Page 161 - 2018 Racecar Engineering Late-Model Muscle Car Parts and Accessories Catalog

“Smart Sleeve” Pinion Crush Sleeve RAT11003
Ratech offers a new “Smart Sleeve” technology built into this pinion crush sleeve.
Replace the stock crush sleeve with more precise and consistent thrust pressure.
Approximately half the fastener torque normally required to compress the spacer.
Cycle duty is better than a solid spacer and shim pack.
Installation Kits Housing Basic Inst. Kit Installation Kit Bearing Kit Complete Kit
GM 7.5", 1993-96 RAT408K RAT108K RAT228B RAT308TK
Basic Kit: pinion shims, crush sleeve, pinion seal, cover gasket
Installation Kit: pinion shims, carrier shims, crush sleeve, pinion seal, pinion nut, ring gear bolts,cover gasket
Bearing Kit: pinion and carrier bearings
Complete Set: All small parts and bearings to com plete a ring and pinion installation.
Individual Component Parts
Whether it's carrier bearings or just a pinion nut, Ratech components will complete the rear end overhaul.
Housing Pinion Shims Carrier Shims Crush Sleeve / Smart Sleeve Pinion Seal Pinion Nut Ring Gear Bolt Cover Gasket Head Bearing Tail Bearing Carrier Bearing Set
GM 7.5" 1993-98 RAT1104 RAT1105 RAT3107/RAT11003 RAT6107 RAT1501 RAT1303 RAT5110 RAT7009 RAT8001 RAT9002

GM 7.5" And 7.625"
• Housing, Oval Cover, 10 Holes
• 7.5" And 7.625" Diameter Ring Gear
• 1.438" Diameter Pinion, 27-Spline
• '93-02 Firebird
Installation Kit 1993-98 RIC83-1044-1
Part No. Ratio Teeth Carrier
RIC49-0001-1 3.08 40-13 *
RIC49-0045-1 3.42 41-12 †
RIC49-0005-1 3.42 41-12 *
RIC49-0046-1 3.73 41-11 †
RIC49-0007-1 3.73 41-11 *
RIC69-0322-1 4.10 41-10 †
* Fits 3.08 and numerically lower carrier.
† Fits 3.23 and numerically higher carrier.

Oil Filter
Filter offers superior particle removal and optimized flow
characteristics for maximum performance and extended life.
Part No. Description
ROY10-47 1998-02, Firebird 3.8L V6
ROY10-454 1993-97, Firebird LT1, V8
ROY10-44 1998-02, Firebird LS1, V8
ROY10-44 2004-06, GTO, V8
ROY10-48 2008-09 G8/GXP 6.0L/6.2L, V8

Pre-Assembled, Direct Bolt-On Brake Hose Kits

Direct bolt-on brake hoses bring the ultimate in braking performance. They improve your braking
performance for competition or every-day driving. Replacing the O.E. rubber hoses with Russell brake
hoses reduces brake hose expansion for more consistent braking. Featuring stainless steel braided
hose with zinc-plated fittings, these brake hoses are factory assembled for convenient installation.
They meet the guidelines of the U.S. Dept. of Transportation MVSS-571.106 requirements.
Brake Hose Speed Bleeders
Year And Model Part No. Front Rear Hoses Per Kit Front Rear
1993-97 Firebird (Without Traction Control) RUS692260 Disc Disc 5 RUS639580 RUS639580
1998-02 Firebird (Without Traction Control) RUS692280 Disc Disc 5 RUS639630 RUS639630
1998-02 Firebird (With Traction Control) RUS692290 Disc Disc 6 RUS639630 RUS639630
2004 GTO — — — — RUS639590 RUS639530
2005-06 GTO RUS692320 Disc Disc 6 RUS639560 RUS639560
2008-09 G8 GT — — — — RUS639560 RUS639560
Livewire TS+ SCT5416P NEW!
Designed for use with 2008-09 Pontiac G8 6.0/6.2L and
2004-06 Pontiac GTO 5.7/6.0L, the Livewire TS+ improves
performance by recalibrating vehicle’s computer for maximum
horsepower and torque. Unit helps provide increased throttle
response, firmer shifts and increased fuel mileage. Switch-
on-the-fly feature allows changing power levels while driving.
Comes pre-loaded with dyno-proven performance tunes and
holds up to 10 custom tuning files for flexability.

160 PONTIAC PRODUCTS
