491001-BL FRG491001 1/8"
Aluminum
Internal Allen NPT Plug
Nylon Sealing Washers FRG493201-BL FRG493201 1/16"
Part No. Description FRG493202-BL FRG493202 1/8"
9/16" ID (-6AN), FRG493203-BL FRG493203 1/4"
FRG999126
10-Pack FRG493204-BL FRG493204 3/8"
3/4" ID (-8AN), FRG493205-BL FRG493205 1/2"
FRG999128
10-Pack FRG493206-BL FRG493206 3/4"
7/8" ID (-10AN), Aluminum Hex NPT Plug
FRG999130
10-Pack FRG493301-BL — 1/8"
1" ID (-12AN) — FRG493302 1/4"
FRG999132
10-Pack FRG493303-BL FRG493303 3/8"
FRG493304-BL FRG493304 1/2"
FRG493306-BL FRG493306 3/4"
