2020 DRAG RACING

Electrical, Gauges & Ignition

Spiral Corded Momentary Buttons Gauge Panels
Buttons are designed for fast,
consistent, and reliable trans-brake
release. Sealed spiral cord leads are
ideal for steering wheel mounting or
into a 5/8" hole. Momentary buttons
may also be used in many other
applications such as nitrous or line lock
activation. 18" spiral cords stretch to approximately 5'. Gauge panels are completely assembled, pre-wired, and include lighted
Part No. Description mechanical gauges, warning indicator lights with senders to alert you of
ALL80180 Spiral Cord With Small Green Button problems, detailed instructions, and installation template. Select from
ALL80181 Spiral Cord With Large Red Button
panels fitted with Allstar, Auto Meter Sport-Comp, Ultra-Lite, or Pro-Comp
liquid-filled 2-5/8" gauges. Panels are available in two, three, or four-gauge
Nitrous Pressure Control Kits
configurations.
Kit simplifies installation
of a nitrous bottle warmer,
while helping to maintain • Two-Gauge Panels Are 4-1/2" Tall x 7-1/4" Long. Gauges:
consistent bottle pressure. Oil Pressure And Water Temperature
12-volt kit includes an ad- • Three-Gauge Panels Are 4-1/2" Tall x 10-1/2" Long. Gaug-
justable pressure switch, es: Oil Pressure, Water Temperature And Oil Temperature
which controls the bottle Or Fuel Pressure
warmer. Each kit is sold
with adjustable pressure switch, -4AN or -6AN line adapter, 30-amp relay, • Four-Gauge Panels Are 4-1/2" Tall x 13-3/4" Long. Gauges:
30-amp circuit breaker, toggle switch, necessary terminals, and wiring. Oil Pressure, Water Temperature, Oil Temperature And Fuel
Part No. Description Pressure.
ALL76197 Pressure Control Kit With -4AN Line Adapter
ALL76198 Pressure Control Kit With -6AN Line Adapter Note: Fuel pressure isolator such as Autometer ATM5282 or Mallory
MAL29806 is always recommended when mounting a fuel pressure gauge
Nitrous Bottle Warmer inside vehicle.
ALL76428 Part No. Description
Nitrous bottle warmers Allstar
are the right way to ALL80090 2-Gauge Panel OP/WT
safely obtain correct pressure in ALL80091 3-Gauge Panel OP/WT/OT
colder weather. Wrap-around design ALL80092 3-Gauge Panel OP/WT/FP
ALL80093
evenly distributes heat to the bottle, Auto Meter Sport Comp 4-Gauge Panel OP/WT/OT/FP
eliminating “hot spots”. 12-16 volt warmers are designed to work with ALL80110 2-Gauge (OP/WT)
ALL76197 and ALL76198 pressure control kits. Bottle warmer measures 19" ALL80112 3-Gauge (OP/WT/OT)
x 6" and includes adjustable straps to fit most 5, 10, and 15 lb. bottles. ALL80113 3-Gauge (OP/WT/FP)
ALL80114 4-Gauge (OP/WT/OT/FP)
Auto Meter Pro-Comp (Liquid Filled)
Mechanical Gauges ALL80120 2-Gauge (OP/WT)
Allstar Performance 2-5/8" mechanical ALL80122 3-Gauge (OP/WT/OT)
gauges feature a full 270° sweeping ALL80123 3-Gauge (OP/WT/FP)
needle, silver-faced background, black Replacement Parts
bezel, and are backlit for easy reading ALL80134 Auto Meter Fuel Pressure Gauge Sport Comp 15 PSI
even during low-light conditions. Perfect ALL80136 Auto Meter Fuel Pressure Gauge Pro Comp 15 PSI
for building custom dash panels or when ALL80125 2-Gauge Mounting Panel, 4-1/2" x 7-1/4" (OP/WT)
adding mechanical gauges to replace existing gauges or warning lights. ALL80126 3-Gauge Mounting Panel, 4-1/2" x 10-1/2" (OP/WT/OT)
ALL80127 3-Gauge Mounting Panel, 4-1/2" x 10-1/2" (OP/WT/FP)
Part No. Description ALL80128 4-Gauge Mounting Panel, 4-1/2" x 13-3/4" (OP/WT/OT/FP)
ALL80095 Oil Pressure Gauge 0-100 PSI
ALL80096 Water Temperature Gauge 140-280 Degree
ALL80097 Oil Temperature Gauge 140-340 Degree LED Bulbs For Gauge Panels
ALL80098 Fuel Pressure Gauge 0-15 PSI ALL99147
ALL80099 Volt Gauge 8-18V
ALL99145 Replacement Bulb, Socket And Pigtail LED bulbs offer a brighter lighting solution and will
hold up much longer than standard bulbs on 16-volt systems.
